Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ONPOW
-
Model Number:
-
PS165P10YSS1
-
Material:
-
stainless steel
-
Operation type:
-
Momentary
-
Function:
-
1NO
-
Terminal type:
-
two wires
-
Head shape:
-
Flat Actuator
-
Mounting hole diameter:
-
16mm
-
Type:
-
piezo switch touch switch
-
Voltage:
-
24V
-
Proof level:
-
IP68
-
Certificate:
-
CE ROHS
-
Certification:
-
-CE ROHS
Quick Details
-
Protection Level:
-
IP68
-
Max. Current:
-
1A
-
Max. Voltage:
-
24V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ONPOW
-
Model Number:
-
PS165P10YSS1
-
Material:
-
stainless steel
-
Operation type:
-
Momentary
-
Function:
-
1NO
-
Terminal type:
-
two wires
-
Head shape:
-
Flat Actuator
-
Mounting hole diameter:
-
16mm
-
Type:
-
piezo switch touch switch
-
Voltage:
-
24V
-
Proof level:
-
IP68
-
Certificate:
-
CE ROHS
-
Certification:
-
-CE ROHS
Most professional manufacturer in China push button market! Keep leading and keep best reputation since 1988!
Part number: PS165P10YSS1
Install diameter:16mm
Switch rating: 2A/24V
Shape: Flat head
Function: Momentary (1NO)
Voltage:1.8V~24V
Terminal:wires
IP rating: IP68
Temperature: - 40 to 75 Degree
Crust material: Stainless steel
Professional manufacture for 30years (CE, ROHS) 16mm 1NO1NC power symbol light through stainless steel push button switch
|
Model Description |
|
|
Part number: |
PS165P10YSS1 |
|
Mounting Cut-out |
16mm +0.2/+0.0 mm |
|
Head shape |
Flat Head |
|
Switch Combination |
1NO |
|
Operation type |
Momentary (Latching can be choose) |
|
Illuminated type |
illuminated can be choose |
|
Illuminated color |
|
|
Lamp voltage |
24V (Other voltage can be choose) |
|
Body and Actuator material |
Aluminum (Stainless steel can be choose) |
|
Approval |
CE,CCC,Rohs,Reach,IP68 |
Packing: switches with high flat button
1. Neutral packing : 20 pcs/box, 25boxes/carton
2. Upon customers' request, but the price is different with neutral packing
3. Carton size: 30*50*35 cm
Shipping: switches with high flat button
1. DHL,TNT, FEDEX, UPS and other international express.
2. By air or by sea.
