Model
|
SHP50DI
|
SHP80DI
|
SHP100DI
|
||
|
Type
|
Self-priming centrifugal pump
|
|
|
||
|
Suction*delivery (mm) (inch)
|
50*50/2*2
|
80*80/3*3
|
100*100/4*4
|
||
|
Total Head (m)
|
85
|
75
|
55
|
||
|
Suction Head (m)
|
6
|
6
|
6
|
||
|
Max delivery volume (m3 /h)
|
35
|
42
|
120
|
||
|
Mechanical seal
|
Ceramic Carbon
|
|
|
||
|
Engine model
|
S178F(E)
|
S186F(E)
|
S192FA(E)
|
||
|
Fuel tank capacity (L)
|
3.5
|
5.5
|
5.5
|
||
|
Starting system
|
Manual Start /electric start
|
|
|
||
|
Packing size (L*W*H) mm
|
580*490*570
|
580*490*630
|
580*490*635
|
||
|
Net weight (KG)
|
32
|
46
|
64
|
||
