Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Woda
-
Year:
-
2019
-
Voltage:
-
Customer Request
-
Dimension(L*W*H):
-
1000X900x1450
-
Weight (T):
-
4.2 T
-
Motor Power (kw):
-
11 kw
-
Power Source:
-
Hydraulic
-
Product name:
-
250Tons Home Dish 150cm Satellite TV Antenna Making machine Press
-
Color:
-
Customer Request
-
Keyword:
-
hydraulic press
-
Keyword 2:
-
Hydraulic press Machine
-
Type:
-
metal sheet forming machine
-
Usage:
-
Pot and kitchen sink making
-
Power souce:
-
Electricity Hydraulic power
-
Application:
-
four pillar hydraulic press machine
-
Function:
-
Deep Drawing
-
Certification:
-
CE
Quick Details
-
Machine Type:
-
Four-column Three-beam Hydraulic Press
-
Slide Stroke (mm):
-
400mm
-
Return Force (kN):
-
250 kN
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Woda
-
Year:
-
2019
-
Voltage:
-
Customer Request
-
Dimension(L*W*H):
-
1000X900x1450
-
Weight (T):
-
4.2 T
-
Motor Power (kw):
-
11 kw
-
Power Source:
-
Hydraulic
-
Product name:
-
250Tons Home Dish 150cm Satellite TV Antenna Making machine Press
-
Color:
-
Customer Request
-
Keyword:
-
hydraulic press
-
Keyword 2:
-
Hydraulic press Machine
-
Type:
-
metal sheet forming machine
-
Usage:
-
Pot and kitchen sink making
-
Power souce:
-
Electricity Hydraulic power
-
Application:
-
four pillar hydraulic press machine
-
Function:
-
Deep Drawing
-
Certification:
-
CE
Product Description
YD32- 250Tons Home Dish 150cm Satellite TV Antenna Making machine Pressing machine
Characteristic:
200 ton sheet metal forming four pillar hydraulic press machine can be operated with automatic one cycle design; two hand push button design for simple and safe operation. Fish bait forming four column hydraulic press could also realize three-operation mode: adjustment, manual and semi-automatic.
200 ton sheet metal forming four pillar hydraulic press machine Parameter:
| project | 200T-A | 200T-AK | 200T-AZS | 200T-B | 200T-BK | 200T-BZS | 200T-C | 200T-CK | 200_CZS | 200T-TKS |
| Max liquid working presure(Mpa) | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 |
| Slide stroke(mm) | 400 | 600 | 600 | 400 | 600 | 600 | 400 | 600 | 600 | 600 |
| Max openging height(mm) | 800 | 1000 | 1000 | 800 | 1000 | 1000 | 800 | 1000 | 1000 | 1000 |
| Worktable size(mm*mm) | 660*660 | 660*660 | 660*660 | 800*800 | 800*800 | 800*800 | 1000*1000 | 1000*1000 | 1000*100 | 1260*1200 |
| Descent speed(mm/s) | 30 | 100 | 190 | 30 | 100 | 190 | 30 | 100 | 190 | 100 |
| Return speed(mm/s) | 20 | 70 | 100 | 20 | 70 | 160 | 20 | 70 | 160 | 100 |
| Motor power(KW) | 7.5 | 7.5 | 11 | 7.5 | 7.5 | 11 | 7.5 | 7.5 | 11 | |
| Displacedment oil pump(ml/r) | 40 | 40 | 63 | 40 | 40 | 63 | 40 | 40 | 63 | |
| Knock-out pressure(t) | 35 | 35 | 35 | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
| Stroke of knock-out(mm) | 250 | 250 | 250 | 250 | 250 | 250 | 250 | 250 | 250 | 300 |
