Quick Details
-
Model Number:
-
ZT-CA-04
-
Place of Origin:
-
Hunan, China
-
Test channel number:
-
4 channel; 4 different parameters analysis in the same time
-
Sample incubation block:
-
24 positions
-
Reagent incubation block:
-
6 positions
-
Software timer:
-
4
-
Momery:
-
10000 test result
-
Test wavelength:
-
470nm
-
Temp control precision:
-
37±0.3℃
-
Reagent consume:
-
20uL-40uL
-
Notation of Result:
-
S, %, PTR, INR, g/L
-
Weight:
-
7kg
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support
-
Brand Name:
-
ZETOP MEDICAL
-
Model Number:
-
ZT-CA-04
-
Place of Origin:
-
Hunan, China
-
Test channel number:
-
4 channel; 4 different parameters analysis in the same time
-
Sample incubation block:
-
24 positions
-
Reagent incubation block:
-
6 positions
-
Software timer:
-
4
-
Momery:
-
10000 test result
-
Test wavelength:
-
470nm
-
Temp control precision:
-
37±0.3℃
-
Reagent consume:
-
20uL-40uL
-
Notation of Result:
-
S, %, PTR, INR, g/L
-
Weight:
-
7kg
Product Description
BASIC FEATURES
●
Low reagent consumption less than 20uL, open reagent
●Special testing cup location system, adding sample bracket
●
Advanced optical light matching system ensure precision result.
●
Optional PT Derived method for testing fibrinogen, decease the dosage of reagent
●
Top quality thermostat, precision 37℃ ±0.3℃
●
Dispense precision: Cv<2%
●
Memory for 10.000 testing results
●
Internal thermal-sensitive printer
●
Electronically-linked pipette optional
●
Perform all routine tests such as PT. APTT. TT Fibrinogen and clotting factors
●RS232 interface, PC connecting
USUAL TEST LIST
Prothrombin PT
Activated Partial thromboplastin time APTT
Thrombin time TT
Fibrinogen FIB
RT, VT, VIII, IX, XI, XII, II, V, VII, X, PS, PC, Xa, etc.
Prothrombin PT
Activated Partial thromboplastin time APTT
Thrombin time TT
Fibrinogen FIB
RT, VT, VIII, IX, XI, XII, II, V, VII, X, PS, PC, Xa, etc.
Specification
|
Test channel
|
4 channels, 4 different parameters analysis in the same time.
|
|
Sample pre-warming position
|
24 positions
|
|
Reagent pre-warming position
|
6 positions
|
|
Software timer
|
4
|
|
Test wavelength
|
470nm
|
|
Memory
|
10000 test result
|
|
Temp control precision
|
37±0.3℃
|
|
Sample consume
|
20uL-40uL
|
|
Reagent consume
|
20uL-40uL
|
|
Coincidence indicator
|
≤3%
|
|
Notation of result
|
S, %, PTR, INR, g/L
|
|
Operation language
|
English
|
|
Screen
|
240*128 LCD
|
|
Power supply
|
220VAC±15% 50-60Hz
|
|
Dimension
|
395mm(L)×320mm(W)×135mm(H)
|
|
Work environment
|
temperature 15℃-30℃ wet≤90%
|
|
Weight
|
7Kg
|
