1- Roof Top:
The roof is designed to stand up even the harshest environment of extreme snow disaster with the echo of top and down part
strong structure and connecting radial ribs which is Z interconnected again itself. Roof panels incorporate with ribs with over and under lap profiles ensuring a precise fit.
2- Body Steel Plate:
A commercial275g/m2 double galvanized steel coating increases life and durability.450g/m2 and 600g/m2 coating available for customized order. Each sidewall sheets are manufactured from high-tensile steel that has the ability to overcome extreme power, pressure.
- Product Details
- {{item.text}}
Quick Details
-
Dimension(L*W*H):
-
15.5*15.5*23.86
-
Weight:
-
39630 KG
-
Product name:
-
wheat silos 12500 mt
-
Application:
-
Farming Industry
-
Farming Industry:
-
Hopper Bottom
-
Installation and Debugging:
-
Engineers Service Overseas
-
Silo Materials:
-
Hot Galvanized Steel
-
Type:
-
Bolted Assembly Corrugated Steel Silo
-
Handling Equipments:
-
Conveyor, Elevator
-
Auxillary System:
-
Cleaning, Ventilation System
-
Key Words:
-
Grain Storage Silos
-
After-Sales Service Provided:
-
Field Installation, Commissioning and Training
Quick Details
-
Core Components:
-
silos
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Famtun Silos
-
Dimension(L*W*H):
-
15.5*15.5*23.86
-
Weight:
-
39630 KG
-
Product name:
-
wheat silos 12500 mt
-
Application:
-
Farming Industry
-
Farming Industry:
-
Hopper Bottom
-
Installation and Debugging:
-
Engineers Service Overseas
-
Silo Materials:
-
Hot Galvanized Steel
-
Type:
-
Bolted Assembly Corrugated Steel Silo
-
Handling Equipments:
-
Conveyor, Elevator
-
Auxillary System:
-
Cleaning, Ventilation System
-
Key Words:
-
Grain Storage Silos
-
After-Sales Service Provided:
-
Field Installation, Commissioning and Training
CHINA TOP 3# GRAIN STORAGE SOLUTION PROVIDER FAITHFUL SILO
1.About Faithful silo system
Typical grain storage system process flow diagram(PFD)
1.grain discharging pit---2.grain cleaning /dedusting---3.grain handling/ silo feeding-----4.grain drying--5.grain storage /condition monitoring /maintaining--6.grain offloading /silo output /car loading
How do we assure the silo durability?Faithful silo
3- Stiffeners:
FAITHFUL’s high tension stiffener(can be located inside or outside the silo,) profiles make bins stronger allowing silos to stand well even under an extreme hurricane. Base stiffener boots are coated so they won’t rust over time.
4- Wind Ring: For tall silos or that need to resist heavy wind. Wind ring and brackets reduce bolt holes in stiffeners; swaged technology ensure silo power load capacity
5- High strength bolts and screws:
FAITHFUL’s high strength bolts paired with sealing washers, coated hardware provides added protection from rust to ensure your grain bin stands the test of time.
6- Manhole: double layer security locking manhole system
7- Wide Flange H Beam Support Structure:
Wide flange H-Beam support structure has the strength and durability
to support the heavy hopper silo loads a long time, and with consideration
of wind and seismic requirements.
FAITHFUL’s high tension stiffener(can be located inside or outside the silo,) profiles make bins stronger allowing silos to stand well even under an extreme hurricane. Base stiffener boots are coated so they won’t rust over time.
4- Wind Ring: For tall silos or that need to resist heavy wind. Wind ring and brackets reduce bolt holes in stiffeners; swaged technology ensure silo power load capacity
5- High strength bolts and screws:
FAITHFUL’s high strength bolts paired with sealing washers, coated hardware provides added protection from rust to ensure your grain bin stands the test of time.
6- Manhole: double layer security locking manhole system
7- Wide Flange H Beam Support Structure:
Wide flange H-Beam support structure has the strength and durability
to support the heavy hopper silo loads a long time, and with consideration
of wind and seismic requirements.
