Quick Details
-
Power:
-
14.2/2200Kw/rpm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
NIVO
-
Maximum Digging Height:
-
3700mm
-
Maximum Digging Depth:
-
2400mm
-
Machine Weight:
-
2000 kg
-
Max Digging Radius:
-
4050mm
-
Rated Speed:
-
2.8Km/h
-
Warranty of core components:
-
1year
-
Max. Dozer Cutting:
-
270mm
-
Max. Dozer Lifting:
-
240mm
-
Tail Swing Radius:
-
650mm
-
Dozer Blade:
-
1050*240mm
-
Traveling Tracking Force:
-
16kN
-
Bucket Digging Force:
-
20kN
-
Arm Digging Force:
-
11kN
-
Grade ability:
-
35°
-
Swing Speed:
-
0-9r/min
-
Boom Deflexion (Left/Right):
-
75/45
Quick Details
-
Operating Weight:
-
2000kg
-
Bucket capacity:
-
0.07m3
-
Engine Brand:
-
Kubota
-
Power:
-
14.2/2200Kw/rpm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
NIVO
-
Maximum Digging Height:
-
3700mm
-
Maximum Digging Depth:
-
2400mm
-
Machine Weight:
-
2000 kg
-
Max Digging Radius:
-
4050mm
-
Rated Speed:
-
2.8Km/h
-
Warranty of core components:
-
1year
-
Max. Dozer Cutting:
-
270mm
-
Max. Dozer Lifting:
-
240mm
-
Tail Swing Radius:
-
650mm
-
Dozer Blade:
-
1050*240mm
-
Traveling Tracking Force:
-
16kN
-
Bucket Digging Force:
-
20kN
-
Arm Digging Force:
-
11kN
-
Grade ability:
-
35°
-
Swing Speed:
-
0-9r/min
-
Boom Deflexion (Left/Right):
-
75/45
Product Description
|
Engine
|
|
|
|
Model
|
|
Kubota
|
|
Power
|
|
14.2kW/2200rpm
|
|
Emission standard
|
|
EURO V
|
|
Type
|
|
Direct injection, water cooled, natural intake
|
|
No. of cylinder
|
|
3
|
|
Operation Weight
|
kg
|
1950
|
|
Bucket Capacity
|
m3
|
0.07
|
|
Max. Digging Radius
|
mm
|
4050
|
|
Max. Digging Depth
|
mm
|
2400
|
|
Max. Digging Height
|
mm
|
3700
|
|
Max. Dumping Height
|
mm
|
2450
|
|
Max. Dozer Cutting
|
mm
|
270
|
|
Max. Dozer Lifting
|
mm
|
240
|
|
Boom Deflexion (Left/Right)
|
°
|
75/45
|
|
Tail Swing Radius
|
mm
|
650
|
|
Dozer Blade
|
mm
|
1050×240
|
|
Traveling Tracking Force
|
kN
|
16
|
|
Bucket Digging Force
|
kN
|
20
|
|
Arm Digging Force
|
kN
|
11
|
|
Traveling Speed
|
km/h
|
2.8
|
|
Grade ability
|
%
|
35°
|
|
Swing Speed
|
r/min
|
0-9
|
|
Overall Length
|
mm
|
3560
|
|
Overall Width
|
mm
|
990/1300
|
|
Overall Height
|
mm
|
2300
|
