Quick Details
-
Engine Brand:
-
Laidong
-
Weight:
-
1997 KG
-
Product name:
-
Wheel Tractor
-
Engine:
-
4 Cylinder Diesel Engine
-
Size:
-
3760*1530*2160mm
-
Wheelbase:
-
1930 mm
-
Clutch form:
-
dry, single, single-acting
-
Gearbox:
-
(4+1)* 2 Composed
-
Number of gears:
-
8+2 (optional 10+2)
-
Shift mode:
-
gear sleeve shift
-
Steering system type:
-
hydraulic steering
Quick Details
-
Brand Name:
-
Demao
-
Place of Origin:
-
Shandong, China
-
Marketing Type:
-
Hot Product
-
Engine Brand:
-
Laidong
-
Weight:
-
1997 KG
-
Product name:
-
Wheel Tractor
-
Engine:
-
4 Cylinder Diesel Engine
-
Size:
-
3760*1530*2160mm
-
Wheelbase:
-
1930 mm
-
Clutch form:
-
dry, single, single-acting
-
Gearbox:
-
(4+1)* 2 Composed
-
Number of gears:
-
8+2 (optional 10+2)
-
Shift mode:
-
gear sleeve shift
-
Steering system type:
-
hydraulic steering
Products Description
This series of products is currently the performance of advanced tractors, two-wheel drive and four-wheel drive two series. With the transmission efficiency, low vibration, traction, adaptability, start-saving features. The mini tractor It is suitable for gardening, greenhouse,lawn and family work. The tractor is assembled with good diesel engine,double stage clutch. Dual-way hydraulic output and hydraulic steering,which is popular in international market.
|
Model
|
DM-400
|
DM-500
|
|
Size
|
3340*1515*2255mm
|
3340*1580*2280mm
|
|
Wheelbase
|
1985mm
|
2000mm
|
|
Machine weight
|
1395kg
|
1494kg
|
|
Engine
|
Diesel engine
|
Diesel engine
|
|
Clutch form
|
dry, single, single-acting
|
dry, single, single-acting
|
|
Gearbox
|
(4+1)*2 Composed
|
(4+1)* 2 Composed
|
|
Number of gears
|
8+2 (optional 10+2)
|
8+2 (optional 10+2)
|
|
Shift mode
|
sliding gear type
|
gear sleeve shift
|
|
Steering system type
|
hydraulic steering
|
hydraulic steering
|
|
Tire standard
|
5.00-15/11.2-24
|
6.00-16/11.2-28
|
|
Suspension device form
|
rear three-point suspension
|
rear three-point suspension
|
|
Model
|
DM-800
|
DM-804
|
|
Size
|
3710*1530*2160mm
|
3760*1530*2160mm
|
|
Wheelbase
|
1930 mm
|
1930mm
|
|
Machine weight
|
1884 kg
|
1997kg
|
|
Engine
|
Diesel engine
|
Diesel engine
|
|
Clutch form
|
dry, single, single-acting
|
dry, single, single-acting
|
|
Gearbox
|
(4+1)* 2 Composed
|
(4+1)* 2 Composed
|
|
Number of gears
|
8+2
|
8+2 (optional 10+2)
|
|
Shift mode
|
gear sleeve shift
|
gear sleeve shift
|
|
Steering system type
|
hydraulic steering
|
hydraulic steering
|
|
Tire standard
|
6.00-16/11.2-28
|
7.50-16/11.2-28
|
|
Suspension device form
|
rear three-point suspension
|
rear three-point suspension
|
|
Model
|
DM704-A
|
DM904-A
|
|
Size
|
3800*1650*2680mm
|
3800*1650*2680mm
|
|
Wheelbase
|
1950mm
|
1950mm
|
|
Wheel track (front/rear)
|
1300/1300mm
|
1300/1300mm
|
|
Optional wheel track
|
1200/1300mm
|
1200/1300mm
|
|
Engine model
|
Xinchai 4D32ZT33/704
|
Xinchai 4D32ZT33/904
|
|
Engine power rating
|
66.2kW
|
66.2kW
|
|
Engine calibration speed
|
2400r/min
|
2400r/min
|
|
Tire model (front/rear)
|
8.3-24/14.9-30
|
8.3-24/14.9-30
|
|
PTO speed
|
540/720(r/min)
|
540/720(r/min)
|
