Quick Details
-
Cooling/Heating:
-
Cooling/Heating
-
Power Source:
-
Electric
-
App-Controlled:
-
Yes
-
Fixed Frequency/Variable Frequency:
-
Variable frequency
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
MORHEE
-
COP:
-
3.62
-
Power (W):
-
1640
-
Voltage (V):
-
220
-
Maximum Airflow Rate:
-
1200m³/h
-
Recommended Room Size（square feet）:
-
500
-
Compressor type:
-
Triple-cylinder Two-stage Rotary Compressor of Variable Volume Ratio
-
Compressor name:
-
GREE
-
Applicable temperature range:
-
-15~54℃
-
WIFI Control:
-
Yes
-
Intelligent Defrosting:
-
Yes
-
Anti-corrosive Golden/Blue Fin:
-
Yes
-
High Temp Resistance PCB:
-
Fireproof
-
Refrigerant:
-
R410A
-
Auto Clean:
-
X-FAN
-
Low Noise:
-
19dB
Quick Details
-
Capacity (btu):
-
36000-48000btu
-
EER:
-
3.21
-
Type:
-
Split Wall Mounted Air Conditioners
-
Cooling/Heating:
-
Cooling/Heating
-
Power Source:
-
Electric
-
App-Controlled:
-
Yes
-
Fixed Frequency/Variable Frequency:
-
Variable frequency
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
MORHEE
-
COP:
-
3.62
-
Power (W):
-
1640
-
Voltage (V):
-
220
-
Maximum Airflow Rate:
-
1200m³/h
-
Recommended Room Size（square feet）:
-
500
-
Compressor type:
-
Triple-cylinder Two-stage Rotary Compressor of Variable Volume Ratio
-
Compressor name:
-
GREE
-
Applicable temperature range:
-
-15~54℃
-
WIFI Control:
-
Yes
-
Intelligent Defrosting:
-
Yes
-
Anti-corrosive Golden/Blue Fin:
-
Yes
-
High Temp Resistance PCB:
-
Fireproof
-
Refrigerant:
-
R410A
-
Auto Clean:
-
X-FAN
-
Low Noise:
-
19dB
Specification
|
Model name
|
|
|
MGCHV-DH080W/R1
|
MGCHV-DH100W/R1
|
MGCHV-DH125W/R1
|
|||||
|
Power supply
|
|
|
220~240V/1N/50Hz
|
220~240V/1N/50Hz
|
220~240V/1N/50Hz
|
|||||
|
|
|
|
220~240V/1N/60Hz
|
220~240V/1N/60Hz
|
220~240V/1N/60Hz
|
|||||
|
Performance data
|
|
|
|
|
|
|||||
|
Cooling
|
Capacity (T1/T3)
|
HP
|
3
|
3.6
|
4.5
|
|||||
|
|
|
kW
|
T1:8/T3:7.2
|
T1:10/T3:9.0
|
T1:12.5/T3:11.3
|
|||||
|
|
|
Btu/h
|
T1:27300/T3:24570
|
T1:34100/T3:30690
|
T1:42600/T3:38340
|
|||||
|
|
|
RT
|
T1:2.27/T3:2.04
|
T1:2.84/T3:2.56
|
T1:3.55/T3:3.20
|
|||||
|
|
Power input (T1/T3)
|
kW
|
T1:2.6/T3:2.81
|
T1:3/T3:3.25
|
T1:3.2/T3:3.46
|
|||||
|
|
Rated current(T1/T3)
|
A
|
T1:11.8/T3:14.2
|
T1:13.6/T3:16.4
|
T1:14.5/T3:17.5
|
|||||
|
|
EER (T1/T3)
|
W/W
|
T1:3.08/T3:2.56
|
T1:3.33/T3:2.77
|
T1:3.74/T3:3.27
|
|||||
|
Heating
|
Capacity
|
kW
|
9
|
11
|
14
|
|||||
|
|
|
Btu/h
|
30700
|
37500
|
47800
|
|||||
|
|
|
RT
|
2.56
|
3.13
|
3.98
|
|||||
|
|
Power input
|
kW
|
2.65
|
3.10
|
3.52
|
|||||
|
|
Rated current
|
A
|
12.0
|
14.0
|
16.1
|
|||||
|
|
COP
|
W/W
|
3.39
|
3.55
|
3.83
|
|||||
|
Max. input consumption
|
|
kW
|
3.96
|
4.40
|
7.48
|
|||||
|
Max. current
|
|
A
|
18
|
20
|
34
|
|||||
|
Physical data
|
|
|
|
|
|
|||||
|
Refrigerant
|
Type
|
|
R410a
|
R410a
|
R410a
|
|||||
|
|
Volume
|
kg
|
2.0
|
2.6
|
3.0
|
|||||
|
|
Throttle type
|
|
EXV
|
EXV
|
EXV
|
|||||
|
Dimension (W*H*D)
|
Net
|
mm
|
935×702×383
|
1032x810x445
|
1100×870×528
|
|||||
|
|
Packing
|
mm
|
975×770×420
|
1075×875×495
|
1140×965×540
|
|||||
|
Weight
|
Net
|
kg
|
47
|
60
|
85
|
|||||
|
|
Gross
|
kg
|
50
|
65
|
95
|
|||||
|
Outdoor sound level
|
|
dB(A)
|
≤54
|
≤56
|
≤56
|
|||||
|
Maximum operating pressure
|
|
MPa
|
4.5
|
4.5
|
4.5
|
|||||
|
Operation temperature range
|
|
|
|
|
|
|||||
|
Cooling
|
Outdoor side
|
°C
|
-5~55
|
-5~55
|
-5~55
|
|||||
|
|
Indoor side
|
°C
|
16~32
|
16~32
|
16~32
|
|||||
|
Heating
|
Outdoor side
|
°C
|
-15~30
|
-15~30
|
-15~30
|
|||||
|
|
Indoor side
|
°C
|
16~32
|
16~32
|
16~32
|
|||||
Notes：
1. Cooling operating temperature range is from -5°C to 55°C. Heating operating temperature range is from -15°C to 30°C.
2. The cooling conditions: indoor side 27°C(80.6°F) DB, 19°C(60°F)WB outdoor side 35°C(95°F) DB.
3. The heating conditions: indoor side 20°C(68°F) DB, 15°C(44.6°F)WB outdoor side 7°C(42.8°F)DB.
4. Sound level: measured at a point 1 m in front of the unit at a height of 1.5 m. During actual operation, these values are normally somewhat higher as a result of ambient conditions.
5. The company reserves the right to revise product technical parameter without having to notify the clients individually.
