Quick Details
-
Insulation Material:
-
PTFE
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
KMCABLE
-
Model Number:
-
FLR5Y
-
Product name:
-
FLR5Y
-
Conductor:
-
Copper
-
Insulation:
-
PTFE
-
Certification:
-
CE CCC ISO
-
Temperature:
-
-90°C to +260°C
-
Standard:
-
ISO 6722 Class H
-
Package:
-
500M/roll
-
Feature:
-
High temperature resistance
-
Core:
-
Single Core Stranded Wire
Quick Details
-
Application:
-
Car
-
Conductor Material:
-
Copper
-
Conductor Type:
-
Stranded
-
Insulation Material:
-
PTFE
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
KMCABLE
-
Model Number:
-
FLR5Y
-
Product name:
-
FLR5Y
-
Conductor:
-
Copper
-
Insulation:
-
PTFE
-
Certification:
-
CE CCC ISO
-
Temperature:
-
-90°C to +260°C
-
Standard:
-
ISO 6722 Class H
-
Package:
-
500M/roll
-
Feature:
-
High temperature resistance
-
Core:
-
Single Core Stranded Wire
Products Description
FLR5Y
This PTFE insulated low-tension automotive cable is used in motorcycles and other motor vehicles for starting
,charging,lighting,signal and instrument panel circuits.
Specifications
|
Model
|
FLR5Y
|
|
Conductor
|
Class 5 copper conductor
|
|
No. of Cores
|
1
|
|
Conductor Type
|
stranded
|
|
Insulation
|
PTFE
|
|
Nominal voltage
|
up to 24V
|
|
Test voltage
|
1KV
|
|
Nominal cross-sectional area of conductor(mm²)
|
0.5~25(mm²)
|
|
Application
|
vehicle constructions
|
|
Colors
|
Black or custom
|
|
Ambient temperature
|
–90°C to +260°C
|
|
NOMINAL CROSS- SECTION
|
THICKNESS WALL MIN.
|
OVERALL DIAMETER
|
WEIGHT APPROX.
|
|
1x 0.35
|
0.20
|
1.35
|
5
|
|
1x0. 5
|
0.22
|
1.6
|
6
|
|
1x 0. 75
|
0.24
|
1.9
|
9
|
|
1x1
|
0.24
|
1.95
|
11
|
|
1x 1.5
|
0.24
|
2.3
|
16
|
|
1x2.5
|
0.28
|
2.8
|
26
|
|
1x4
|
0.32
|
3.35
|
40
|
|
1x6
|
0.32
|
4.15
|
61
|
Application