RECOMMEDATION OF FAITHFUL SILO MODELS
Mostly, we recommend our customers to choose
hopper -bottom silos
with capacity range
50T-1000T
,
flat bottom silo
s with capacity range from
1500T-10000T
|
diameter(m)
|
model
|
capacity(m3)
|
ring beam（m)
|
silo height(m)
|
whole height(m)
|
weight(t)
|
|
3.6
|
TCZ03602
|
33
|
2.69
|
4.99
|
5.83
|
1.45
|
|
|
TCZ03603
|
45
|
|
6.11
|
6.95
|
2.03
|
|
|
TCZ03604
|
56
|
|
7.23
|
8.07
|
2.25
|
|
|
TCZ03605
|
68
|
|
8.35
|
9.19
|
2.46
|
|
|
TCZ03606
|
80
|
|
9.47
|
10.31
|
2.68
|
|
|
TCZ03607
|
92
|
|
10.59
|
11.43
|
2.9
|
|
4.5
|
TCZ04503
|
73
|
3.19
|
6.61
|
7.66
|
2.98
|
|
|
TCZ04504
|
92
|
|
7.73
|
8.78
|
3.25
|
|
|
TCZ04505
|
111
|
|
8.85
|
9.9
|
3.51
|
|
|
TCZ04506
|
129
|
|
9.97
|
11.02
|
3.77
|
|
|
TCZ04507
|
148
|
|
11.09
|
12.14
|
4.18
|
|
|
TCZ04508
|
166
|
|
12.21
|
13.26
|
4.45
|
|
|
TCZ04509
|
185
|
|
13.33
|
14.38
|
4.78
|
|
5.5
|
TCZ05504
|
138
|
3.62
|
8.16
|
9.42
|
5.14
|
|
|
TCZ05505
|
165
|
|
9.28
|
10.54
|
5.67
|
|
|
TCZ05506
|
192
|
|
10.3
|
11.66
|
6.04
|
|
|
TCZ05507
|
218
|
|
11.52
|
12.78
|
6.52
|
|
|
TCZ05508
|
245
|
|
12.64
|
13.9
|
7.31
|
|
|
TCZ05509
|
272
|
|
13.76
|
15.02
|
7.66
|
|
|
TCZ05510
|
298
|
|
14.88
|
16.14
|
8.02
|
|
|
TCZ05511
|
324
|
|
16
|
17.26
|
9.65
|
|
6.4
|
TCZ06405
|
231
|
4.07
|
9.73
|
11.21
|
8.11
|
|
|
TCZ06406
|
267
|
|
10.85
|
12.33
|
8.46
|
|
|
TCZ06407
|
303
|
|
11.97
|
13.45
|
8.93
|
|
|
TCZ06408
|
339
|
|
13.09
|
14.57
|
9.31
|
|
|
TCZ06409
|
375
|
|
14.21
|
15.69
|
9.98
|
|
|
TCZ06410
|
411
|
|
15.33
|
16.81
|
10.61
|
|
|
TCZ06411
|
447
|
|
16.45
|
17.93
|
11.44
|
|
7.3
|
TCZ07305
|
314
|
4.53
|
10.19
|
11.88
|
9.65
|
|
|
TCZ07306
|
361
|
|
11.31
|
13
|
10.18
|
|
|
TCZ07307
|
408
|
|
12.43
|
14.12
|
10.84
|
|
|
TCZ07308
|
455
|
|
13.55
|
15.24
|
11.49
|
|
|
TCZ07309
|
503
|
|
14.67
|
16.36
|
12.2
|
|
|
TCZ07310
|
550
|
|
15.79
|
17.48
|
12.82
|
|
|
TCZ07311
|
597
|
|
16.91
|
18.6
|
14.11
|
|
|
TCZ07312
|
644
|
|
18.03
|
19.72
|
14.59
|
|
|
TCZ07313
|
692
|
|
19.15
|
20.84
|
15.19
|
|
8.2
|
TCZ08206
|
468
|
4.98
|
11.76
|
13.66
|
14.2
|
|
|
TCZ08207
|
528
|
|
12.88
|
14.78
|
14.7
|
|
|
TCZ08208
|
588
|
|
14
|
15.9
|
15.28
|
|
|
TCZ08209
|
648
|
|
15.12
|
17.02
|
15.97
|
|
|
TCZ08210
|
708
|
|
16.24
|
18.14
|
16.93
|
|
|
TCZ08211
|
768
|
|
17.36
|
19.26
|
18.89
|
|
|
TCZ08212
|
828
|
|
18.48
|
20.38
|
20.42
|
|
|
TCZ08213
|
888
|
|
19.6
|
21.5
|
21.4
|
|
|
TCZ08214
|
948
|
|
20.72
|
22.62
|
22
|
|
9.1
|
TCZ09107
|
666
|
5.43
|
13.33
|
15.45
|
20.74
|
|
|
TCZ09108
|
740
|
|
14.45
|
15.57
|
21.59
|
|
|
TCZ09109
|
886
|
|
15.57
|
17.69
|
22.44
|
|
|
TCZ09110
|
886
|
|
16.69
|
18.81
|
23.29
|
|
|
TCZ09111
|
960
|
|
17.81
|
19.93
|
24.13
|
|
|
TCZ09112
|
1034
|
|
18.93
|
21.05
|
25.55
|
|
|
TCZ09113
|
1108
|
|
20.05
