Quick Details
-
Product name:
-
Coin Cell Battery Tester
-
Application:
-
Finished Battery Tester
-
Source voltage:
-
AC 220V ±10% / 50Hz
-
Input active power:
-
25 W
-
Warranty:
-
1 Year
-
Constant voltage range control:
-
25mV~5V
-
Minimum discharge voltage:
-
0V
-
Output range per channel:
-
Range one:5uA~5mA;Range two:5mA~50mA
-
Server operating systems:
-
Windows 7
-
HS Code:
-
9030339000
Quick Details
-
Brand Name:
-
TOB
-
Place of Origin:
-
Fujian, China
-
Model Number:
-
TOB-CT4008-5V50mA-S1
-
Product name:
-
Coin Cell Battery Tester
-
Application:
-
Finished Battery Tester
-
Source voltage:
-
AC 220V ±10% / 50Hz
-
Input active power:
-
25 W
-
Warranty:
-
1 Year
-
Constant voltage range control:
-
25mV~5V
-
Minimum discharge voltage:
-
0V
-
Output range per channel:
-
Range one:5uA~5mA;Range two:5mA~50mA
-
Server operating systems:
-
Windows 7
-
HS Code:
-
9030339000
5V50mA 8 Channel Coin Cell Battery Voltage Analyzer Tester For Lithium Battery
1.TOB-5V50mA Battery analyzer is an eight-channel battery analyzer to analyze small coin cells
with a range current 0-50mah, voltage 0-5v. Each channel of the analyzer has independent
constant current and constantvoltage source, which can be programmed and controlled by computer software.
2. This coin cell tester system provides most applications in battery testing fields such as electrode materials research, battery performance test, smallscale battery formation, capability grading, battery pack testing, etc.
3.The coin cell tester is suitable for all kinds of coin cell battery such as lithium battery, NI-MH battery, Zn-Mn watch battery and so on.
|
Model: TOB-BTS-CT4008-5V50mA-S1 coin cell tester machine |
|||||||
|
Item |
Technology parameters |
||||||
|
Input power |
AC 220V ±10% / 50Hz |
||||||
|
Input active power |
25W |
|
|||||
|
Resolution ratio |
AD:16bit;DA:16bit |
||||||
|
Input impedence |
≥10G Ω |
||||||
|
Voltage |
Constant voltage range control |
25mV~5V |
|||||
|
Minimum discharge voltage |
0V |
||||||
|
Precision |
± 0.05% of FS |
||||||
|
Current |
Output range per channel |
Range one:5uA~5mA;Range two:5mA~50mA |
|||||
|
Precision |
± 0.05% of FS |
||||||
|
Constant voltage cut-off current |
Range one:10uA;Range two:0.1mA |
||||||
|
Stability |
± 0.05% of FS |
||||||
|
Power |
Single channel maximum output power |
0.25 |
W |
||||
|
Stability |
± 0.1% of FS |
||||||
|
Time |
Current response time |
Maximum current rise time : 1ms |
|||||
|
Step time range |
≤(365*24)Hour / step ,Time format support00:00:00.000(h,min,s,ms) |
||||||
|
Charging |
Charging mode |
Constant current charging, constant voltage charging, constant current and constant voltage charging, constant power charging |
|||||
|
Cut-off condition |
Voltage, current, relative time, capacity -δV |
||||||
|
Discharging |
Discharging mode |
Constant current discharge, constant power discharge, constant resistance discharge |
|||||
|
Cut-off condition |
Voltage, current, relative time, capacity -δV |
||||||
|
Burst Mode |
Charging |
Constant current mode, constant power mode |
|||||
|
Discharging |
Constant current mode, constant power mode |
||||||
|
Pulse number |
A single pulse step supports 32 different pulses |
||||||
|
Cut-off condition |
Voltage, relative time |
||||||
|
DCIR test |
Support custom fetch point for DCIR calculation |
||||||
|
IP protection level |
IP20 |
||||||
|
Channel control mode |
Independent control |
||||||
|
Voltage and current detection sampling |
Four wire connection |
||||||
|
Computer communication mode |
Base onTCP/IP agreement |
||||||
|
Server operating systems |
Windows 7 |
||||||
|
Data output mode |
EXCEL2003,2010,TXT |
||||||
|
Server disk configuration |
500GB |
||||||
|
Communication interface |
Ethernet |
||||||
|
Leakage current |
0.0000005mA |
||||||
|
Machine channels |
8 |
||||||
|
Item |
Parameter |
||||||
|
Operating temperature range |
0℃~40℃(range25±10℃,assuring measure accuracy:precision drift0.005% of FS /℃) |
||||||
|
Storage Temperature Range |
-10℃~50℃ |
||||||
|
Working environment relative humidity range |
≤70% RH(No condensation of water vapor) |
||||||
|
Storage environment relative humidity range |
≤80% RH(No condensation of water vapor) |
||||||
5V50MA Coin cell Battery Tester
accessories
packing details
