Quick Details
-
Drilling Diameter:
-
1500m
-
Drilling Depth:
-
Max.56m
-
Rated output torque:
-
155kN.m
-
Lifting capacity:
-
160kN
-
Rotary speed:
-
5-35rpm
Quick Details
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
18300*3140*3265 mm
-
Weight:
-
48000 KG
-
Drilling Diameter:
-
1500m
-
Drilling Depth:
-
Max.56m
-
Rated output torque:
-
155kN.m
-
Lifting capacity:
-
160kN
-
Rotary speed:
-
5-35rpm
Contact Way
Factory price borehole driller YCR50 Piling Rotary drilling rig machine
Product Overview
Rotary Drilling Rig YCR50
Efficient and flexible
Widely used in small dia. & deep borehole construction in civil engineering, high main hoist lifting up and down speed, high
verticality of finished borehole, high working efficiency in civil construction.
Economical and energy-saving
Imported large-displacement E.FI engine with strong power, adopts power optimization control technology, adjusts power
distribution in real time, fast response speed, higher fuel efficiency and more energy-saving
High reliability
Efficient and flexible
Widely used in small dia. & deep borehole construction in civil engineering, high main hoist lifting up and down speed, high
verticality of finished borehole, high working efficiency in civil construction.
Special chassis
Telescopic large widening chassis designed for rotary drilling rig, roller type large diameter slewing bearing to guarantee the high stability in deep borehole construction.
Telescopic large widening chassis designed for rotary drilling rig, roller type large diameter slewing bearing to guarantee the high stability in deep borehole construction.
Economical and energy-saving
Imported large-displacement E.FI engine with strong power, adopts power optimization control technology, adjusts power
distribution in real time, fast response speed, higher fuel efficiency and more energy-saving
High reliability
The mast adopts box structure with strong resistance to torsion and fatigue; sixth generation kelly bar adopting upgraded material and strengthened block ring, the overall strength increased by 25% with high drilling ability in strongly weathered rock layer.
Intelligent upgrade
10-inch HD touch screen, fast response and more convenient operation.
10-inch HD touch screen, fast response and more convenient operation.
Product Paramenters
|
MODEL
|
YCR50
|
|
Max. pile Diameter(mm)
|
1200
|
|
Max. pile Depth(m)
|
23
|
|
Max.output torque(kN m)
|
50
|
|
Speed of rotationrpm
|
6-35
|
|
Engine model
|
B3.9
|
|
Rated power (kw/rpm)
|
86/2200
|
|
Working pressure(Mpa)
|
34
|
|
Diameter of the steel wire rope(mm)
|
16
|
|
The length of crawler (mm)
|
4310
|
|
Track shoe width(mm)
|
600
|
|
Operating weight (t)
|
18.2
|
|
Transport Dimensions (LxWxH/mm)
|
9950x2600x3480
|
