Quick Details
-
Voltage:
-
220--380
-
Weight:
-
1000 KG
Quick Details
-
Type:
-
LINEAR
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
POWO
-
Voltage:
-
220--380
-
Weight:
-
1000 KG
Folding Vibrating Separator Sand Screen Sieve Machine
1. Economical & efficient classification, Screening.
2. Screen replaceable for different mesh sizes.
3. Multiple screen size and easily changed screen plates, mesh is not easy to block.
4. screening tube can be closed, easy to close dust collection.
5. Unique design with higher capacity & no clogging.
6. Heavy duty feed hopper and extension.
7. Gear drive mechanism.
8. With a special screen, high screening efficiency, long service life.
|
Model |
Power (kw) |
Hopper (mm) |
Conveyor (mm) |
Conveying height (mm) |
Screen hole diameter (mm) |
Screen size (mm) |
Vibration power (kw) |
Capacity (m³/h) |
Dimensions (mm) |
|
20 sand screen machine |
7 |
2000x1100 |
8400x500 |
2200 |
8 (Replaceable) |
1500x600 |
0.5 |
70-90 |
4300x1300x2600 |
|
30 sand screen machine |
12 |
3200x1500 |
16000x800 |
3200 |
10 (Replaceable) |
3000x800 |
0.5 |
130-170 |
8200x1600x3000 |
|
50 sand screen machine |
15 |
3700x1600 |
18000x1000 |
3300 |
10 (Replaceable) |
3500x1100 |
0.5 |
150-210 |
9300x2000x3600 |
