Quick Details
-
Product name:
-
Fast Constructed Prefab House Container Price Of Used Containers
-
Size:
-
3(W)x6(L)x2.6m(H)
-
Description:
-
1 open room
-
Area m2/unit:
-
18
-
Container Loading Quantity:
-
12 units/40HQ
-
ADDITIONAL OPTIONS:
-
Electrical, plumbing, toilet and bath, ceiling,
-
ADDITIONAL OPTIONS 2:
-
flooring, kitchen, furniture,air conditioner, heater,
-
Model Number:
-
SC0603
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Max Prefab
-
Product Type:
-
Container House
-
Product name:
-
Fast Constructed Prefab House Container Price Of Used Containers
-
Size:
-
3(W)x6(L)x2.6m(H)
-
Description:
-
1 open room
-
Area m2/unit:
-
18
-
Container Loading Quantity:
-
12 units/40HQ
-
ADDITIONAL OPTIONS:
-
Electrical, plumbing, toilet and bath, ceiling,
-
ADDITIONAL OPTIONS 2:
-
flooring, kitchen, furniture,air conditioner, heater,
-
Model Number:
-
SC0603
SC0603 Hot Selling Fast Constructed Prefab House Container Price Of Used Containers
Product Paramenters
|
DIMENSION
|
3(W)x6(L)x2.6m(H)
|
|
STACKING
|
Not available for this system
|
|
FLOORING
|
Plywood/MGO flooring 18mm with PVC flooring covering 1.5mm
|
|
ROOF and WALLS
|
2’’ Styrofoam insulation on walls and roof with oven baked double sided PPGI
|
|
ASSEMBLY
|
No need to use crane in order to assemble, two people can carry each part of container house while disassembled. Two people can install 1 standard unit in 4 hours.
Can be lifted by crane after installation |
|
ELECTRICAL
|
Electrical wires can be concealed locally on walls and roof.
Electrical items are not included in our standard offer |
|
WINDOWS AND DOORS
|
Aluminum sliding windows with single clear glass. Security shutter are optional item.
Double sided PPGI with 2’’ Styrofoam insulation door. The doors and windows can be fixed in random position. Interior partitions can be arranged in any position inside the room |
Product Description
1. Pre-painted light-steel frame with good welding & polishing workmanship;
2. Roof: 50mm EPS sandwich panel 0.376mm PPGI
3. Exterior wall and interior partition: 50mm EPS sandwich panel 0.376mm PPGI
2. Roof: 50mm EPS sandwich panel 0.376mm PPGI
3. Exterior wall and interior partition: 50mm EPS sandwich panel 0.376mm PPGI
4. Doors: EPS sandwich panel door with Cylindrical Knob sets
5. Windows: Aluminum sliding windows with single clear glass
6. Ceiling is not included in this offer
7. Flooring:18mm plywood + 1.5mm PVC flooring in rolls are included.
8. Furnitures, kitchen cabinet, sanitary wares, bathroom accessories, electric appliances, electrical items, lights, wiring, plumbing, heating are optional items which are not included in this offer.
5. Windows: Aluminum sliding windows with single clear glass
6. Ceiling is not included in this offer
7. Flooring:18mm plywood + 1.5mm PVC flooring in rolls are included.
8. Furnitures, kitchen cabinet, sanitary wares, bathroom accessories, electric appliances, electrical items, lights, wiring, plumbing, heating are optional items which are not included in this offer.
9. Interior partitions and interior doors are included in this offer.
|
Wind Load Capaciy:
|
Grade 11 (wind speed<120 km/h)
|
|
Anti-seismic Performance:
|
GB50011-2001.GB50017-2003 Meet
|
|
Meet Seismic Forticition Intensity:
|
Grade 7
|
|
Sound Insulation Performance:
|
35 db
|
|
Snow load capacity of roofing:
|
30 kg/m²
|
|
Live load capacity of roofing:
|
30 kg/m²
|
|
Wall and Roof heat transmission coefficient:
|
K=0.414(m2·K/W)
|
|
Wall permitted loading:
|
30 kg/m²
|
|
Floor load capacity:
|
120kg/m²
|
|
Density of EPS:
|
12 kg/m3
|
|
Density of Rockwool:
|
80~120 kg/m3
|
|
Density of PU:
|
35~45 kg/m3
|
|
Delivery time
|
Normally 20-25 days
|
|
Container loading
|
According to the quotation, please fill in 20 foot container loading quantity and 40 tall ark of loading quantity
|
Installation Instructions
Easy to assemble and transport, foolproof installation can be done:
1. Hang the bottom on the place where you need it to be.
2. Install the four corner columns on the bottom, then fix it with M12 screw bolt.
3. Hang the top on the four corner columns, then fix it with M12 screw bolt.
4. Check with gradienter, make the four corner columns be vertical.
5. Insert the wall panel one by one from the short side clockwise.(14 pieces in total )
6. Install the prefabricated vertex angle and base angle which we call them PVC at the correct position. (Give a good push to it, very convenient.)
