Quick Details
-
Warranty:
-
25 Years Warranty
-
Brand Name:
-
sunrover, sunrover
-
Model Number:
-
SUN540-560 DE21M(18)-182
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2278*1134*35mm
-
Application:
-
Solar Power System
-
Certificate:
-
TUV,CE, TUV/CE
-
Frame:
-
Anodized Aluminium Alloy
-
Weight:
-
27.5kg
-
Connector:
-
MC4 Compatible Connector
-
Efficiency:
-
21.7%
-
Solar cell:
-
A-grade
-
Junction Box:
-
IP68 Rated
-
Brand Name: sunrover Model Number:
-
SUN540-560 DE21M(18)-182
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, All Black, Flexible
-
Panel Efficiency:
-
21.7%
-
Warranty:
-
25 Years Warranty
-
Brand Name:
-
sunrover, sunrover
-
Model Number:
-
SUN540-560 DE21M(18)-182
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2278*1134*35mm
-
Application:
-
Solar Power System
-
Certificate:
-
TUV,CE, TUV/CE
-
Frame:
-
Anodized Aluminium Alloy
-
Weight:
-
27.5kg
-
Connector:
-
MC4 Compatible Connector
-
Efficiency:
-
21.7%
-
Solar cell:
-
A-grade
-
Junction Box:
-
IP68 Rated
-
Brand Name: sunrover Model Number:
-
SUN540-560 DE21M(18)-182
Products Description
Certifications
Product Paramenters
|
Module
|
SUN540-DE21M
|
SUN545-DE21M
|
SUN550-DE21M
|
SUN555-DE21M
|
SUN560-DE21M
|
||||
|
Maximum Power(Pmax)
|
540W
|
545W
|
550W
|
555W
|
560W
|
||||
|
Maximum Power Voltage(Vmp)
|
41.65V
|
41.80V
|
41.95V
|
42.10V
|
42.25V
|
||||
|
Maximum Power Current(Imp)
|
12.97A
|
13.04A
|
13.12A
|
13.19A
|
13.26A
|
||||
|
Open-circuit Voltage(Voc)
|
49.50V
|
49.65V
|
49.80V
|
49.95V
|
50.10V
|
||||
|
Short-circuit Current(Isc)
|
13.85A
|
13.92A
|
13.98A
|
14.04A
|
14.10A
|
||||
|
Module Efficiency STC(%)
|
20.90%
|
21.10%
|
21.30%
|
21.50%
|
21.70%
|
||||
|
Operating Temperature(℃)
|
-40℃~+85℃
|
|
|
|
|
||||
|
Maximum system voltage
|
1500V DC(IEC/UL)
|
|
|
|
|
||||
|
Maximum series fuse rating
|
25A
|
|
|
|
|
||||
|
Power tolerance
|
0-3%
|
|
|
|
|
||||
|
Temperature coefficients of Pmax
|
-0.340%℃
|
|
|
|
|
||||
|
Temperature coefficients of Voc
|
-0.265%℃
|
|
|
|
|
||||
|
Temperature coefficients of Isc
|
0.05%℃
|
|
|
|
|
||||
|
Nominal operating cell temperature(NOCT)
|
45±2℃
|
|
|
|
|
||||
Product packaging
|
Type
|
Pallet
|
40HQ
|
|
SUN535-555 DE21M(18)
|
31pcs
|
620pcs
|
