Made from highly galvanized steel sheets in order to assure highest strength and strong resistance to corrosion.the frame material
also can customized: Aluminized zinc,Stainless steel.
- Product Details
- {{item.text}}
Quick Details
-
After-sales Service Provided:
-
Online support
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Rfan
-
Model Number:
-
swung drop hammer exhaust fan
-
Voltage:
-
380V/220V/Customized, 380V/220V/Customized
-
Frame Material:
-
Stainless Steel/galvanized sheet/Aluminized zinc
-
Motor:
-
Siemens Motor/Chinese famous motor
-
Phase:
-
3 phase /single phase
-
Belt:
-
Japanese Mitsuboshi brand
-
Frequency:
-
50HZ
-
Blades Diameter:
-
1400mm/1270mm/1100mm/1000mm/900mm etc.
-
Outline Size:
-
1530mm,1380mm,1220mm,1100mm,1000mm Customized
-
color:
-
silvery
Quick Details
-
Applicable Industries:
-
Building Material Shops, Manufacturing Plant, Farms, poultry house, greenhouse, industry, textile industry, ventilation
-
Electric Current Type:
-
AC
-
Mounting:
-
Wall Fan
-
After-sales Service Provided:
-
Online support
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Rfan
-
Model Number:
-
swung drop hammer exhaust fan
-
Voltage:
-
380V/220V/Customized, 380V/220V/Customized
-
Frame Material:
-
Stainless Steel/galvanized sheet/Aluminized zinc
-
Motor:
-
Siemens Motor/Chinese famous motor
-
Phase:
-
3 phase /single phase
-
Belt:
-
Japanese Mitsuboshi brand
-
Frequency:
-
50HZ
-
Blades Diameter:
-
1400mm/1270mm/1100mm/1000mm/900mm etc.
-
Outline Size:
-
1530mm,1380mm,1220mm,1100mm,1000mm Customized
-
color:
-
silvery
WHY CHOOSE US
1、PRICE ADVANTAGE:
FACTORY-DIRECT BOTTOM PRICE, ALSO GOOD MANAGEMENT AND EFFICENCYTO CONTROL THE PRODUCTION COST.
2、QUALITY CONTROL:
QUALITY IS SUPERVISED AND CONTROLLEDIN EVERY PROCESS PF PRODUCTION AND CAN PASS THE TEST.
3、PROMPT DELIVERY:
STRONG AND STABLE PRODUCTIONCAPACITY WITH YEAR OF 300 CONTAINERS ENSURE THE TIME OF DELIVERY.
4、EXPORT EXPERIENCE:
RICH PRODUCTION EXPERIENCE ENABLEUS TO HANDLE ANY PROBLEM HAPPENED IN THE PROCESS OF PRODUCTION.
Product Description
|
Model
|
Drive
|
Blades Diameter
(mm)
|
Input Power
(W)
|
Voltage
|
Motor Rotational Speed(rpm)
|
Air Flow (m³/h)
|
Noise (db)
|
|
RF-600B
|
Direct
|
450(18")
|
370
|
380V/220V/50HZ
|
1350
|
7380
|
<60
|
|
RF-620B
|
Direct
|
500(20")
|
370
|
380V/220V/50HZ
|
1350
|
9960
|
<70
|
|
RF-800B
|
Belt
|
710(28")
|
370
|
380V/220V/50HZ
|
1350
|
22000
|
<60
|
|
RF-900B
|
Belt
|
750(30")
|
550
|
380V/220V/50HZ
|
1400
|
28000
|
<65
|
|
RF-1000B
|
Belt
|
900(36")
|
550
|
380V/220V/50HZ
|
1400
|
30000
|
<70
|
|
RF-1100B
|
Belt
|
1000(40")
|
750
|
380V/220V/50HZ
|
1400
|
32500
|
<70
|
|
RF-1220B
|
Belt
|
1100(43")
|
750
|
380V/220V/50HZ
|
1400
|
38000
|
<70
|
|
RF-1380B
|
Belt
|
1250(50")
|
1100
|
380V/220V/50HZ
|
1400
|
44000
|
<75
|
|
RF-1530B
|
Belt
|
1400(55")
|
1500
|
380V/220V/50HZ
|
1400
|
55800
|
<70
|
|
Model
|
Blades Rotational Speed
(rpm)
|
Total pressure
(Pa)
|
Height
(mm)
|
width
(mm)
|
Thickness
(mm)
|
|
RF-600B
|
1350
|
60
|
600
|
600
|
370
|
|
RF-620B
|
1350
|
60
|
620
|
620
|
370
|
|
RF-800B
|
546
|
60
|
800
|
800
|
400
|
|
RF-900B
|
566
|
65
|
900
|
900
|
400
|
|
RF-1000B
|
566
|
62
|
1000
|
1000
|
400
|
|
RF-1100B
|
488
|
70
|
1100
|
1100
|
400
|
|
RF-1220B
|
395
|
73
|
1220
|
1220
|
400
|
|
RF-1380B
|
418
|
56
|
1380
|
1380
|
400
|
|
RF-1530B
|
418
|
60
|
1530
|
1530
|
400
|
Details Images
Fan Frame:
Blades:
Fan blades is made of stainless steel by punch forming,no dust,attractive and durable.Special blades shape design ensure large air volume,no deformation ,no broken,keep air volume same all the way.Thickness 1.2mm,surface finish BA grade.
6pieces stainless steel blades and the fan has all passed the experiment of homeostasis with big air volume,low noise.
100% Pure Copper Motor .
Motor have Siemens and Chinese famous brand motor,all are 100% Pure Copper Motor .Motor voltage and frequency can be customized.
Chinese famous brand motor has open phase protection device,When the lack of power,can carry out their own power to control;Motor
protection grade IP55,insulation class:F.
Chinese famous brand motor has open phase protection device,When the lack of power,can carry out their own power to control;Motor
protection grade IP55,insulation class:F.
Belt:
Use imported belts,making sure long service life,free to maintain.
Pulley and Impeller:
Pulley is made of high strength aluminum-magnesium alloy by die-casting which reduces the weight of blade impeller complete,high
corrosion resistance. Special three reinforced ribs pulley design.Blast sanding treatment for attractive appearance,eliminate
internal stress to improve its own rigidity and stablity.
corrosion resistance. Special three reinforced ribs pulley design.Blast sanding treatment for attractive appearance,eliminate
internal stress to improve its own rigidity and stablity.
Drop hammer:
Using high strength nylon drop hammer opening device,shutters opening and closing flexible stabilization.
