- Product Details
- {{item.text}}
Quick Details
-
CaO Content (%):
-
/
-
CrO Content (%):
-
/
-
SiC Content (%):
-
/
-
Place of Origin:
-
Henan, China
-
Model Number:
-
SK34
-
Brand Name:
-
KERUI
-
Fe2O3:
-
≤2%
-
Apparent Porosity:
-
≤20-22%
-
Cold Crushing Strength:
-
≥30MPa
-
Refractoriness(SK):
-
≥30
-
Refractoriness underload,0.2Mpa,℃:
-
≥1250
-
Bulk Density,g/cm3:
-
≥1.9-2.0
Quick Details
-
SiO2 Content (%):
-
/
-
Al2O3 Content (%):
-
≥38%
-
MgO Content (%):
-
/
-
CaO Content (%):
-
/
-
CrO Content (%):
-
/
-
SiC Content (%):
-
/
-
Place of Origin:
-
Henan, China
-
Model Number:
-
SK34
-
Brand Name:
-
KERUI
-
Fe2O3:
-
≤2%
-
Apparent Porosity:
-
≤20-22%
-
Cold Crushing Strength:
-
≥30MPa
-
Refractoriness(SK):
-
≥30
-
Refractoriness underload,0.2Mpa,℃:
-
≥1250
-
Bulk Density,g/cm3:
-
≥1.9-2.0
Fire Clay Bricks
Content introduction
Clay bricks are small man-made blocks used in construction. Also known as sintered brick. Solid clay brick is one of the oldest building materials in the world. From the Mausoleum of the First Emperor of Qin in Shaanxi Province to the Great Wall of Ming and Qing Dynasties in Beijing, it has inherited the architectural civilization of the Chinese nation for thousands of years. Today, it is still the favorite building material of Chinese people.
Sort
According to the hole rate: solid brick (no hole or hole rate is less than 25% of the brick), porous brick (hole rate is equal to or greater than 25%), the size of the hole is small and the number of bricks, often used for bearing parts, strength grade is higher. Hollow brick (a brick with a hole rate equal to or greater than 40%, a large hole size and a small number of holes, often used in non-load-bearing parts, and a low strength grade).
Peculiarity
Solid brick and porous brick are mostly used for load-bearing structure walls, hollow brick is mostly used for non-load-bearing structure walls.
Carbon Roaster
Carbon baking furnace is a kind of furnace used in the domestic carbon industry. The main function of carbon baking furnace is to indirectly heat the raw electrode, carbon block, chemical anode and other carbon products under the condition of isolating air according to the specified roasting temperature, so that the roasting temperature is indirectly heated, and the mechanical strength, electrical conductivity and thermal resistance of the carbon products after roasting are greatly improved.
Clay bricks, also known as sintered bricks, are man-made small blocks used in construction. Clay bricks take clay (including shale, coal gangue and other powder) as the main raw material, and are made by mud treatment, molding, drying and roasting, with solid and hollow respectively.
|
Item/Grade
|
|
SK-30
|
SK-32
|
SK-34
|
SK-35
|
|
|
Al2O3, %
|
≥
|
30
|
35
|
38
|
45
|
|
|
Fe2O3, %
|
≤
|
2.5
|
2.5
|
2
|
2
|
|
|
Refractoriness (SK)
|
≥
|
30
|
32
|
34
|
35
|
|
|
Refractoriness underload, 0.2MPa, °C
|
≥
|
1250
|
1300
|
1360
|
1420
|
|
|
Apparent Porosity, %
|
≤
|
22-26
|
20-24
|
20-22
|
18-20
|
|
|
Bulk Density, g/cm³
|
≥
|
1.9-2.0
|
1.95-2.1
|
2.1-2.2
|
2.15-2.22
|
|
|
Cold Crushing Strength, MPa
|
≥
|
40
|
45
|
30
|
40
|
|
High Temperature Stability
KERUI The refractory resistance is the highest among general refractory bricks, usually above 2000
℃
.
Resistance To Corrosion
Which is important in industrial environments with harsh chemicals and gases.
Strong Slag Resistance
Kerui Refractory because of its good chemical structure ,it has super slag resistance and can resist slag ,metal melt, furnace dust and sinter surface.
Customized
Kerui refractory bricks can be shaped and customized to suit various furnace configurations, offering flexibility and adaptability in challenging industrial settings.
Introduction Of Advantages
Clay brick is made of clay (including shale, coal gangue and other powder) as the main raw material, through mud treatment, molding, drying and roasting. The size of ordinary brick is 240 mm ×115 mm ×53 mm, according to the size of compressive strength (Newton/square mm, N/mm2) is divided into MU30, MU25, MU20, MU15, MU10, MU7.5 these six strength grades.
The Al2O3 content of clay bricks in China is generally more than 40%, and the Fe2O3 content is less than 2.0 ~ 2.5%. The clinker is 65 ~ 85% and the combined clay is 35 ~ 15%. The pulverized bonded clay is mixed with the fine clinker, and then the granular clinker is prepared into semi-dry mud, which is formed under high pressure and fired at about 1400℃. Clay brick is weakly acidic at high temperature, and its ability to resist alkaline slag erosion is slightly poor, but it is enhanced with the increase of Al2O3 content. The thermal stability is better than that of silicon brick and magnesium brick (see magnesium brick).
The phosphoric acid impregnated product of qualified BF clay bricks after drying treatment and secondary low temperature firing is used for laying the lining of BF furnace body.
