Quick Details
-
Measurement range:
-
30A: 0~20mΩ 50A: 0~10mΩ 80A: 0~8mΩ 100A : 0~5mΩ
-
Accuracy:
-
± (Reading *0.5%+1uΩ)
-
Resolution:
-
0.1uΩ
-
Display digital:
-
4 1/2 digital
-
Test power supply:
-
Constant current limit, about 2V
-
Input voltage:
-
Max. 5V
-
Test time:
-
Quickly , 10s-60s optional
-
Battery capacity:
-
7.5AH power lithium battery
-
Measurement time:
-
More than 600 times (rechargeable, fast measurement mode)
Quick Details
-
Power:
-
Electronic
-
Place of Origin:
-
Hubei, China
-
Test Current:
-
30A, 50A, 80A, 100A
-
Measurement range:
-
30A: 0~20mΩ 50A: 0~10mΩ 80A: 0~8mΩ 100A : 0~5mΩ
-
Accuracy:
-
± (Reading *0.5%+1uΩ)
-
Resolution:
-
0.1uΩ
-
Display digital:
-
4 1/2 digital
-
Test power supply:
-
Constant current limit, about 2V
-
Input voltage:
-
Max. 5V
-
Test time:
-
Quickly , 10s-60s optional
-
Battery capacity:
-
7.5AH power lithium battery
-
Measurement time:
-
More than 600 times (rechargeable, fast measurement mode)
1. Lithium battery power supply, can be tested more than 600 times after a single charge, the test process is simple and convenient.
2. The output current is up to 100A, multiple currents are available, and the test range is wide.
3. The longest test time can reach 60 seconds at 100A , to meet various applications on site.
4. Wide range and high precision, up to 5mΩ at 100A.
5. It has perfect protection functions such as open circuit protection and overheat protection.
6. 5.6-inch large industrial-grade high-brightness color LCD screen, the display is still clearly visible under strong sunlight.
7. Optional external printer for easy data printing.
8. With local storage and USB storage for easy data storage.
