Quick Details
-
Coil Number:
-
customize
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Baina
-
Model Number:
-
ER40-A07
-
Certification:
-
ROHS
-
Core material:
-
PC40/PC44/PC47/PC95/R5K/R10K/R15K
-
Bobbin material:
-
Bakelite/phenolic/plastics
-
Type:
-
Vertical
Quick Details
-
Usage:
-
High Frequency
-
Phase:
-
Single
-
Coil Structure:
-
TOROIDAL
-
Coil Number:
-
customize
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Baina
-
Model Number:
-
ER40-A07
-
Certification:
-
ROHS
-
Core material:
-
PC40/PC44/PC47/PC95/R5K/R10K/R15K
-
Bobbin material:
-
Bakelite/phenolic/plastics
-
Type:
-
Vertical
Specification:
1.Ferrit Core,high frequency.
2.Test condition:1KHz/0.25v,AC3750V, DC500V>200Oohm
3.Apply to Many Circuit design
Product Paramenters
|
Iteme No
|
Size(mm)
|
VA
|
|
N.W(g)
|
|
|
|
|
F=50KHz
|
F=100KHz
|
|
|
|
ER-28
|
28*34*30
|
42
|
58
|
35
|
|
|
ER-35
|
35*46*29
|
100
|
150
|
78
|
|
|
ER-40
|
40*47*32
|
180
|
290
|
110
|
|
|
ER-42
|
42*47*41
|
240
|
380
|
125
|
|
|
ER-49
|
49*58*53
|
650
|
1000
|
191
|
|
Product Description
|
item
|
value
|
|
Place of Origin
|
China
|
|
Brand Name
|
Baina
|
|
Model Number
|
ER40-A07
|
|
Usage
|
High Frequency
|
|
Phase
|
Single
|
|
Coil Structure
|
TOROIDAL
|
|
Coil Number
|
customize
|
|
Certification
|
CE UL ETL ISO
|
|
Output Power
|
0.5 to 5000 W
|
|
Working Temperature
|
-40 ℃ to + 125 ℃
|
|
Storage Temperature
|
-25 ℃ to + 85 ℃
|
|
Working Frequency
|
20KHz-500KHz
|
|
Frequency
|
50/60Hz
|
|
Voltage Parameter
|
Customized
|
