COVNA 1/2 inch Automatic Drainage Water Solenoid Valve with Timer
COVNA 1/2 inch Automatic Drainage Water Solenoid Valve with Timer
COVNA 1/2 inch Automatic Drainage Water Solenoid Valve with Timer
COVNA 1/2 inch Automatic Drainage Water Solenoid Valve with Timer
COVNA 1/2 inch Automatic Drainage Water Solenoid Valve with Timer
COVNA 1/2 inch Automatic Drainage Water Solenoid Valve with Timer
COVNA 1/2 inch Automatic Drainage Water Solenoid Valve with Timer
COVNA 1/2 inch Automatic Drainage Water Solenoid Valve with Timer

COVNA 1/2 inch Automatic Drainage Water Solenoid Valve with Timer

FOB Reference Price: Get Latest Price
≥2 Sets
US $30.78
≥50 Sets
US $30.5
≥100 Sets
US $30
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Model Number:
HK-11-4 Solenoid Valve with Timer
Brand Name:
COVNA
Product name:
Auto drain solenoid valve
Connection:
Female Thread
Working pressure:
0-10bar
Voltage:
DC12V/DC24V/DC36V/AC36V/AC110V/AC220V/AC380V
Certification:
Reach

Quick Details

Port Size:
1/2 inch Solenoid Valve
Warranty:
1 years
Place of Origin:
Zhejiang, China
Model Number:
HK-11-4 Solenoid Valve with Timer
Brand Name:
COVNA
Product name:
Auto drain solenoid valve
Connection:
Female Thread
Working pressure:
0-10bar
Voltage:
DC12V/DC24V/DC36V/AC36V/AC110V/AC220V/AC380V
Certification:
Reach

Our Advantages

Wenzhou COVNA aims to provide our customers the best quality products with the most competitive pricing, on-time delivery and full warranty service.

19 YEARS manufacturer of actuated valves, MASS CUSTOMIZATION acceptable.

• 3 production base, large stock, SHORT LEAD TIME , same day shipping.

• German imported manufacturing facilities, 100% Q.C passed before shipping, quality assured. Industrial standard 1 YEAR (12 months) warranty.

• ISO 9001 certificated, with extra certifications include CE, TUV, RoHS, SGS, BV , explosion & fire safe.

OEM / ODM service available.

COVNA 1/2 inch Automatic Drainage Water Solenoid Valve with Timer
Model
HK11-4
Voltage
220V AC
MOQ
1 Set
No. of Ways
2/2 Way
Pipe Size
1/2 inch
Operation
Diaphragm
Orifice
15mm
Switching Function
Normally Closed (NC)
Operating Pressure
0 to 1.0MPa
Media
Water, Oil, Gas, Liquid
Body Material
Brass
Temp. of Media
-20°C to 80°C
Sealing Material
NBR/FKM
Certification
ISO 9001, CE, TUV, SGS
End Connection
Female Thread
Warranty
1 Year (12 Months)

Dimension

Click to enlarge

S91B Solenoid Coil
S41B Solenoid Coil
Ex1620 Solenoid Coil
DIN43650B Solenoid Coil
Model
Specification
S91B Solenoid Coil
Voltage: AC 24V/110V/220V/240V, 50/60Hz; DC 12V/24V/48V
Power Consumption: AC: 22VA; DC: 17W
Protection Class: H
S41B Solenoid Coil
Voltage: AC 24V/110V/220V/240V, 50/60Hz; DC 12V/24V/48V
Power Consumption: AC: 18VA; DC: 11W
Protection Class: H
Ex1620 Ex-proof Coil
Voltage: AC 220V, 50Hz; DC 24V
Power Consumption: AC: 20VA; DC: 16W
Protection Class: H

Analog Timer Specification

Specification of Solenoid Valve Timer
Voltage
24-230V AC/DC, 50/60Hz
Current (Continuous)
1A
Current (Peak)
10A During 10ms
Power Consumption
4mA Max. (Standby)
Operating Temperature
-10°C ~ +50°C
Lifetime Switch
3*10^8 × Switching
Time ON
From 0 to 10 Seconds (Potentiometer)
Time OFF
From 0 to 45 Minutes (Potentiometer)
Program
Repeating ON-OFF
Indicator
Red LED'S
Connector
EN 175301-803 (Formally DIN 43650A)
IP Rating
IP65-EN 60529

About Wenzhou COVNA

Wenzhou COVNA Valve Co., Ltd.

Wenzhou COVNA is one of the top manufacturers of quarter turn actuators and actuated valve products in China with 19 years experience. All COVNA products are designed and manufactured by experienced engineers to provide safe and reliable valves, actuators and solutions. COVNA aims to provide our customers the best quality products with the most competitive pricing, on-time delivery and full warranty service.

Our Certificates

Global Trusted

Packing Details

Packing details : each valve will be packed with foam in carton or in pallet to keep it safe during shipment.

Shipping method : we offer a variety of fast shipping methods, including DHL, Fedex, TNT, UPS, EMS, Airway, etc.

Delivery time : within 15 working days after payment due, stocking items same-day shipping.

FAQs

1. When can I get the price?

We usually quote within 3 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.

2. How can I get a sample to check your quality?

After price confirmation, you can require for samples to check our quality. If you just need a blank sample to check the design and paper quality, we will provide you sample for free, as long as you afford the express freight.

3. How long can I expect to get the sample?

After you pay the sample charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3-5 workdays. You can use your own express account or prepay us if you do not have an account.

4. How long does the whole procedure being worked out?

After you place a order,the production handling time is about 45-60 days. We need 15 days to prepare all the stuff then 30 days for manufacturing.

5. What about the transportation and delivery date?

Normally we use shipment to transprot the goods.It is about 25-40 days. It also denpends on which coutry and port you are. It could be shorter if you need to send the goods like Asian.

If there are some emergencies we can send the goods via air express, as long as you afford the traffic expense.
