Low price Digital Display Resiliometer Concrete Test Hammer

Low price Digital Display Resiliometer Concrete Test Hammer

FOB Reference Price: Get Latest Price

≥1 Sets

US $540

≥5 Sets

US $420

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: Lovely

Model Number:: HT225S

Sensor:: MOS image sensor

Display:: Color LCD Display

Strength range:: 10~60 Mpa

Power Supply:: rechargeable built-in lithium battery

Hammer strock:: 75mm

Weight:: 4.6KGs

Quick Details

Warranty:: 1 year

Power:: Electronic

Place of Origin:: Hebei, China

Brand Name:: Lovely

Model Number:: HT225S

Sensor:: MOS image sensor

Display:: Color LCD Display

Strength range:: 10~60 Mpa

Power Supply:: rechargeable built-in lithium battery

Hammer strock:: 75mm

Weight:: 4.6KGs

Parameters

HT225S Digital Display Resiliometer Concrete Test Hammer

GTJ-HT225S Digital Display Resiliometer Concrete Test Hammer is used for non-destructive testing and evaluation of the compressive strength of hardened concrete in building structures. The parameters such as carbonization depth value, bounce angle, bounce test surface, and whether to pump or not can be set according to on-site inspection conditions. After the test is completed, the strength estimation result of the component can be given immediately.

Model	GTJ-HT225
Sensor	MOS image sensor
Phone APP language	English/Chinese
Phone	5 inch Android system (optional)
Print function	Supports micro bluetooth printer (optional)
Data Acquisition Terminal	Input mode	Automatically record rebound value
		Data processing	Automatic date vevision, calculation and analysis
		Display mode	LCD
		System capacity	200,000 Measuring points
		Power mode	Rechargeable large capacity lithium battery
		Wolume	1235525mm
		Weight	200g
Mechanical Rebound Tester	Range of strength measurement	10~60 Mpa
		Nominal kinetic energy	2.207J
		Stiffness of spring strike	7.84N/cm
		Hammer stroke	75mm
		Indicative Consistency error	＜0.5
		Calibrated rebound value of steel anvil	80±2
		Volume	5555270mm
		Weight	1.1KG
Working environment requirements	Temperature: -10℃ ~ +40℃ Humidity：＜90%RH
Packing Specification	Material: engineering plastic Volume:420140335mm Weight: 4.8Kgs

Detailed Images

Digital Display Resiliometer Concrete Test Hammer with App

PRODUCT FEATURES:

◎Mobile APP control;

◎Instrument calibration can correct the deviation caused by temperature or environment;

◎Special computer software for data analysis can quickly generate test reports;

◎Portability: One-piece design, small size and easy to carry.

◎Digitalization: The rebound value is displayed in two forms of numbers and pointers, and the displayed value is consistent.

◎Convenience: Manage data according to components, estimate intensity, and record carbonization value on site. ◎Automation: Parameters such as the number of test areas, test direction, pouring surface, and pumping can be set and modified.

Digital Display Resiliometer Concrete Test Hammer with App

After a component is tested and calculated, it is automatically transferred to the next test area according to the same parameters, eliminating the need for on-site manual recording and improving Detection efficiency and timeliness.

Phone and Mini printer are also available.
