Quick Details
-
Brand Name:
-
FATO
-
Model Number:
-
FT-2520/150
-
External Size:
-
250mm*200mm*150mm
-
Material thickness:
-
1.2mm
Quick Details
-
Protection Level:
-
IP65
-
Type:
-
DISTRIBUTION BOX
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
FATO
-
Model Number:
-
FT-2520/150
-
External Size:
-
250mm*200mm*150mm
-
Material thickness:
-
1.2mm
|
External
Dimensions(mm) |
Enclosures | |||||
|
Height
(A) |
Width
(B) |
Depth
(C) |
Model | Figure |
Flange
Opening Type |
Approx
Weight (KG) |
| 250 | 200 | 150 | FT-2520/150 | 1 | O | 3.2 |
| 300 | 250 | 150 | FT-3025/150 | 1 | A | 4.2 |
| 300 | 250 | 200 | FT-3025/200 | 1 | A | 4.9 |
| 300 | 300 | 150 | FT-33/150 | 1 | B | 5 |
| 300 | 300 | 200 | FT-33/200 | 1 | B | 6 |
| 400 | 300 | 150 | FT-43/150 | 1 | B | 6 |
| 400 | 300 | 200 | FT-43/200 | 1 | B | 6.8 |
| 400 | 400 | 200 | FT-44/200 | 1 | C | 8 |
| 400 | 600 | 250 | FT-46/250 | 1 | D | 10 |
| 400 | 600 | 300 | FT-46/300 | 1 | D | 11.2 |
| 500 | 400 | 150 | FT-54/150 | 2 | B | 8.7 |
| 500 | 400 | 200 | FT-54/200 | 2 | C | 9.8 |
| 500 | 400 | 250 | FT-54/250 | 2 | C | 11 |
| 500 | 500 | 250 | FT-55/250 | 2 | D | 12.8 |
| 600 | 400 | 150 | FT-64/150 | 2 | B | 9.3 |
| 600 | 400 | 200 | FT-64/200 | 2 | C | 10.8 |
| 600 | 400 | 250 | FT-64/250 | 2 | C | 12.3 |
| 600 | 500 | 150 | FT-65/150 | 2 | B | 11.3 |
| 600 | 500 | 200 | FT-65/200 | 2 | D | 14.3 |
| 600 | 500 | 250 | FT-65/250 | 2 | D | 16.3 |
| 600 | 600 | 250 | FT-66/250 | 2 | D | 18.2 |
| 600 | 600 | 300 | FT-66/300 | 2 | D | 19.8 |
| 700 | 500 | 200 | FT-75/200 | 2 | D | 17.3 |
| 700 | 500 | 250 | FT-75/250 | 2 | D | 19.3 |
| 800 | 600 | 200 | FT-86/200 | 2 | D | 21.8 |
| 800 | 600 | 250 | FT-86/250 | 2 | D | 24.8 |
| 800 | 600 | 300 | FT-86/300 | 2 | D | 26.3 |
| 800 | 800 | 200 | FT-88/200 | 2 | E | 29.5 |
| 800 | 800 | 300 | FT-88/300 | 2 | E | 32.5 |
| 1000 | 600 | 250 | FT-106/250 | 3 | D | 28.4 |
| 1000 | 600 | 300 | FT-106/300 | 3 | D | 30.6 |
| 1000 | 800 | 250 | FT-108/250 | 3 | E | 34.5 |
| 1000 | 800 | 300 | FT-108/300 | 3 | E | 37.4 |
| 1000 | 1000 | 300 | FT-1010/300 | 4 | F | 46.7 |
| 1200 | 800 | 300 | FT-128/300 | 3 | F | 44.8 |
| 1200 | 1000 | 300 | FT-1210/300 | 4 | F | 53.4 |
