Quick Details
-
Brand Name:
-
PLK LIFT
-
Dimension(L*W*H):
-
1230*910*390
-
Weight (KG):
-
100 kg
-
lifting capacity:
-
400/600/800/1000/1200KG
-
cup qty:
-
4-12pcs
-
Single Cup Size:
-
300mm
-
Rotation:
-
360°manual rotate
-
Tilting:
-
90° manual
-
Extension Bar Length:
-
500 MM
-
volte:
-
DC12v
-
charger:
-
AC220/110V
-
sucker frame size:
-
customization
Quick Details
-
Warranty:
-
1 Year
-
Marketing Type:
-
Hot Product 2024
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
PLK LIFT
-
Dimension(L*W*H):
-
1230*910*390
-
Weight (KG):
-
100 kg
-
lifting capacity:
-
400/600/800/1000/1200KG
-
cup qty:
-
4-12pcs
-
Single Cup Size:
-
300mm
-
Rotation:
-
360°manual rotate
-
Tilting:
-
90° manual
-
Extension Bar Length:
-
500 MM
-
volte:
-
DC12v
-
charger:
-
AC220/110V
-
sucker frame size:
-
customization
Europe standard CE certified 600kg vacuum glass lifter for installing window
PLK LIFT
suction caps
are specially design for handling different kinds of heavy plate, board and glass, useful for installing steel board, glass wall, moving such as granite, marble.
The following are the main parameters,If the following parameters do not meet your requirements, they can be customized according to your requirements.
|
Model |
GL-SC-400X |
GL-SC-600X |
GL-SC-800X |
GL-SC-1000X |
GL-SC-1200X |
|
|
Lifting Capacity |
kg |
400 |
600 |
800 |
1000 |
1200 |
|
Cup Qty |
/ |
4 |
6 |
8 |
10 |
12 |
|
Single Cup Size |
mm |
300 |
300 |
300 |
300 |
300 |
|
Single Cup Lifting Capacity |
kg |
100 |
100 |
100 |
100 |
100 |
|
Rotation |
/ |
360°manual rotate |
||||
|
Tilting |
/ |
90° manual |
||||
|
Volte |
V |
DC12 |
||||
|
Charger |
V |
AC220/110 |
||||
|
Weight |
kg |
70 |
90 |
100 |
110 |
120 |
|
Sucker Frame Size |
mm |
850*750*300 |
1800*900*300 |
1760*1460* 300 |
1900*1600* 300 |
1900*1600* 300 |
|
Extension Bar Length |
mm |
500 |
||||
|
Control System |
/ |
Integrated Control Cabinet and Wired Remote Control |
||||
|
Overall Size after packing by wooden box |
mm |
1230*910*390 |
||||
|
Gross Weight after packing by wooden box |
kg |
97 |
110 |
123 |
150 |
163 |
Features & Advantages
:
1.Sealed cover for components protection,safe and reliable. Usually cooperated with bridge crane to use in glass deep processing and handling job, or with cantilever crane to use in glass curtain wall installation job .
2.Adjustable type, can be changed the position of the suction cup to absorb glass of different shapes and sizes (also can be customized according to the glass size)
3.Manually rotated 360° in the vertical side, and manually rotated 90° in the horizontal side, but taking and releasing by electric
4.Adopt American THOMAS vacuum pump and high quality maintenance-free battery, no need the air source or power supply during use.
5.Japan Panasonic digital display vacuum pressure switch , battery fuel gauge, clearly monitor the safty use.
6.With vacuum pressure auto supply system, during handling glass, ensure the whole vacuum system maintained at a relatively constant safety pressure value
7.Equipped with the power-cut but pressure-keeping device and alarm device. If power failure accidently,the pressure-keepping function can extend the handling time and make the use safer.
8.Equipped with 12V backup battery, can be replaced in time to ensure the progress of the project.
Offer OEM & ODM service,according to different materials size and weight.
Please inform us the materials you want to lift,as well as size and weight to get a proper proposal.
