Quick Details
-
Nature:
-
IPTV Live Streaming H.265 IPTV Encoder
-
Video Inputs:
-
one channel HD MI/SDI for option
-
Output:
-
4 groups TS over IP stream out
-
IP Protocol ouput:
-
RTMP/RTSP/HTTP/UDP/HLS
-
Video Encoding:
-
H.265/H.264 Main Profile/High Profile and MP3 & AAC audio compression
-
Audio Encoding:
-
AAC, MP3
-
Resolution:
-
Up to 1080P Full HD
-
Bitrate:
-
VBR/CBR
-
Configuration Interface::
-
Web operation
-
Bitrate mode:
-
CBR/VBR 16Kbit/s~12Mbit/s
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
DIGICAST
-
Model Number:
-
DMB-8900A-EC(HD MI IN)
-
Nature:
-
IPTV Live Streaming H.265 IPTV Encoder
-
Video Inputs:
-
one channel HD MI/SDI for option
-
Output:
-
4 groups TS over IP stream out
-
IP Protocol ouput:
-
RTMP/RTSP/HTTP/UDP/HLS
-
Video Encoding:
-
H.265/H.264 Main Profile/High Profile and MP3 & AAC audio compression
-
Audio Encoding:
-
AAC, MP3
-
Resolution:
-
Up to 1080P Full HD
-
Bitrate:
-
VBR/CBR
-
Configuration Interface::
-
Web operation
-
Bitrate mode:
-
CBR/VBR 16Kbit/s~12Mbit/s
FEATURES
*Video Input: one Channel HDM I
*Video Compression: HD H.264/MPEG-4 AVC
*Audio compression: AAC,AAC+,AAC++,MP3,MP2,
Dolby Digital AC-3
*All protocols (HLS, RTMP, HTTP, RTSP, UDP) can be working simultaneously
*Support output 2 groups TS over IP streams with 2 different resolutions and 2 different bitrates by each HDMI channel input
*Having 8*HDMI embedded audio input
*Support RTMP User name and Pass word for authentication of IPTV Server
*Capable of OSD settings for logo, text and Scroll Caption; Adjustable of audio gain;
*Support H.264 Baseline Profile/Main Profile/High Profile and MP3 & AAC audio compression
*Bitrate mode: CBR/VBR
*Capable of image parameter settings
*Configurable of Multi-Screen, Multi-Protocol, Low bitrate with high quality image.
*Any iOS browsers (iPhone, iPad, MacBook etc.) can have streams from IPTV Streaming Encoder in Anytime, Anywhere by HLS protocol without install any software players.
*Any terminal devices/decoders can have streams from IPTV Streaming Encoder directly by RTMP protocol with software players (such as VLC).
*Support HDCP protocol
*Support ONVIF Network Video Protocol
*Support multiple equipment display at the same time on a computer
*System supports WINDOWS XP/VISTA/SERVER2003/SERVER2008/ WIN7 32 and WIN7 64, LINUX
*Web-based management
*Full-duplex mode 1000M
|
SPECIFICATIONS
|
|
|
|
VIDEO SPECIFICATIONS
|
Video compression: H.264/AVC High/Main/Baseline Profile Level 4.0
Video input: 1*HDMI (HDCP compatible)
Resolution:
HDMl main stream: 1920x1080, 1680x1056, 1280x720, 1024x576, 850x480, 720x576, 720x540, 720x480, 720x404,704x576, 640x480, 640x360, auto HDMl sub-stream: 1280x720, 800X450, 720x576, 720x540, 720x480, 720x404, 704x576, 640x480, 640x300, 352X288, 320X240, 320X180 auto Bit-rate: 16kbps~12Mbps, CBR/VBR Video pre-processing: Noise reduction, Sharpen, Filtering |
|
|
AUDIO SPECIFICATIONS
|
Audio compression: AAC,AAC+,AAC++,MP3,MP2,
Dolby Digital AC-3
Audio input: 1*HD embedded Sampling accuracy: 24-bit Bit Rate: 48kbps~320kbps Sample-rate: 44.1KHz, 48KHz |
|
|
OUTPUTS
|
Transport protocol:TS over IP output, HLS, RTSP, HTTP, UDP and RTMP protocol
For 1* HDMI to IP output, supporting output 4 groups TS over IP streams (for each group the HLS, HTTP, RTSP, UDP and RTMP protocol all enabled).
Connector: RJ45, 1000M
|
|
|
