Quick Details
-
power phase number:
-
Single-phase to three-phase
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
VFDDRIVE
-
Model Number:
-
KE300A-12
-
Warranty:
-
12 months
-
Type:
-
Frequency Inverter
-
Rated Output Current:
-
17A-32A
-
Display:
-
LED, LCD optional
-
Frequency:
-
0-600HZ
-
Product name:
-
VFD AC DRIVE
-
Application:
-
Motor Speed Control
-
Condition:
-
100%new
-
Package:
-
Standard Package
-
SHIPPING:
-
DHL FEDEX TNT UPS
-
PAYMENT:
-
TT\Western Union\ Trade Assurance\ Paypal
-
Protection:
-
IP 20
-
Certification:
-
ce
Quick Details
-
Control Mode:
-
vector control
-
Rated Power:
-
0.75kw-110kw
-
Nominal Voltage:
-
220v to 380v
-
power phase number:
-
Single-phase to three-phase
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
VFDDRIVE
-
Model Number:
-
KE300A-12
-
Warranty:
-
12 months
-
Type:
-
Frequency Inverter
-
Rated Output Current:
-
17A-32A
-
Display:
-
LED, LCD optional
-
Frequency:
-
0-600HZ
-
Product name:
-
VFD AC DRIVE
-
Application:
-
Motor Speed Control
-
Condition:
-
100%new
-
Package:
-
Standard Package
-
SHIPPING:
-
DHL FEDEX TNT UPS
-
PAYMENT:
-
TT\Western Union\ Trade Assurance\ Paypal
-
Protection:
-
IP 20
-
Certification:
-
ce
Why choose us ?
1. We offer the mos
t
cost-effective price.
1. We provide you with the most complete technical support and plan the overall scheme.
2. Strictly Control the whole production process and guarantee punctual delivery, Test each of our products one by one before packing to ensure the quality.
3. Supply you a good pre-sale, in-sale and after-sale Service. We're not just working partners, but a
lso Friends and Family.
Products Description
Function introduction of boost frequency converter
1, single-phase to three-phase phase transformation function, 220v to 380v boost function, frequency conversion function;
2. It has most functions of general frequency converter, such as soft start function (reducing starting current and impact on power grid, which can replace soft starter), speed regulation function (stepless adjustment from 0 to rated motor speed), positive and negative switching function of terminal start and stop (controlling motor start, stop, positive and negative rotation through external switch, which can replace AC contactor), etc.
3. It has motor protection function, overcurrent, overload, overvoltage, overheating and short circuit protection, etc., which effectively prolongs the service life of the equipment.
|
Item
|
Technical Index
|
Specification
|
|
Input
|
Input voltage
|
1AC/3AC 220V±15%, 3AC 380V±15%, 3AC 660V±15%
|
|
|
Input frequency
|
47~63Hz
|
|
Output
|
Output voltage
|
0～rated input voltage
|
|
|
Output frequency
|
V/f control: 0~3000Hz
Sensorless vector control: 0~300Hz |
|
Control Features
|
Control mode
|
V/f control
Sensorless vector control Torque control |
|
|
Operation command mode
|
Keypad control
Terminal control Serial communication control |
|
|
Frequency setting mode
|
Digital setting, analog setting, pulse frequency setting, serial communication setting, multi-step speed setting & simple PLC, PID
setting, etc. These frequency settings can be combined & switched in various modes. |
|
|
Overload capacity
|
G model: 150% 60s, 180% 10s, 200% 3s
P model: 120% 60s, 150% 10s, 180% 3s |
|
|
Starting torque
|
0.5Hz/150% (SVC); 1Hz/150% (V/f)
|
|
|
Speed adjustment range
|
1:100 (SVC), 1:50 (V/f)
|
|
|
Speed control precision
|
±0.5% (SVC)
|
|
|
Carrier frequency
|
1.0--16.0kHz, automatically adjusted according to temperature and load characteristics
|
|
|
Frequency accuracy
|
Digital setting: 0.01Hz
Analog setting: maximum frequency * 0.05% |
|
|
Torque boost
|
Automatically torque boost; manually torque boost: 0.1%~30.0%
|
|
|
V/f curve
|
Three types: linear, multiple point and square type (1.2 power, 1.4 power, 1.6 power, 1.8 power, square)
|
|
|
Acceleration/deceleration mode
|
Straight line/S curve; four kinds of acceleration/deceleration time, range: 0.1s~3600.0s
|
|
|
DC braking
|
DC braking when starting and stopping
DC braking frequency: 0.0Hz~maximum frequency, braking time: 0.0s~100.0s |
|
|
Jog operation
|
Jog operation frequency: 0.0Hz~maximum frequency
Jog acceleration/deceleration time: 0.1s~3600.0s |
|
|
Simple PLC & multi-step speed operation
|
It can realize a maximum of 16 segments speed running via the built-in PLC or control terminal.
