Printing Head
|
EPSON XP600
|
EPSON DX5/DX7
|
|
|
Printing Speed
|
6pass 12m2/H
|
4pass 15m2/H
|
|
|
|
9pass 9m2/H
|
6pass 12m2/H
|
|
|
|
12pass 6m2/H
|
8pass 8m2/H
|
|
|
Color
|
CMYK(4 Color)
|
|
|
|
Printing Width
|
1.6m/1.8m
|
|
|
|
Ink
|
Eco solvent ink
|
|
|
|
Media
|
Indoor outdoor advertisement materials
|
|
|
|
Fabric Thickness
|
2-30mm
|
|
|
|
Interface
|
Internet cable
|
|
|
|
RIP
|
Maintop
|
|
|
|
Voltage
|
220V AC 50/60HZ
|
|
|
|
Operating environment
|
Temperature 20~30℃ /Humidity:35%~65%
|
|
|
|
File Format
|
BMP/JPG/PDF,TIFF
|
|
|
1. Built-in two stage heater ,Intelligent exterior heater+Fan
2. Optional XP600/DX5/DX7 print head , High printing precision
3. Hiwin slider, low noise , low friction
4. Optional Eco solvent/Water-based ink ,fulfil all your printing demands
Hangzhou Caiyue Tubang Technology Co.Ltd is a leading company which specialized in digital printers and ink for Textile and Advertisement Industry ,now own brand CY TOPBON,SUTENG and MEITENG.Our factory is located in Hangzhou China,near Shanghai port.As a professional High-tech enterprise ,We integrates research ,production, sales and After sales together.
Our joint venture-Hangzhou YuLan Technology Co. Ltd,is specialized in Sublimation printer,Eco solvent printer and UV printer
Our joint venture-Hangzhou Yichi Precision Machinery Manufacturing Co.,Ltd,is specialized in digital printer spare parts and other precision spare parts.
TOPBON,as a sales and after sales headquarter,We hired many talented engineers to serve all over the world.we devote to printer improvement ,new technology research and trusty after sale service.
The concept of TOPBON is the :QUALITY,SERVICE,TRUST.We always make the latest and best products to different countries to achieve win-win strategic policy.
1. Adopt variable do printing technology. There are 8 columns of nozzles in the print head, every column contains 180nozzles, and therefore, there are a total of 1440 nozzles.
2. Selfdeveloped automatic cleaning and capping system which makes the operation and maintenance convenient
3. AC servo motor for both X and Y direction which are stable and durable.
4. New designed constant pressure ink supply system with inserted ink bottle which is clean, reliable, at the same, the ink flow is more fluent.
5. Carriage height adjustable system (Max. printing height 10mm).
6. Rear, platen, and front individual heating system improve the printing quality.
7. No space between bearings and rails for the carriage movement with low noise, low resistance, and no vibration. Market approved that it is durable
8. Fixed feeding structure which is compatible with 2 and 3 inch paper core. Equipped with take-up balancing bar which is flexible and easy to use.
