Quick Details
-
Brake Distance:
-
≤5m
-
Travlled KM:
-
80-100km
Quick Details
-
Tire Size:
-
10/12/14 inch, 23*10.5-12 vacuum tires aluminum wheels
-
Dimension:
-
2900*1250*2050mm, 2900*1250*2050mm
-
Max speed:
-
35km/h
-
Brake Distance:
-
≤5m
-
Travlled KM:
-
80-100km
➤Product Paramenters
|
Model specifications
|
Model
|
TCKC2
|
TCKC22
|
TCKC4
|
TCKC42
|
TCKC6
|
TCKC62
|
TCKC8
|
TCKC82
|
|||||||
|
Technical parameters
|
Overall Dimension（L*W*H)
|
2500*1300*2000
|
2900*1300*2000
|
3200*1300*2000
|
3600*1300*2000
|
4000*1300*2000
|
4400*1300*2000
|
4800*1300*2000
|
5200*1300*2000
|
|||||||
|
|
Passengers Capacity
|
2
|
4
|
4
|
6
|
6
|
8
|
8
|
10
|
|||||||
|
|
Max.Speed(km/h)
|
30 or Negotiatable
|
|
|
|
|
|
|
|
|||||||
|
|
Max.Travelling Range(km)
|
80~100
|
|
|
|
|
|
|
|
|||||||
|
|
Slope Climbing Capacity
|
30%
|
|
|
|
|
|
|
|
|||||||
|
|
Turning Radius(m)
|
3.5
|
3.5
|
4.6
|
4.6
|
5.7
|
5.7
|
6.7
|
6.7
|
|||||||
|
|
Minimum Ground Clearance（mm)
|
150
|
|
|
|
|
|
|
|
|||||||
|
|
Brake Distance(m)
|
≤5m
|
|
|
|
|
|
|
|
|||||||
|
|
Wheelbase(mm)
|
1700
|
1700
|
2400
|
2400
|
3100
|
3100
|
3850
|
3850
|
|||||||
|
|
Front/Rear Tread(mm)
|
Front 900mm / Rear 1000mm
|
|
|
|
|
|
|
|
|||||||
|
|
Weight(kg)
|
530
|
560
|
600
|
620
|
680
|
710
|
800
|
830
|
|||||||
|
Electric system
|
Motor power (kw)
|
3.5/4/5kw or customized
|
|
|
|
|
|
|
|
|||||||
|
|
Electric Controller
|
Enpower Fully Intelligent Controller
|
|
|
|
|
|
|
|
|||||||
|
|
Battery type
|
6V 200AH /8V 150AH / 12V 100AH can choose
|
|
|
|
|
|
|
|
|||||||
|
|
Charger
|
Intelligent high-frequency car charger
|
|
|
|
|
|
|
|
|||||||
|
|
Charging time(h)
|
8~10
|
|
|
|
|
|
|
|
|||||||
|
|
Charging input voltage
|
220V/110V
|
|
|
|
|
|
|
|
|||||||
|
Chassis system
|
Suspension
|
Front Torsion Beam Suspension+Integral rear axle high strength steel plate spring cartridge or customized
|
|
|
|
|
|
|
|
|||||||
|
|
Brake system
|
Drum hydraulic brake, double-circuit hydraulic brake and parking brake device or customized
|
|
|
|
|
|
|
|
|||||||
|
|
Steering
|
"Rack&Pinoin"Steering
|
|
|
|
|
|
|
|
|||||||
|
|
Motion transfer system
|
Continuously variable transmission
|
|
|
|
|
|
|
|
|||||||
|
|
Drive mode
|
Rear drive
|
|
|
|
|
|
|
|
|||||||
|
Exterior
|
Dashboard
|
Multi-function smart display(Bluetooth-radio-movie etc.)
|
|
|
|
|
|
|
|
|||||||
|
|
Light
|
LED combined headlights,turn signals,combined rear taillights,brake lights and electric
|
|
|
|
|
|
|
|
|||||||
|
|
Seat
|
Joint row seats (leather fabric+high resilience PU seats)
|
|
|
|
|
|
|
|
|||||||
|
|
Body material
|
Steel frame+injection shell /ABS engineering plastic molded parts
|
|
|
|
|
|
|
|
|||||||
|
|
Wheel
|
10/12/14inch iron/aluminum wheels options
|
|
|
|
|
|
|
|
|||||||
|
|
Tire
|
Road and off-road tire options
|
|
|
|
|
|
|
|
|||||||
➤Our Advantages
1、Tongcai is located in the
largest
low-speed electric vehicle industry belt in northern China of Shandong province.
We understand product trends and better meet your requirements.
2、An independent product
design
department can provide you with timely, efficient and high-quality services.
3、A professional sales team can provide
7*24
hours
service. We also have an independent documentation department that can update your shipping information in a timely manner and assist you with customs clearance.
4、Professional
QC
team performs full-process quality control. We always believe that what we sell is not products, but responsibility and trust.
5、
1 year
warranty
for the major parts, 5 years warranty for lithium battery,
Provide spare parts for free,during the warranty period.
6、
In case of major situations, we can provide professional online guidance to solve problems. If it's necessary, we can send our team to local place.
➤OEM/ODM
➢
➢
➢
Show Some Details
Any Color Customization
Seat Options
Customizable Battery
Optional Suspension
Customizable Wheels
Customizable Motor
Customizable Dashboard
➢➣
➢
Other Customization Options
➤Packing&Delivery