7. Then fixing,switch,socket,brushing glue, laying the ground are the last steps. (If the combined house is needed, the container houses should be connected with screw bolt and iron sheet before inserting the wall panel.)
1. Hang the bottom on the place where you need it to be.
2. Install the four corner columns on the bottom, then fix it with M12 screw bolt.
3. Hang the top on the four corner columns, then fix it with M12 screw bolt.
4. Check with gradienter, make the four corner columns be vertical.
5. Insert the wall panel one by one from the short side clockwise.(14 pieces in total )
6. Install the prefabricated vertex angle and base angle which we call them PVC at the correct position. (Give a good push to it, very convenient.)
7. Then fixing,switch,socket,brushing glue, laying the ground are the last steps. (If the combined house is needed, the container houses should be connected with screw bolt and iron sheet before inserting the wall panel.)
Product Advantages
1. Customizable Sizes
2. Complete knock down system, quick assembly and disassembly
3. Low cost
4. Reusable for several times.
5. Can be combined in length and width side
6. Stackable 2 layers and can be lifted by crane
7. Transportable by truck
2. Complete knock down system, quick assembly and disassembly
3. Low cost
4. Reusable for several times.
5. Can be combined in length and width side
6. Stackable 2 layers and can be lifted by crane
7. Transportable by truck
1.Container house designed according to ISO 1161 for various purpose.I.e,hospital,dormitory,office,store room etc. Also are suitable for international container transport and stand in the remote area and nature neatly.
2.Save high labor cost, the main structure of container house ---- bottom frame, top frame and side wall panels to form a light weight structure, pre-made good self-drainage system, pre-made electrical, pre-made water-plumbing in factory, quick to fold out, assemble disassemble the components.
3.Flexibility combination, the construction enables compounding of individual container house in transverse or longitudinal directions without limits, and can also be stacked 2~4 stories, to enlarge the space and function. The top, bottom and around the container house used heat insulation, heat preservation materials, providing comfortable temperature for the internal living.
4.Easy transportation and saving high transportation cost, every four units will packed as a standard 20’ HC shipping container size. And each dimension is 6058*2438*720 which can be moved by forklift, but after four units packed as a standard 20’ HC shipping container size, the package can only be moved by crane.
5.All the materials used are green and recyclable.
6.Fast installation, 2 skilled workers can finish one container house in 3 hours.
7.Superior performance: Beautiful appearance, sturdy and durable, and also with good anti-corrosion, heatproof, windproof, earthquake proof, moisture proof, waterproof, and anti-creep functions.
8.Complete functions: With lights, socket, wirings, doors and windows and external power source configured inside the panels.
2.Save high labor cost, the main structure of container house ---- bottom frame, top frame and side wall panels to form a light weight structure, pre-made good self-drainage system, pre-made electrical, pre-made water-plumbing in factory, quick to fold out, assemble disassemble the components.
3.Flexibility combination, the construction enables compounding of individual container house in transverse or longitudinal directions without limits, and can also be stacked 2~4 stories, to enlarge the space and function. The top, bottom and around the container house used heat insulation, heat preservation materials, providing comfortable temperature for the internal living.
4.Easy transportation and saving high transportation cost, every four units will packed as a standard 20’ HC shipping container size. And each dimension is 6058*2438*720 which can be moved by forklift, but after four units packed as a standard 20’ HC shipping container size, the package can only be moved by crane.
5.All the materials used are green and recyclable.
6.Fast installation, 2 skilled workers can finish one container house in 3 hours.
7.Superior performance: Beautiful appearance, sturdy and durable, and also with good anti-corrosion, heatproof, windproof, earthquake proof, moisture proof, waterproof, and anti-creep functions.
8.Complete functions: With lights, socket, wirings, doors and windows and external power source configured inside the panels.
About Max Prefab
High wind resistant ability - They are used as houses for rent because they are sturdy,Max Prefab House Co.,Ltd is an innovative manufacturing company with great commitment, contribution heart, passion and responsibility.
We are specialized in designing, manufacturing and building high quality environmental prefabricated houses, container houses, foldable containers, portable homes, steel structure warehouses and architectural steel construction.
We are specialized in designing, manufacturing and building high quality environmental prefabricated houses, container houses, foldable containers, portable homes, steel structure warehouses and architectural steel construction.
