Quick Details
-
Name:
-
Container swimming pool
-
Style:
-
Luxary
-
Color:
-
Customized Color
-
Advantage1:
-
move
-
Advantage2:
-
perspective
-
Advantage3:
-
leisure time
-
Advantage4:
-
Trendy
-
Advantage5:
-
hygiene
-
Advantage6:
-
comfortable
Quick Details
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
WSZ
-
Product Type:
-
Swimming pool
-
Name:
-
Container swimming pool
-
Style:
-
Luxary
-
Color:
-
Customized Color
-
Advantage1:
-
move
-
Advantage2:
-
perspective
-
Advantage3:
-
leisure time
-
Advantage4:
-
Trendy
-
Advantage5:
-
hygiene
-
Advantage6:
-
comfortable
Product Description
System 1:
Galvanized steel structure welding (keel + column + square tube + steel shim + exterior
waves steel sheet, Steel plate liner) + PU insulation + painting; WPC trim boards
waves steel sheet, Steel plate liner) + PU insulation + painting; WPC trim boards
Steel sheet painting liner Detailed structure
1. Steelsheet painting liner 2.Bottom keel 3.Water return holes 4. Exteriorwall Keel 5. Wood plastic floor 6.Overflow hole 7. Water inlet 8.Skimmer 9.Zinc plated wave steel sheet 10.Zinc plated steel Column 11.160U steel 12.Container corner steel
System 2:
Galvanized steel structure welding (keel + column + square tube + steel shim + exterior
waves steel sheet, inner fiberglass liner) + PU insulation + painting; WPC trim boards
waves steel sheet, inner fiberglass liner) + PU insulation + painting; WPC trim boards
Fiberglass liner Detailed structure
1. Fiberglass liner 2.Pool Lights 3.Water return holes 4. Exterior wall Keel 5. Wood plastic floor 6.Overflow hole 7.Water inlet 8.Skimmer 9.Zinc plated wave steel sheet 10.Zinc plated steel Column 11.160U steel 12.PU insulation
Swimming pool operation process
Swimming pool accessories
Swimming pool application
Swimming pool design parameters
|
No.
|
Design parameter item
|
parameter specification
|
|
1
|
The water volume(m³)
|
17m3(20ft)
|
|
2
|
cycle time(h)
|
1h
|
|
3
|
circular flow(m³/h)
|
17m3/h
|
|
4
|
Sand cylinder filter speed(m³/h)
|
V650 17m3/h *1
|
|
5
|
filtering medium
|
silica sand
|
|
6
|
filtration rate
|
intermediate speed
|
|
7
|
Design filter speed (m³/h)
|
17m3/h
|
|
8
|
Design pressure of circulation line
|
0.4Mpa
|
|
9
|
Vertical load bearing design
|
2.5T/m2
|
Other problems in the swimming pool
|
Project
|
Detailed description
|
|
Product name
|
Container swimming pool
|
|
Product mix
|
Steel structure + Steel sheet painting liner or Fiberglass liner
|
|
Product use
|
Campsites, scenic spots, markets, amusement parks, diving training, swimming teaching, product exhibitions,
large-scale outdoor, indoor and outdoor swimming equipment and facilities |
|
Product features
|
Some shallow and deep water areas in the swimming pool are suitable for adults and children to play and study.
|
|
Specifications (external dimensions)1
|
It is 5.8m long, 2.2m wide, 1.8m, 2.0m ,2.2mand 2.5m high
|
|
Specifications (external dimensions)2
|
It is 11.8M long, 2.2m wide, 1.8m, 2.0m ,2.2mand 2.5m high
|
|
Standard configuration
|
Ultra-silent circulating pump,Filter (polymer finish),Filter material: Quartz sand,Circuit control system,Water inlet and outlet Material:PVC,Pipeline system.
|
|
Optional configuration
|
Window, Pool Ladder, Water Lamp, Salt Chlorinator, Dosing Pumps Chlorine Feeder, Manuel Cleaning Tools, Pool Cover and Reel,
Electric-air energy heater, Swimming pool surfing equipment. |
