Quick Details
-
Dimension(L*W*H):
-
1569*1114*1327 MM
-
Weight (KG):
-
320 kg
-
Product name:
-
Road Sweeper
-
Function:
-
Sweeping Road
-
Key word:
-
Automatic Floor Cleaning Machine
-
Certification:
-
ISO
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
Relion craftsman
-
Power:
-
800
-
Dimension(L*W*H):
-
1569*1114*1327 MM
-
Weight (KG):
-
320 kg
-
Product name:
-
Road Sweeper
-
Function:
-
Sweeping Road
-
Key word:
-
Automatic Floor Cleaning Machine
-
Certification:
-
ISO
Product Description
Spare Parts Technical Features：
1.
Leakage protector
Effectively protect the motor from overloading, enhance the equipment life, and have an open design for easy observation.
2.Kelly controller
Using automotive grade Feienkar CPU, advanced MOSFET electronic components, passisng IATF16949 automotive quality system certification and enhancing equipment's stable operation and endurance.
3.Anti-dust cover
Integrated stamping dust cover with galvanized anti-rust treatment. Efficient dust prection, preventing corrosion from external harmful substance, and extending bearing service life
4.Standard dimensions
Standard elevator size design for easily accessing to multi floor workshops.
Features：
★
Compact design, flexible operation
★
High power drive motor to increase the climbing capacity.
★
Unique vacuum filtration system to make better dust absorption effect
★
Sturdy and durable big size tires for strong climbing obstacle ability
★
75L large capacity dustbin, no need to dump dust frequently.
★
Hydraulic double disc brake system for safer parking and driving
★
Easy to drive over speed bumps
|
MODEL NO.
|
RS1100
|
BATTERY CAPACITY
|
48 V / 50 AH
|
|
CLEANING WIDTH
|
1100 MM
|
TRACTION MOTOR
|
48V/800W
|
|
MAIN BRUSH
|
490*300 MM
|
MAIN BRUSH MOTOR
|
48V/650W
|
|
WORKING EFFICIENCY
|
0-6600 M²/H
|
SIDE BRUSH MOTOR
|
48V/2*90W
|
|
FORWARD SPEED
|
0-6 KM/H
|
VIBRATION MOTOR
|
48V/120W
|
|
SOLUTION TANK
|
60 L
|
VACUUM MOTOR
|
48V/95W
|
|
DUSTBIN CAPACITY
|
75 L
|
WEIGHT
|
320 KG
|
|
SIDE BRUSH
|
2*460 MM
|
MACHINE SIZE
|
1569*1114*1327 MM
|
|
BATTERY
|
LEAD-ACID /LITHIUM
|
MINIMUM TURNING RADIUS
|
260 MM
|
