Quick Details
-
Brand Name:
-
ZERUN
-
Model Number:
-
PF-eu
-
Item:
-
Palisade Fence
-
Material:
-
Iron
-
Application:
-
Garden,garage.Home,Factory,park,schoo letc
-
Color:
-
Black/green/yellow etc
-
Certification:
-
ISO9001
-
Surface treatment:
-
Galvanized+PVC Coated Powder Coated
-
Packing:
-
Plastic film and pallet
-
Product name:
-
Galvanized Palisade Guard High Security Fence & Gates
-
Height:
-
1.5-3m
Quick Details
-
Frame Material:
-
Metal
-
Feature:
-
Easily Assembled, Sustainable, ECO FRIENDLY, FSC, Pressure Treated Timbers, Renewable Sources, Rodent Proof, Rot Proof, Tempered Glass, TFT, Waterproof
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
ZERUN
-
Model Number:
-
PF-eu
-
Item:
-
Palisade Fence
-
Material:
-
Iron
-
Application:
-
Garden,garage.Home,Factory,park,schoo letc
-
Color:
-
Black/green/yellow etc
-
Certification:
-
ISO9001
-
Surface treatment:
-
Galvanized+PVC Coated Powder Coated
-
Packing:
-
Plastic film and pallet
-
Product name:
-
Galvanized Palisade Guard High Security Fence & Gates
-
Height:
-
1.5-3m
Galvanized Palisade Guard High Security Fence & Gates
DESCRIPTION OF PALISADE FENCE
Palisade Fence widely accepted as the industry leader to protect and deter general attack from all types and
conditions of intrusion.The pales are made of hot formed and cold rolled steel belts.These belts offer both
strength and rigidity combined with a long life span. Palisade normally produce three types of pales,
"W" profile, "D" profile and angle iron
.
PALE TYPE OF PALISADE FENCE
D section pales.
Working with long bolts, are designed for boundary delineation requiring low to medium security and damage resistance.
W section pales.
with higher inherent strength and better vandal resistance, are the most used type to provide effective high security and extra protection. Fastened by short bolts, the W type palisade pales are flush against the horizon rails without flexibility.
Angle steel pales.
Bolted or welded to horizon fence rails, are suitable for general purpose applications, such as residential estates protection.
SPECIFICATIONS OF PALISADE FENCE
Pales-"W" section
Most useful vertical type of pales for palisade fencing, which is always the customers' first choice for
pales .
|
Width |
Thickness |
Surface Treatment |
Head |
Height |
|
68mm
|
2.0mm
|
Galvanized and Electrostatic polyester coated or Hot dipped galvanized |
Single point
|
1200mm---3000mm |
Pales-"D" section
Compared with "W" profile pales, "D" profile is more economical.
|
Width |
Thickness |
Surface Treatment |
Head |
Height |
|
60mm |
2.0mm
|
Galvanized and Electrostatic polyester coated or Hot dipped galvanized |
Single point
|
1200mm---3000mm |
Pale-Angle iron
Its cost is similar with "D" profile ,but its structure is simpler than "D" profile.
|
Width |
Thickness |
Surface Treatment |
Head |
Height |
|
40x40 |
2.0mm
|
Galvanized and Electrostatic polyester coated or Hot dipped galvanized |
Single point |
1200mm--3000mm |
Post- IPE Type
As a connection pipe between the fence panels, IPE type is the most useful way.
|
Size |
Thickness |
Surface Treatment |
Head |
Height |
|
100x55mm
|
3.5mm
|
Galvanized and
or Hot dipped galvanized |
Cut sharp |
On the fence height basis |
Rail- Angle Iron
It is the connection between pales and IPE post, which make the fence as a whole panel.
|
Size |
Thickness |
Surface Treatment |
Holes |
Length |
|
50x50
|
5.0mm
|
Galvanized and
or Hot dipped galvanized |
With19 holes drilled on one edge side |
2710mm |
DRAWING AND INSTALLATION
Colour of Palisade Fence
Customized is available
APPLICATION OF PALISADE FENCE
*Apartment buildings protection solutions;
*Industrial facilities protection solutions;
*Telecom & Mobile tower base station protection solutions;
*The airport port & harbor protection solutions;
*Roads and railways protection solutions;
*The border protection solutions;
*Prison protection solutions.
BENEFITS OF PALISADE FENCE
Deter and Delay
The Palisade fence system presents an architecturally-pleasing security barrier design that deters potential attacks with pale designs to discourage scaling, and delays intrusion with highstrength steel construction designed to withstand impact.
Fast Installation
Because of its unique rail support, this security fence can be installed in as little as half the time required of conventional systems that are set between posts.
Security Integration
This barrier solution can be integrated with Intrusion Detection and other electronic security components, protecting cabling through a raceway of steel rails within the framework of the Palisade Fence System.
Long Service Life
High-quality galvanized steel is coated with our exclusive superdurable, Architectural Grade Powder Coating, providing the industry’s longest-lasting protection.
