Quick Details
-
Power:
-
17.57
-
Dimension(L*W*H):
-
3600*1700*1600mm
-
Product name:
-
Turnover Basket Washing Machine
-
Application:
-
Food Industry
-
Function:
-
Turnover Basket Washing
-
size:
-
3600*1700*1600mm
Quick Details
-
Weight (KG):
-
800
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Bomeida
-
Power:
-
17.57
-
Dimension(L*W*H):
-
3600*1700*1600mm
-
Product name:
-
Turnover Basket Washing Machine
-
Application:
-
Food Industry
-
Function:
-
Turnover Basket Washing
-
size:
-
3600*1700*1600mm
The whole machine adopts SUS 304 food grade stainless steel material.Reliable performance,stable operation,simple installation and maintenance.It has the advantages of high production efficiency,good cleaning effect,low energy consumption and long service life.
|
Product name
|
Crate washing machine
|
Max crate size
|
W650*H300 MM
|
|||
|
Material
|
304 stainless steel
|
Thinckness
|
2.0mm
|
|||
|
Type
|
Manual/Auto-induction
|
Voltage
|
3ph,customized
|
|||
|
Type of heating
|
steam heating
|
Sterilization way
|
high temperature sterilization
|
|||
|
Three stage cleaning :3600*1700*1600mm
|
|
|
|
|||
|
Cleaning capacity
|
350-600pcs/h
|
The tank number
|
2pcs
|
|||
|
Power
|
13.37kw
|
Conveyor speed
|
4.9~8 m/min,adjustable
|
|||
|
Four stage cleaning :4800*1700*1600mm
|
|
|
|
|||
|
Cleaning capacity
|
600-1000pcs/h
|
The tank number
|
3pcs
|
|||
|
Power
|
17.57kw
|
The tank number
|
7.5~811.3m/min,adjustable
|
|||
Feature and advantage:
Unique circular chain track design,double track operation,so that the operation of the revolving box more stable;
Three-stage filtration system,enhance the cleanliness,reduce water tank stains.
Water tank level and water temperature are automatically controlled, through the solenoid valve according to the design of the water temperature for hot and cold ratio to the set temperature of 82 degrees Fahrenheit or 95 degrees Celsius, so that the energy consumption to the minimum.
Silicone waterproof gasket prevents water from flowing out of the inside of the screw
Different cleaning sections use different pressure nozzles
Stainless steel pipe connection adopts modular assembly, flexible connection joint, convenient disassembly and maintenance.
The liquid level and water temperature of three independent water tanks are automatically controlled,and the ration of hot and cold water reaches the set temperature of 82℃ or 95℃ through the solenoid valve according to the design water
Water tank with level measuring device, when the water level is insufficient, it will remind to add water
How to choose suitable crate washing machine:
1.According to the requirements of cleaning capacity, you can choose three stage cleaning(3600*1700*1600mm) or four stage cleaning(4800*1700*1600mm).
2.According to the requirements of equipment control,you can choose manual control and PLC automatic control.
3.According to the number of operators required,you can choose either one-way operation or two-way operation.
1.According to the requirements of cleaning capacity, you can choose three stage cleaning(3600*1700*1600mm) or four stage cleaning(4800*1700*1600mm).
2.According to the requirements of equipment control,you can choose manual control and PLC automatic control.
3.According to the number of operators required,you can choose either one-way operation or two-way operation.
Founded in 2021, to serve customers for the purpose ,
Bomeida
is committed to providing customers with one-stop service such as technical consultation, scheme design and equipment configuration for global food processing enterprises.
Many years of industry experience, Bomeida has a number of institutions and platforms, involving food plant process design and research and development, equipment application, technical guidance, production and manufacturing, etc., for the development of Bomeida provides practical experience and foundation.
As a resource integrator and equipment procurement expert, Bomeida provides practical and feasible advice for customers from single machine equipment to large factory assembly line procurement. And have been insisting on providing customers with intelligent, efficient, safe, simple and practical food processing equipment, and serving for the standardized design and management of factories, so that the traditional processing mode can be replaced by intelligent and efficient.
Bomeida
products cover the whole food industry chain, from cleaning and disinfection of food plants, primary processing of raw materials (including slaughtering of meat and poultry, sorting and cutting of fruits and vegetables) to deep processing of raw materials (cooked food, meat products, steak, prepared vegetables, etc.). It involves slaughtering, meat products, fresh distribution, cooked food, group meal/central kitchen, baking, pet food, fruit and vegetable processing and other industries.
We provide customized solutions for each customer, establish independent files, communicate with each link in time, strictly control the quality of each piece of equipment, ensure the smooth installation and commissioning of equipment, timely respond to customer feedback, and constantly improve products. We always adhere to the "integrity-based, enthusiastic service" business philosophy, continue to create more valuable products and services for customers, and constantly improve customer trust and satisfaction.
FAQ
1. What are your prices?
Our prices are subject to change depending on supply and other market factors. We will send you an updated price list after your company contact
us for further information.
2.Do you have a minimum order quantity?
No,one set is ok.You just need to buy according to your needs.
3.Can it be customized?
Yes, Most of our products can be customized.
4.What is the average lead time?
The lead time is 15-30 days after receiving the deposit payment.
The specific delivery date is related to whether the voltage of the product is customized, the number of products and the production schedule of the workshop.
Please check the actual delivery date with the salesman according to the actual situation.
5.What kinds of payment methods do you accept?
T/T,L/C,or Alibaba trade assurance order
