Quick Details
-
Brand Name:
-
ENXIY
-
Model Number:
-
ECM20
-
Work Time (h):
-
24
-
Max PV Power:
-
5200W
-
Max PV Voltage:
-
150V
-
Certificate:
-
CE
-
Warranty:
-
5 years
-
Rated Current:
-
10A/20A/30A/40A/50A/60A
-
MPPT efficiency:
-
99%
-
Display:
-
LCD Screen
-
Battery type:
-
GEL, SLD,FLD and USER(default),Lithium batteries
-
System Voltage:
-
12/24/36/48/Auto
-
OEM:
-
Accept OEM
-
Environmental temperature:
-
-20℃ ~ +55℃
-
Storage temperature:
-
-40℃ ~ +75℃
-
Feature:
-
High Efficiency Charging Method
-
Charge mode:
-
MPPT Charging
Quick Details
-
Type:
-
MPPT
-
Application:
-
Solar System Controller
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ENXIY
-
Model Number:
-
ECM20
-
Work Time (h):
-
24
-
Max PV Power:
-
5200W
-
Max PV Voltage:
-
150V
-
Certificate:
-
CE
-
Warranty:
-
5 years
-
Rated Current:
-
10A/20A/30A/40A/50A/60A
-
MPPT efficiency:
-
99%
-
Display:
-
LCD Screen
-
Battery type:
-
GEL, SLD,FLD and USER(default),Lithium batteries
-
System Voltage:
-
12/24/36/48/Auto
-
OEM:
-
Accept OEM
-
Environmental temperature:
-
-20℃ ~ +55℃
-
Storage temperature:
-
-40℃ ~ +75℃
-
Feature:
-
High Efficiency Charging Method
-
Charge mode:
-
MPPT Charging
|
|
I Charger MPPT 8048
|
|
I Charger MPPT 10048
|
|
|||
|
Charging mode
|
3-stage:Constant Current(MPPT),Constant Voltage,Floating
|
|
|
|
|||
|
System Voltage
|
12/24/36/48/Auto
|
|
|
|
|||
|
Max PV Input Power
|
1200W/12V;2400W/24V
3600W/36V;4800W/48V
|
|
1500W/12V; 3000W/24V
4500W/36V; 6000W/48V
|
|
|||
|
Max PV Input Voltage
|
150 Voc
|
|
|
|
|||
|
Battery voltage automatic recognition: 48V Battery
|
12V System(DC8.7V-DC15.5V)
24V System(DC16V -DC31V)
36V System(DC33V -DC41V)
48V System(DC42V -DC64V)
|
|
|
|
|||
|
Overcharging protection voltage: 48V Battery
|
12V System(16V)
24V System(32V)
36VSystem(48V)
48V System(64V)
|
|
|
|
|||
|
Limited current protection
|
80A/100A
|
|
|
|
|||
|
Max effiffifficiency
|
≥98.1%
|
|
|
|
|||
|
PV utilization
|
≥99%
|
|
|
|
|||
|
Temperature protection
|
80℃
|
|
|
|
|||
|
Fan-on temperature
|
>45℃
|
|
|
|
|||
|
Fan-offff temperature
|
<40℃
|
|
|
|
|||
|
Size (mm)
|
252*201*80.3
|
|
|
|
|||
|
Net weight(Kg)
|
2.28
|
|
2.49
|
|
|||
|
Electromagnetic compatibility
|
Accord to EN61000, EN55022, EN55024
|
|
|
|
|||
|
Enclosure
|
IP21
|
|
|
|
|||
|
Environmental temperature
|
-20℃~+55℃
|
|
|
|
|||
|
Storage temperature
|
-40℃~+75℃
|
|
|
|
|||
