Quick Details
-
Model Number:
-
LCSSR-3DA
-
Product name:
-
Solid State Relay
-
Control Voltage:
-
3-32VDC
-
Load Voltage:
-
24~480VAC
-
Load Current:
-
40A
-
Control:
-
DC to AC
-
Max Input Current:
-
40mA
-
Peak Voltage:
-
800V
-
Operation Temperature:
-
-30℃ to 80℃
Quick Details
-
Contact Load:
-
High Power
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LCTC
-
Model Number:
-
LCSSR-3DA
-
Product name:
-
Solid State Relay
-
Control Voltage:
-
3-32VDC
-
Load Voltage:
-
24~480VAC
-
Load Current:
-
40A
-
Control:
-
DC to AC
-
Max Input Current:
-
40mA
-
Peak Voltage:
-
800V
-
Operation Temperature:
-
-30℃ to 80℃
Product Description
3 phase 3-32VDC to 24-480VACHigh Power SSR 40A Three-phaseb DC to AC Solid State Relay
Features
1.MOSFET output.
2.With LED indicator.
3.Low on-state resistance.
4.Photo isoation.
Precautions
1.Must add suppression circuit for inductive load. 2.Apply heat-radiation silicon grease of a heat conductive sheet between the SSR and heat sink. 3.Tighten the ssr terminal screws properly. 4.Please do not use the relay beyond the descriptions in the data sheet.
1.Must add suppression circuit for inductive load. 2.Apply heat-radiation silicon grease of a heat conductive sheet between the SSR and heat sink. 3.Tighten the ssr terminal screws properly. 4.Please do not use the relay beyond the descriptions in the data sheet.
Choose current
Current of Equipment/Ratio = Current of SSR
PS: The Ratio depend on the kind of your loading equipment.
Resistive load :50%, Inductive load:20%,Capacitive load：10%.
|
Model
|
LCDH480-3DA
|
|
Control
|
DC to AC
|
|
Load Current
|
10A 25A 40A 60A 80A 100A 120A 150A 200A
|
|
Control Voltage
|
3-32VDC
|
|
Max Input Current
|
40mA
|
|
Must Operation Voltage
|
3VDC
|
|
Must Release Voltage
|
2VDC
|
|
Output Voltage
|
24-480VAC
|
|
Peak Voltage
|
800V
|
|
Operation Temperature
|
-30℃ to 80℃
|
|
Max off-state leakage current
|
2mA
|
|
Max on-state voltage drop
|
1.5V
|
|
Dielectric strength
|
2500V
|
|
Certificates
|
CE
|
