three way remote control electrical motor automatic wireless water shut off brass ball valve DN20 DN25

three way remote control electrical motor automatic wireless water shut off brass ball valve DN20 DN25

FOB Reference Price: Get Latest Price

≥2 Pieces

US $46

Free Inquiry

Customized Request

Explore More Products

brass water shut off valve

$ 0.7 - $ 1.38

Wholesale Price Forged Water System Brass Gate Red Hand Wheel Water Hose Shutoff Valve Shut Off Tool

$ 1.08 - $ 2.18

Blue Wheel Ppr Brass Pipe Pe Shut Off Valve Spool Lift Valve Switch Water Shut Off Tool

$ 0.7 - $ 1.38

Wholesale Lift Ppr Water Hose Thickened Brass Shut Off Copper Core Stop Valve

$ 0.7 - $ 1.38

Hot Sale Ppr Concealed Brass Core Chrome Plate Stop Cockgarden Hose Shut Off Valve

$ 0.7 - $ 1.38

High Quality Pipe Saddle Clamp Pe Pp Fittings Garden Brass Hose Valve Shut Off For Drip Pipe

$ 0.7 - $ 1.38

Wholesale Brass Core Garden Hose Attachment Hose Stop Faucet Valve Shut Off

$ 0.7 - $ 1.38

Wholesale 90 Degree Brass Gas Ball Valve

Brass Butterfly Gas Pipe Switch Valve Inner Thread Outer Thread Ball Valve Y Three Way Ball Valve

$ 0.7 - $ 1.38

Product Details

{{item.text}}

Quick Details

Brand Name:: Taike

Standard or Nonstandard:: Standard

Type:: Normal Closed Solenoid Valve, BALL VALVES

Certificate:: CE Approved

Working pressure:: PN20/16

Voltage:: AC24, AC110V, AC220V ± 10%, 50 / 60HZ

Size:: 1/2" or 3/4" or 1''

Material:: Forged brass body

Electrical specifications:: AC110V/220V DC12V/DC24V

Temperature:: -10-150℃

Quick Details

Port Size:: 1/2" or 3/4" or 1''

Place of Origin:: Liaoning, China

Model Number:: SR203

Brand Name:: Taike

Standard or Nonstandard:: Standard

Type:: Normal Closed Solenoid Valve, BALL VALVES

Certificate:: CE Approved

Working pressure:: PN20/16

Voltage:: AC24, AC110V, AC220V ± 10%, 50 / 60HZ

Size:: 1/2" or 3/4" or 1''

Material:: Forged brass body

Electrical specifications:: AC110V/220V DC12V/DC24V

Temperature:: -10-150℃

Product Description

Power adapter: DC12V 1A Remote control distance: 100 meters in the open (There are wall obstacles or electromagnetic wave interference will affect the distance) Use: Each time the opening time is not less than one minute (Automatically reset and close the valve in case of power failure)

OPEN

A and B are connected, C is closed

CLOSE

C and B are connected, A is closed

Switch speed 10 seconds to complete the action, built-in limit switch When the switch is in place, the internal power is automatically cut off, and the power consumption is 6W during the switching process

Motor type: synchronous motor	Valve body pressure: PN16
Lead wire length: 250MM	Temperature: -10-+150 ℃
Action time: 7 /10 seconds	Drive torque: 6N.M
Connection: Female thread	Power consumption: 6 watts 50/60HZ
Closing pressure difference: ≤0.6Mpa	Applicable medium: cold and hot water or 50% ethanol solution
Electrical specifications: (50/60HZ) AC220V AC 24V DV12V DC24V

Installation Instructions

Three-lines two control：

One common wire is opened, and the other is closed;
The power cord is a live wire (positive) and a neutral wire (negative)
The two-color line common line is connected to the neutral line (negative)
The live wire (positive) is connected to the blue valve opening wire to open the valve,
The live wire (positive) is connected to the brown valve-off wire to close the valve.
The switching time is 15 seconds for alternating current and 8 seconds for direct current.
It adopts synchronous motor, built-in current position contact switch, and automatically power off after fully open or fully
closed.

Three-Lines one control:(normally closed type)

Three-Lines one control:(normally closed type)
A live wire, a neutral wire, and an open valve wire!
When the valve opening line is connected to the live line, it will open, and if it is not connected, it will be closed.
Switch action time: AC power is 15 seconds (three wires and one control without DC power)
It adopts synchronous motor, built-in current position contact switch, and automatically power off after fully open or fully
closed.
