Quick Details
-
Model Number:
-
NETPRO-33S
-
Weight:
-
Other
-
Product name:
-
Online UPS
-
Battery Type:
-
Lead Acid Battery
-
Wave Form:
-
Pure Sinewave
Quick Details
-
Warranty:
-
1 year
-
Place of Origin:
-
Istanbul, Turkey
-
Brand Name:
-
Servo Matik
-
Model Number:
-
NETPRO-33S
-
Weight:
-
Other
-
Product name:
-
Online UPS
-
Battery Type:
-
Lead Acid Battery
-
Wave Form:
-
Pure Sinewave
Products Description
SERVO-MATIK NETPRO-33S SERIES ONLINE UPS 10KVA -40KVA THREE PHASE INPUT-THREEPHASE OUTPUT BEST PRICE
• Online Uninterrupted Power supplies
•
High Frequency Double Conversion Technology
• Pure Sine Wave
• ECO Mode
• DSP Microprocessor Control
• Intelligent Battery Charge Topology
• Energy Saving High Efficiency
• LCD Display
• Cost-effective solution with superior input and output performance
• Wide Input Voltage Operating Range
• Short Circuit, Overload and Lightning Protection
• Intelligent Communication Options
• Common Technical Service Support
• ISO 9001,Standards
General Features
- Pure Sine Wave Output Online Ups
- Double Conversion Technology
- DSP Microprocessor Controlled
- IGBT Rectifier And Inverter
- Active Input Power Factor Correction PFC (
≥
0.99)
-
Low Input Thdi (
<%3
)
With Excelent Generator Compatibility
-
Low Output Thdv<%3-5 Perfect Energy For Loads
-Excellent Compatibility With Loads
-Wide Input Voltage Range (160 - 260 VAC)
-High Efficiency Up To %95
-Ultra High Efficiency With Smart Eco Mode (%98)
-Reliable Parallel/ Redundant Operation With Load Synchronization
-Smart Fan Control
-EMI / RFI Filter
-Short Circuit, High/Low Voltage And Overload Protections
-Adjustable Time For Battery Operation
-Battery Deep Discharge
Protection
-Temperature Controllable Battery Charger, Selectable Charge Current
-Standard Static And Manual By-Pass
-240 X 320 Touch Screen Graphical LCD Display
-Advanced Fault Identifıcation, 1000 PCS Alert/Event Memory
-Advanced Communication Options With RS232/RS485
Optional Features
- Advanced Remote Monitoring And Management With SNMP
- Long Back Up With External Batteries
- Easy Power Up With Paralleling
- Galvanic Isolation Transformer
- Special Input / Output Options
Standards
- EN 62040-1 Safety - EN 62040-2 EMC - EN 62040-3 LVD - ISO 9001:2015
Product Paramenters
|
Place of Origin
|
Turkey
|
|
Warranty
|
1 Year
|
|
Brand Name
|
Servo-Matik
|
|
Model Number
|
NETPRO-33S
|
|
Phase
|
Three Phase
|
|
Type
|
Online
|
|
Application
|
Home,Office,
|
|
Input voltage
|
380V/400V/415VAC
|
|
Capacity
|
10kVA, 20kVA, 30kVA, 40kVA
|
|
Noise Level
|
≤50dB (1m)
|
|
Output Frequency
|
50/60±0.2 Hz
|
Product packaging
|
Package Type
|
Pallet, Carton box
|
