Quick Details
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
22500 kg
-
Drive Wheel:
-
4x4
-
After-sales Service Provided:
-
Online support
-
Brand Name:
-
DALI
-
Place of Origin:
-
Shandong, China
-
Engine Brand:
-
VOLVO
-
Gear Box Brand:
-
DANA
-
Forward Shift Number:
-
4
-
Dimensions (L x W x H) (mm):
-
9000X2380X2480 mm
-
Cargo Tank Dimension:
-
10 m 3
-
Engine Model:
-
VOLVO TAD853VE
-
Output:
-
235kw @ 2200rpm
-
Inlet form:
-
Turbocharged
-
Cooling method:
-
Water-cooling
-
Front axle(Unladen):
-
13500 kg
-
Rear axle(Unladen):
-
9000 kg
-
Front axle(laden):
-
19400 kg
-
Rear axle(laden):
-
23100 kg
-
Payload:
-
20ton
-
Application:
-
Underground Mining
Quick Details
-
Condition:
-
New
-
Horsepower:
-
451 - 500hp
-
Emission Standard:
-
EU III, US T3
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
22500 kg
-
Drive Wheel:
-
4x4
-
After-sales Service Provided:
-
Online support
-
Brand Name:
-
DALI
-
Place of Origin:
-
Shandong, China
-
Engine Brand:
-
VOLVO
-
Gear Box Brand:
-
DANA
-
Forward Shift Number:
-
4
-
Dimensions (L x W x H) (mm):
-
9000X2380X2480 mm
-
Cargo Tank Dimension:
-
10 m 3
-
Engine Model:
-
VOLVO TAD853VE
-
Output:
-
235kw @ 2200rpm
-
Inlet form:
-
Turbocharged
-
Cooling method:
-
Water-cooling
-
Front axle(Unladen):
-
13500 kg
-
Rear axle(Unladen):
-
9000 kg
-
Front axle(laden):
-
19400 kg
-
Rear axle(laden):
-
23100 kg
-
Payload:
-
20ton
-
Application:
-
Underground Mining
Product Description
|
Tramming capacity
|
20000 kg
|
Weight, empty
|
Operation Weight
|
22500 kg
|
|
Dump box volume
|
10 m3
|
|
Front axle
|
13500 kg
|
|
Overall Size
|
9000X2380X2480 mm
|
|
Rear axle
|
9000 kg
|
|
Box Lift Height
|
4480 mm
|
Weight, Loaded
|
Fully Loaded Weight
|
42500 kg
|
|
Wheelbase
|
4618 mm
|
|
Front axle
|
19400 kg
|
|
Min. ground clearance
|
300 mm
|
|
Rear axle
|
23100 kg
|
|
Turning radius
|
5400 / 8100 mm
|
Optional engine
|
|
QSL-8.9-C300 242kw
|
|
Turning angle
|
45°
|
|
DEUTZ
|
BF6M1013FC 223kw
|
|
Dump angle
|
65°
|
|
BENZ
|
OM926 240kw
|
|
Diesel engine
|
VOLVO TAD853VE
|
Converter
|
Brand
|
DANA
|
|
Output
|
235kw @ 2200rpm
|
|
Model
|
C5000 series
|
|
Max. Torque
|
1310 Nm @ 1200rpm
|
Transmission
|
Brand
|
DANA
|
|
Displacement
|
7.7 L
|
|
Model
|
RT36000
|
|
Emission norms
|
EU III, US T3
|
Axle
|
Model
|
KESSLER D81
|
|
Air filter
|
Dry type, two stage
|
|
Type
|
Rigid planetary axle
|
|
Purifier
|
Catalytic purifier with muffler
|
|
Differential
|
Standard
|
|
Electric system
|
24v
|
|
Front axle
|
spring applied hydraulic
operated rakes. Fixed. |
|
Cooling system
|
Water cooling
|
|
Rear axle
|
spring applied hydraulic
operated brakes. Oscillating ± 8° |
|
Number of cylinders
|
in-line 6
|
|
Tire
|
16.00-25 PR32 L-5S TT
|
|
Method of operation
|
4-stroke, direct injection with intercooler
|
Dump Box Motion Time
|
Discharging time
|
≤13.2s
|
|
Fuel tank refill capacity
|
350L
|
|
Box lowering time
|
≤12s
|
