- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Hebei, China
-
Machine Weight:
-
5000 kg
-
Marketing Type:
-
New Product 2023
-
Item:
-
articulated wheel loader
-
Color:
-
Color Customized
-
Keyword:
-
Wheel loader
-
Drive type:
-
4x4 4x2Wheel Drive
-
Certification:
-
CE EPA
-
Brand:
-
HUAYA
-
Drive:
-
4*4 4*2Wheel Drive
-
Load capacity:
-
1-7ton
-
Transmission Type:
-
Hydrostatic Automatic 4WD
-
Name:
-
Backhoe Loader
Quick Details
-
Engine Brand:
-
YUNNEI
-
Power:
-
75 KW, 60 KW, 55 kw
-
Brand Name:
-
HUAYA
-
Place of Origin:
-
Hebei, China
-
Machine Weight:
-
5000 kg
-
Marketing Type:
-
New Product 2023
-
Item:
-
articulated wheel loader
-
Color:
-
Color Customized
-
Keyword:
-
Wheel loader
-
Drive type:
-
4x4 4x2Wheel Drive
-
Certification:
-
CE EPA
-
Brand:
-
HUAYA
-
Drive:
-
4*4 4*2Wheel Drive
-
Load capacity:
-
1-7ton
-
Transmission Type:
-
Hydrostatic Automatic 4WD
-
Name:
-
Backhoe Loader
Product Description
Attachments
Specification
Overall Dimension
|
6800x1900x2960mm
|
Operate weight
|
4200kg
|
Bucket width
|
1700mm
|
Bucket capacity
|
0.7m³
|
Dig bucket capacity
|
0.1m³
|
Max. dumping height
|
2800mm
|
Max. digging depth
|
2000mm
|
Dumping distance
|
1050mm
|
Model
|
YUNNEI engine
|
Rated power
|
42KW
|
Drive model
|
Four wheel drive
|
Overall Dimension
|
7600x2330x2960mm
|
Operate weight
|
5000kg
|
Bucket width
|
1800mm
|
Bucket capacity
|
0.8m³
|
Dig bucket capacity
|
0.15m³
|
Max. dumping height
|
2700mm
|
Max. digging depth
|
2500mm
|
Model
|
YUNNEI YN27 turbocharged engine
|
Rated power
|
58KW
|
Pattern
|
In-line, water-cooling, 4 cylinder, direct inject
|
Storage Battery
|
80 A free-maintenance
|
Optional
|
YANMAR/Kohler EPA4 engine
|
Gearbox model
|
Hydraulic torque converter
|
Overall Operating Weight
|
5500KG
|
Length×width×height
|
6950x2200x3100mm
|
Min. Ground Clearance
|
300mm
|
Bucket Capacity
|
1m3
|
Loading Lifting Capacity
|
2000KG
|
Bucket Dumping Height
|
3300mm
|
Backhoe Capacity(Width)
|
0.2m3
|
Max. Digging Depth
|
2700mm
|
Model
|
YUNNEI YN33GBZ Turbo
|
Rated Power
|
65KW
|
Length x Width x Height
|
7,800 x 2,250 x 3,300MM
|
Wheel Base
|
2,250MM
|
Track
|
1,640MM
|
Min. Ground Clearance
|
300MM
|
Total Weight
|
6,300KG
|
Maximum Speed
|
22Km/h
|
Bucket Discharge Height
|
3,500MM
|
Loading Bucket Capacit
|
1CBM
|
Model
|
Yunnei turbocharged engine
|
Engine Power
|
76KW
|
Total operating weight
|
7500Kg
|
Length*width*height(mm)
|
7600×2250×2900mm
|
Wheel base
|
2250mm
|
Minimum ground clearance
|
300m
|
Loading bucket capacity
|
1.m³
|
Digging up capacity
|
38KN
|
Loading lift capacity
|
2500Kg
|
Bucket discharge height
|
2742mm
|
Bucket discharge distance
|
1062mm
|
Model
|
YUCHAI YCD4T22T-105 turbo engine
|
Type
|
Inline,direct injection,our-stroke,liquid cooled
|
Length x Width x Height
|
8,000 x 2,300 x 3,250MM
|
Wheel Base
|
2,250MM
|
Track
|
1,640MM
|
Min. Ground Clearance
|
300MM
|
Total Weight
|
6800KG
|
Maximum Speed
|
25Km/h
|
Loading Capacity
|
2,800KG
|
Model
|
Yuchai turbocharged engine
|
Engine Power
|
85KW
|
Bucket Dump Height
|
3800MM
|
Length×width×height
|
8000×2200×2900mm
|
Wheel base
|
2250mm
|
Min. Ground Clearance
|
300mm
|
Bucket Capacity
|
1.5m3
|
Breakout Force
|
38KN
|
Loading Lifting Capacity
|
2800KG
|
Bucket Dumping Height
|
2800mm
|
Digging Depth
|
52mm
|
Max. Digging Depth
|
4100mm
|
Model
|
DONGFENG CUMMIS
|
Rated Power
|
92KW
|
