* High-transmittance and low reflection
* Inspection:GB15763.2-2005.ISO9050
* High solar transmittance
* High mechanical strength
* High flatness
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
25 Years, 25 years
-
Brand Name:
-
AS Solar
-
Model Number:
-
ASZH54L 395-415M
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1724*1134*35mm
-
Material:
-
Monocrystaline Silicon
-
Cell Type:
-
Mono Solar Cell 182mm
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP 68,3 diodes
-
Glass:
-
3.2mm, High Transmission, AR Coated Tempered Glass
-
Connector:
-
MC 4 Compatible Connector
-
Cable:
-
4 mm² ,350 mm (With Connectors)
-
Packaging:
-
31pcs
-
Keyword:
-
Pv Module
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell
-
Panel Efficiency:
-
21.23%
-
Warranty:
-
25 Years, 25 years
-
Brand Name:
-
AS Solar
-
Model Number:
-
ASZH54L 395-415M
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1724*1134*35mm
-
Material:
-
Monocrystaline Silicon
-
Cell Type:
-
Mono Solar Cell 182mm
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP 68,3 diodes
-
Glass:
-
3.2mm, High Transmission, AR Coated Tempered Glass
-
Connector:
-
MC 4 Compatible Connector
-
Cable:
-
4 mm² ,350 mm (With Connectors)
-
Packaging:
-
31pcs
-
Keyword:
-
Pv Module
Products Description
Excellent Cells Efficiency
Our solar panels use MBB technology to reduce 1/2 of the original current and the power dissipation is reduced to 1/4 of the original’s.
Excellent load capacity
Our solar panels are extremely adaptable to harsh outdoor environments and resistant to
harsh environments such as salt, ammonia, sand, high temperatures and high humidity environments.
harsh environments such as salt, ammonia, sand, high temperatures and high humidity environments.
Long durability
We adopt the most advanced full automatic production line to ensure long life of our solar modules.
High reliability
Our solar modules are guaranteed to have a positive tolerance of 0-3% to ensure the reliability of the power output and are backed by a 10-year limited product warranty and a 25-year limited power warranty.
Anti PID
To ensured PID resistance, our panels are subject to strict quality control in the selection of raw materials and in the
production process.
production process.
Solar Panel Glass
Solar Panel Cell
* High output-power: conversation efficiency is 18%-22%
* High shunt-resistance: adapt the several environmental conditions.
* Bypass diode minimizes the power drop by shade
* Excellent low light effect
* Low breakage rate
* High shunt-resistance: adapt the several environmental conditions.
* Bypass diode minimizes the power drop by shade
* Excellent low light effect
* Low breakage rate
Frame
* Aluminium extrusion profile with prompt delivery
* Available in customized surface finish
* Excellent material for smooth and subtle edges
* Extrusion for construction and other industrial purposes
* Thickness variable according special request
* Available in customized surface finish
* Excellent material for smooth and subtle edges
* Extrusion for construction and other industrial purposes
* Thickness variable according special request
Junction Box
* High current and voltage carrying capacity
* Simple, quick and safe effective field assembly
* IP 68 it can be used in the outdoor iron environment
* Expansion connector are available for future requirement
* Double permanent connection are adapted for all of the connecting.
* Simple, quick and safe effective field assembly
* IP 68 it can be used in the outdoor iron environment
* Expansion connector are available for future requirement
* Double permanent connection are adapted for all of the connecting.
Product Specifications
Electrical Specification(STC*)
|
Nominal Power Watt Pmax(W)*
|
395
|
400
|
405
|
410
|
415
|
|
Power Output Tolerance Pmax(%)
|
0~+3
|
0~+3
|
0~+3
|
0~+3
|
0~+3
|
|
Maximum Power Voltage Vmp(V)
|
30.70
|
30.90
|
31.10
|
31.30
|
31.50
|
|
Maximum Power Current Imp(A)
|
12.87
|
12.95
|
13.03
|
13.10
|
13.18
|
|
Open Circuit Voltage Voc(V)
|
36.90
|
37.10
|
37.30
|
37.50
|
37.70
|
|
Short Circuit Current Isc(A)
|
13.63
|
13.70
|
13.77
|
13.84
|
13.91
|
|
Module Efficiency (%)
|
20.20
|
20.46
|
20.72
|
20.97
|
21.23
|
*STC(Standard Test Condition): Irradiance 1000W/m², Module Temperature 25℃, AM 1.5
Electrical Specification(NOCT*)
|
Maximum Power Pmax(Wp)
|
295.20
|
299.00
|
302.70
|
306.30
|
310.10
|
|
Maximum Power Voltage Vmpp(V)
|
28.50
|
28.70
|
28.90
|
29.10
|
29.30
|
|
Maximum Power Current Impp(A)
|
10.35
|
10.41
|
10.47
|
10.53
|
10.59
|
|
Open Circuit Voltage Voc(V)
|
34.50
|
34.70
|
34.80
|
35.00
|
35.20
|
|
Short Circuit Current Isc(A)
|
11.01
|
11.06
|
11.12
|
11.18
|
11.23
|
*NMOT:Irradiance 800W/m²,Ambient Temperature 20℃,AM 1.5,Wind Speed 1m/s
Mechanical Specification:
|
Solar cells
|
Mono PERC
|
|
Cells orientation
|
108（6×18）
|
|
Module dimension
|
1724×1134×35mm (With Frame)
|
|
Weight
|
21±1 kg
|
|
Glass
|
3.2mm, High Transmission, AR Coated Tempered Glass
|
|
Junction box
|
IP 68，3 diodes
|
|
Cables
|
4 mm² ,350 mm (With Connectors)
|
|
Connectors*
|
MC4-compatible
|
Manufacturing Technique
Solar Cell String EL Testing
Each solar photovoltaic string must be tested by EL machine to ensure that each solar cell is perfect
EL Testing Before Lamination
Each solar module must be tested by EL machine before lamination to ensure that each solar string is perfect.
Appearance Inspection After Lamination
Each Solar Module must be inspected by QC after lamination to ensure there is no defect during lamination.
.
Final EL Testing
The final EL test 100% ensures that each solar module has zero internal electrical defects.
Output Power Testing
Output power testing ensures 100% positive power tolerance and excellent power performance.
Final Appearance Inspection
Each solar module must be inspected by the quality control department before packaging to ensure that there are no defects in the production process.
Product packaging
Packing Method: Customized Wooden&Carton with Pallet(offer 100% protection during transportation)
Project:
Certifications
FAQ
1. Who are we?
We are ANHUI SHANGXIA SOLAR ENERGY CO.,LTD,
2. How can we guarantee quality?
Always a most advanced fully automatic production;
Always a step by step Inspection system before shipment.
Always a step by step Inspection system before shipment.
3. What can you buy from us?
Poly and mono solar panels, solar batteries,solar power system, solar charger controller, solar inverters, etc..
4. Why should you buy from us not from other suppliers?
As a trustworthy and reliable supplier, our products have been exported to all over the world, including Australia, Africa,Russia, the Middle East, South America, Asia and so on!
5. What services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,Express Delivery;
Accepted Payment Currency: USD,EUR,HKD,CNY; etc
Accepted Payment Type: T/T,Cash
Accepted Payment Currency: USD,EUR,HKD,CNY; etc
Accepted Payment Type: T/T,Cash
