Quick Details
-
Brand:
-
Bestcreate
-
Application:
-
PCBA
-
Color:
-
Black
-
Contact:
-
Copper Alloy
-
Contact Rating:
-
1.5A
-
Contact Resistance:
-
100m ohms Max
-
Insulation Resistance:
-
1000m ohms Min
-
Dielectric Withstanding Voltage:
-
500VAC 1 minute.
-
Operating force:
-
1000gf Max
-
Plating:
-
GOLD FLASH 1u"(min) SOLDERTALL
-
Operating Temperature:
-
-40°to+85°
-
Mechanical Life:
-
3000cycles minimum
-
Package:
-
Tube&Reel
Quick Details
-
Model Number:
-
HPXXTSGET
-
Type:
-
DP Switch
-
Place of Origin:
-
Guangdong, China
-
Brand:
-
Bestcreate
-
Application:
-
PCBA
-
Color:
-
Black
-
Contact:
-
Copper Alloy
-
Contact Rating:
-
1.5A
-
Contact Resistance:
-
100m ohms Max
-
Insulation Resistance:
-
1000m ohms Min
-
Dielectric Withstanding Voltage:
-
500VAC 1 minute.
-
Operating force:
-
1000gf Max
-
Plating:
-
GOLD FLASH 1u"(min) SOLDERTALL
-
Operating Temperature:
-
-40°to+85°
-
Mechanical Life:
-
3000cycles minimum
-
Package:
-
Tube&Reel
|
Insulator
|
|
PBT Black UL94-0
|
|
|
|||
|
Contacts
|
|
Copper Alloy
|
|
|
|||
|
Current Rating
|
|
1.5 AMP.
|
|
|
|||
|
Dielectric Withstand Voltage
|
|
500V DC
|
|
|
|||
|
Contact Resistance
|
|
100MILLIOHMS MAX.
|
|
|
|||
|
Insulation Resistance
|
|
1000 MEGOHMS MIN
|
|
|
|||
|
Operating Temperature
|
|
-40℃～+85℃
|
|
|
|||
|
Mating Force
|
|
1000gf Max
|
|
|
|||
|
Unmating Force
|
|
1000gf Max
|
|
|
|||
|
Durability
|
|
3000 CYCLES MIN.
|
|
|
|||
|
Certification
|
|
SGS,ROHS,ISO9001
|
|
|
|||
|
Packaging
|
|
Tube &Reel
|
|
|
|||
|
SPQ
|
|
1000PCS/Reel
|
|
|
|||
Contact me to get PDF and 3D Drawing .