|
|
|
Built-in PID
|
Built-in PID control to easily realize the close loop control of the process parameters (such as pressure, temperature, flow,
etc.) |
|
|
Automatic voltage regulation
|
Keep output voltage constant automatically when input voltage fluctuating
|
|
Control Function
|
Common DC bus
|
Common DC bus for several inverters, energy balanced automatically
|
|
|
Torque control
|
Torque control without PG
|
|
|
Torque limit
|
“Rooter” characteristics, limit the torque automatically and prevent frequent over-current tripping during the running process
|
|
|
Wobble frequency control
|
Multiple triangular-wave frequency control, special for textile
|
|
|
Timing/length/counting control
|
Timing/length/counting control function
|
|
|
Over-voltage & over-current stall control
|
Limit current & voltage automatically during the running process, prevent frequent over-current & over-voltage tripping
|
|
|
Fault protection function
|
Up to 30 fault protections including over-current, over-voltage, under-voltage, overheating, default phase, overload, shortcut,
etc., can record the detailed running status during failure & has fault automatic reset function |
|
Input/output terminals
|
Input terminals
|
Programmable DI: 7 on-off inputs, 1 high-speed pulse input
2 programmable AI: AI1: 0～10V or 0/4～20mA A12: 0～10V or 0/4～20mA |
|
|
Output terminals
|
1 programmable open collector output: 1 analog output (open collector output or high-speed pulse output)
2 relay output 2 analog output: 0/4~20mA or 0~10V |
|
|
Communication terminals
|
Offer RS485 communication interface, support MODBUS-RTU communication protocol
|
|
Human machine interface
|
LED display
|
Display frequency setting, output frequency, output voltage, output current, etc.
|
|
|
Multifunction key
|
QUICK/JOG key, can be used as multifunction key
|
|
Environ-ment
|
Ambient temperature
|
-10℃～40℃, derated 4% when the temperature rise by every 1℃ (40℃～50℃).
|
|
|
Humidity
|
90%RH or less (non-condensing)
|
|
|
Altitude
|
≤1000M: output rated power, ＞1000M: output derated
|
|
|
Storage temperature
|
-20℃～60℃
|
Keypad.
1.Simple Operation
2. With Digital Display
3.panel desmontable
Control Board.
1.Low Frequency with High Torque
2.Automatic Voltage Regulation
PCB Board.
1.Aging Resistance
2.Acid & Alkali Resistance
3.Automatic painting with better quality
Fan.
1.
Powerful cooling fan system
2.
low noise
3.
Dust- proof
Capacitors .
1.Capacitors from EPCOS of Germany which are
2.world famous capacitor manufacturers
Independent air duct.
1.Adapt to all kinds of complex and harsh field environments.
Application scenarios
fan，water puump，sewage teratment and other loads can be selected with the same power
Heavy loads such as injection molding machines,crushers, mixers, ball mills, rolling mills, winches, wire drawing machines, flat knitting machines,transport vehicles, Roots blowers, feeders, etc,need to increase the power by 1-2 gears.
If you have any questions, please click here to contact customer service.
More Products
Customer Photos
Our Factory
Exhibition
Order flow
FAQ
Q1. what's the payment term?
A1.We accept T/T, L/C, D/P, WEST UNION, PAYPAL, CASH,OA
Q2. What is the standard of package?
A1、Below 70kw, it's carton package
A2、90kw and above,it's wooden package.
Q3. Do you accept OEM business?
A1.We accept OEM with your authorization.
Q4.How is the after-sale service?
A1. We offer spare parts accordingly and English-speaking engineer offer online service.
Q5. What’s voltage range and power range can support?
A1、voltage range：Single-phase and Three-phase 220v input, three-phase 220v output;Single-phase 380v input, three-phase 380v output;
A2、 power range：0.75kw to 630kw
Q6.Do you support urgent orders?
A1. Sure. We have an ERP management system. Once there is an inventory warning,
A2. we will prepare materials in advance to meet the urgent needs of customers
Q7.How to ensure product quality?
A1. Our production strictly follow ISO9001 quality control system and CE certification.
