Quick Details
-
Brand Name:
-
LTMG
-
Fork Length:
-
920mm
-
Fork Width:
-
120mm
-
Overall Dimensions:
-
2035*1150*2145mm
-
Weight (KG):
-
2800 kg
-
Product Name:
-
Electric Forklift Truck
-
Key words:
-
electric forklift
-
Rated Capacity:
-
1500kg forklift
-
Ground Clearance(Bottom of mast):
-
110mm
-
Overall Dimension(without fork):
-
2035*1150*2145mm
-
Turning Radius:
-
1997mm
-
Max.Gradeability:
-
12-15%
-
Wheelbase:
-
1360mm
-
Mast Tilt Angle:
-
6°/12°
-
Marketing Type:
-
New Product 2022
Quick Details
-
Min. Lifting Height:
-
0M
-
Warranty:
-
1 Year
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
LTMG
-
Fork Length:
-
920mm
-
Fork Width:
-
120mm
-
Overall Dimensions:
-
2035*1150*2145mm
-
Weight (KG):
-
2800 kg
-
Product Name:
-
Electric Forklift Truck
-
Key words:
-
electric forklift
-
Rated Capacity:
-
1500kg forklift
-
Ground Clearance(Bottom of mast):
-
110mm
-
Overall Dimension(without fork):
-
2035*1150*2145mm
-
Turning Radius:
-
1997mm
-
Max.Gradeability:
-
12-15%
-
Wheelbase:
-
1360mm
-
Mast Tilt Angle:
-
6°/12°
-
Marketing Type:
-
New Product 2022
Advantages
|
Model
|
FB10
|
FB15
|
FB20
|
FB25
|
FB30
|
|
Rated Capacity
|
1000kg
|
1500kg
|
2000kg
|
2500kg
|
3000kg
|
|
Load Centre
|
500mm
|
500mm
|
500mm
|
500mm
|
500mm
|
|
Lift Height
|
3000mm
|
3000mm
|
3000mm
|
3000mm
|
3000mm
|
|
Fork Size (L×W×T)
|
920x100x35（mm）
|
920×120×35（mm）
|
1070×120×40（mm）
|
1070×120×40（mm）
|
1070×125×45（mm）
|
|
Length to fork face of fork (Without fork)
|
1950mm
|
2035mm
|
2360mm
|
2360mm
|
2610mm
|
|
Overall Width
|
1000mm
|
1150mm
|
1160mm
|
1160mm
|
1230mm
|
|
Overhead Guard Height
|
1875mm
|
1995mm
|
2240mm
|
2240mm
|
2250mm
|
|
Turning Radius (outside)
|
1800mm
|
1997mm
|
2075mm
|
2075mm
|
2350mm
|
|
Wheelbase
|
1200mm
|
1360mm
|
1510mm
|
1510mm
|
1700mm
|
|
Driven Motor
|
4KW
|
5.5KW
|
11KW
|
11KW
|
15KW
|
|
Lift Motor
|
5KW
|
6KW
|
8.6KW
|
8.6KW
|
12KW
|
|
Battery Standard
|
48/320V/Ah
|
48/400V/Ah
|
48/560V/Ah
|
48/630V/Ah
|
80/500V/Ah
|
|
Controller Manufacturer
|
CURTIS
|
CURTIS AC
|
CURTIS AC
|
CURTIS AC
|
CURTIS AC
|
Product selling point
1.【simple appearance】
1.【simple appearance】
The flowing outline of the truck chassis and the exposed application parts of metal materials make people shine. This forklift is light in weight, small in size, simple and elegant.
2.【reliable stability】
Advanced parallel layout of drive motor and lower located battery up to chassis bottom provide good stability to the truck. Low center of gravity provides good turning stability,
3.【Secure safety equipment】
Regenerative braking, reverse current braking and anti-slide on slop function guarantee the operation safety. Equipped a water cooling system with a good heat dissipation effect is used on a new energy forklift for the first time, so that the forklift can carry out long-time and high-intensity operations
4.【Environment protecting】
Low noise, no exhaust emission, and low energy consumption, all meet environment friendly requirement.
Low noise, no exhaust emission, and low energy consumption, all meet environment friendly requirement.
5.【Strong service capability】
Fully open the battery cover for easy battery maintenance, easy to open the counterweight cover, easy to protect the controller, contacter, power plug, emergency switch, dashboard and accelerator and other electronic products, avoid water and dust
