- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
heli
-
Fork Length:
-
1070mm
-
Fork Width:
-
125mm
-
Overall Dimensions:
-
2682*1225*2090mm
-
Weight (KG):
-
4240 kg
-
Product Name:
-
Diesel Forklift Truck
-
Name:
-
CPCD30
-
Loading Capacity:
-
3000kg
-
Color:
-
Yellow, red or custom
-
Mast:
-
2 stage mast or 3 stage mast
-
Seat:
-
Toyota seat with safety belt
-
Brand:
-
Heli
-
Optional:
-
side shifter, fork positioner,Cab with A/C,paper roll clamp,bale clamp
-
After-sales Service Provided:
-
1 year
-
Lifting height:
-
3000MM and customizable
Quick Details
-
Min. Lifting Height:
-
2090mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
heli
-
Fork Length:
-
1070mm
-
Fork Width:
-
125mm
-
Overall Dimensions:
-
2682*1225*2090mm
-
Weight (KG):
-
4240 kg
-
Product Name:
-
Diesel Forklift Truck
-
Name:
-
CPCD30
-
Loading Capacity:
-
3000kg
-
Color:
-
Yellow, red or custom
-
Mast:
-
2 stage mast or 3 stage mast
-
Seat:
-
Toyota seat with safety belt
-
Brand:
-
Heli
-
Optional:
-
side shifter, fork positioner,Cab with A/C,paper roll clamp,bale clamp
-
After-sales Service Provided:
-
1 year
-
Lifting height:
-
3000MM and customizable
Product Description
We are professional in forklift
Specification
|
|
|
|
|
|
CPCD30He
|
CPCD35He
|
|||
|
features
|
Power type
|
|
|
|
diesel
|
diesel
|
|||
|
|
Rated cut-off load
|
|
|
kg
|
3000
|
3500
|
|||
|
|
Load center distance
|
|
|
mm
|
500
|
500
|
|||
|
|
Lifting height
|
|
|
mm
|
3000
|
3000
|
|||
|
|
Free lifting height
|
|
|
mm
|
150
|
65
|
|||
|
|
Fork size
|
long*wide*thick
|
|
mm
|
1070x125×45
|
1070x125×50
|
|||
|
|
Gantry inclination
|
Front / rear
|
|
|
8/10
|
|
|||
|
|
Min turning radius
|
|
|
mm
|
2550
|
2570
|
|||
|
|
Min right angle stacking channel width
|
|
|
mm
|
4025
|
4045
|
|||
|
|
Min right angle channel width
|
|
|
mm
|
2750
|
2770
|
|||
|
|
Min ground clearance
|
|
|
mm
|
140
|
|
|||
|
|
Height of roof protection frame
|
|
|
mm
|
2090
|
|
|||
|
|
Seat to roof frame height
|
|
|
mm
|
1000
|
|
|||
|
|
Front overhang distance
|
|
|
mm
|
475
|
485
|
|||
|
size
|
overall length
|
No fork
|
|
mm
|
2765
|
2810
|
|||
|
|
Full width
|
|
|
mm
|
1230
|
|
|||
|
|
Max lifting height of fork (blocked shelf)
|
|
|
mm
|
4260
|
|
|||
|
|
Standard gantry height
|
|
|
mm
|
2075
|
|
|||
|
power
|
tyre
|
front wheel
|
|
|
28×9-15-14PR
|
|
|||
|
|
|
rear wheel
|
|
|
6.50-10-10PR
|
|
|||
|
|
wheelbase
|
|
|
mm
|
1760
|
|
|||
|
|
Track width
|
Front / rear
|
|
mm
|
1000
|
970
|
|||
|
|
dead weight
|
No load
|
|
kg
|
4280
|
4700
|
|||
|
|
lithium battery
|
Voltage
|
|
v
|
80V/115V/156V
|
|
|||
|
|
|
capacity
|
The max climbing capacity is 15%
|
Ah
|
220Ah
|
270Ah ( 10% )
|
|||
|
|
|
|
The max climbing capacity is 20%
|
|
/
|
/
|
|||
|
|
electric machinery
|
walk
|
|
kw
|
16.6
|
|
|||
|
|
|
Lifting
|
|
Kw
|
13.5
|
|
|||
|
|
control mode
|
|
|
|
AC
|
|
|||
|
|
working pressure
|
|
|
Mpa
|
18.5
|
|
|||
|
|
Traction
|
|
|
KN
|
18
|
19
|
|||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
