Quick Details
-
Type:
-
Grinder/Crusher/Milling
-
Voltage:
-
220v/380v
-
Power:
-
5.5-7.5kw
-
Weight:
-
150 KG
-
Dimension(L*W*H):
-
950*720*1500mm
-
Function:
-
Apple Grinder Machine
-
Capacity:
-
500-1500 kg/h
-
Speed:
-
1450r/min
-
Grinding disc diameter:
-
400mm
-
Cutter number:
-
24pcs
-
Flange with Cutter gap:
-
0.5mm-5mm (adjustable)
Quick Details
-
Marketing Type:
-
Hot Product
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Longer
-
Type:
-
Grinder/Crusher/Milling
-
Voltage:
-
220v/380v
-
Power:
-
5.5-7.5kw
-
Weight:
-
150 KG
-
Dimension(L*W*H):
-
950*720*1500mm
-
Function:
-
Apple Grinder Machine
-
Capacity:
-
500-1500 kg/h
-
Speed:
-
1450r/min
-
Grinding disc diameter:
-
400mm
-
Cutter number:
-
24pcs
-
Flange with Cutter gap:
-
0.5mm-5mm (adjustable)
Apple/Pears/Pineapple/Plum/Carrot Meat Grinder/Crusher/Milling Machine
Introduction:
The device absorbs many customers experience and absorb the Italian advanced equipment, well-developed, is a highly efficient grind equipment. It grind with high efficiency, stable performance, long life, low noise, easy operation and maintenance, etc., can significant reduction in production costs.
The device is widely applicable to a variety of berries (example: strawberries, tomatoes, blueberries, mulberries, etc.), pome fruit (example: apples, pears, crab, etc.), vegetables (carrots, turnips) and enucleated after stone (Example: peaches, apricots, plums, etc.), other shelled or peeled class (example: coconut, onion, ginger, pineapple, etc.) crushing grinding.
Works Principle:
After cleaning materials or peeled (shelled) by man or hoist feed material into hopper. The material in the high-speed rotation of the disc cutter feed platen, the material into the hopper along a fixed spiral downward extrusion at the same time get the tooth thickness cut, grind, and finally small particles from the fixed flange and disc cutter gap falling out. You can adjust the gap flange and disc cutter obtained optimum crushing fineness of grind and production capacity.
Main Technical Parameter:
|
Model Parameters |
LGJ-200 |
LGJ-400 |
LGJ-600 |
|
Capacity |
400-600kg/h |
500-1500 kg/h |
1000-3000 kg/h |
|
Power |
2.2-3KW |
5.5-7.5KW |
11-15KW |
|
Speed |
1450r/min |
1450r/min |
1450r/min |
|
Grinding disc diameter |
200mm |
400mm |
700mm |
|
Cutter number |
12pcs |
24pcs |
48pcs |
|
Flange with Cutter gap |
0.5mm-5mm (adjustable) |
||
|
Dimension |
700*500*1200mm |
950*720*1500mm |
1350*1050*1800mm |