|
22.17
|
26.83
|
|
|
TCZ09114
|
1182
|
|
21.17
|
23.29
|
27.72
|
|
10
|
TCZ01008
|
914
|
5.89
|
14.91
|
17.24
|
27.27
|
|
|
TCZ01009
|
1003
|
|
16.03
|
18.36
|
28.09
|
|
|
TCZ01010
|
1092
|
|
17.15
|
19.48
|
29.02
|
|
|
TCZ01011
|
1181
|
|
18.27
|
20.6
|
30.27
|
|
|
TCZ01012
|
1271
|
|
19.39
|
21.72
|
31.36
|
|
|
TCZ01013
|
1360
|
|
20.51
|
22.84
|
32.58
|
|
|
TCZ01014
|
1449
|
|
21.63
|
23.96
|
34.27
|
|
|
TCZ01015
|
1539
|
|
22.75
|
25.08
|
35.64
|
|
11
|
TCZ01108
|
1112
|
6.33
|
15.35
|
17.89
|
30.49
|
|
|
TCZ01109
|
1218
|
|
16.47
|
19.01
|
31.75
|
|
|
TCZ01110
|
1324
|
|
17.59
|
20.13
|
32.7
|
|
|
TCZ01111
|
1430
|
|
18.71
|
21.25
|
33.95
|
|
|
TCZ01112
|
1536
|
|
19.83
|
22.37
|
35.17
|
|
|
TCZ01113
|
1643
|
|
20.95
|
23.49
|
36.36
|
|
|
TCZ01114
|
1749
|
|
22.07
|
24.61
|
38.57
|
|
|
TCZ01115
|
1855
|
|
23.19
|
25.73
|
39.93
|
|
11.9
|
TCZ011909
|
1481
|
7.35
|
10.15
|
20.55
|
34.25
|
|
|
TCZ011910
|
1606
|
|
11.27
|
21.67
|
35.661
|
|
|
TCZ011911
|
1731
|
|
12.39
|
22.79
|
37.212
|
|
|
TCZ011912
|
1856
|
|
13.51
|
23.91
|
40
|
|
|
TCZ011913
|
1981
|
|
14.63
|
25.03
|
43
|
|
|
TCZ011914
|
2106
|
|
15.75
|
26.15
|
46
|
|
|
TCZ011915
|
2231
|
|
16.87
|
27.27
|
48
|
|
|
TCZ011916
|
2356
|
|
17.99
|
28.39
|
50
|
|
|
TCZ011917
|
2481
|
|
19.11
|
29.51
|
52
|
FAITHFUL SILO DETAILS
1.goose neck vents 2.inspection man-hole 3.wall stiffener 4.silo roof beam
1. hopper areation inlets 2.high strength bolts 3.silo wind ring 4.ladder with fence
Worry-Free After-Sale Service
* FAITHFUL provides advanced grain safety storage technology to assure your grain 100% quality stability.
* Quality guarantee is one year after installation and commissioning or 18 months after leaving China Port. Maturity is the first.
* 7 days x 24 hours service, within 8 hours reply/solve of any technical issues upon request.
* Routinely telephone track to remove all might be problems or issues guarantying the whole system long-lasting safety and reliability.
* FAITHFUL will consider all other needs like customs clearance, sea delivery, insurance, customs tax benefit plan, documentation, etc. So our respected Users feel so relaxed and easy to get the silo system well.
* Quality guarantee is one year after installation and commissioning or 18 months after leaving China Port. Maturity is the first.
* 7 days x 24 hours service, within 8 hours reply/solve of any technical issues upon request.
* Routinely telephone track to remove all might be problems or issues guarantying the whole system long-lasting safety and reliability.
* FAITHFUL will consider all other needs like customs clearance, sea delivery, insurance, customs tax benefit plan, documentation, etc. So our respected Users feel so relaxed and easy to get the silo system well.
