- Product Details
- {{item.text}}
Quick Details
-
Application:
-
custom
-
Type:
-
orignal
-
Series:
-
OEM
-
Features:
-
custom
-
Mounting Type:
-
Contract Sales
-
Description:
-
custom, Custom
-
Manufacturing Date Code:
-
custom
-
MOQ:
-
1pcs
-
Shipping time:
-
3~7Days
-
Applications:
-
PCB/PCBA/Other
-
Payment:
-
Flexible payment
-
Service:
-
One Stop BOM List Service
-
Solder mask:
-
Green. Red. Blue. White. Black.Yellow
-
Certificat:
-
IATF16949/ISO13485/ISO9001
-
Product name:
-
Electronic Components
-
Quality:
-
100% Oriqinal 100% Brand
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Customized
-
Model Number:
-
Customized
-
Application:
-
custom
-
Type:
-
orignal
-
Series:
-
OEM
-
Features:
-
custom
-
Mounting Type:
-
Contract Sales
-
Description:
-
custom, Custom
-
Manufacturing Date Code:
-
custom
-
MOQ:
-
1pcs
-
Shipping time:
-
3~7Days
-
Applications:
-
PCB/PCBA/Other
-
Payment:
-
Flexible payment
-
Service:
-
One Stop BOM List Service
-
Solder mask:
-
Green. Red. Blue. White. Black.Yellow
-
Certificat:
-
IATF16949/ISO13485/ISO9001
-
Product name:
-
Electronic Components
-
Quality:
-
100% Oriqinal 100% Brand
Specification
|
Layer
|
1-32layers
|
|
Material
|
FR4 , CEM1 , CEM3 , Hight TG , Rogers , F4B , Taconic , FR1 , FR2 , 94v0 , Aluminum
|
|
Order Quantity
|
1 -500 , 000
|
|
Board shape
|
Rectangular , round , slots , cutouts ,complex , irregular
|
|
Board type
|
Rigid ,flexible ,rigid-flexible
|
|
Board cutting
|
Shear , V-score , tab-routed , counter sunk
|
|
Board thickness
|
0 . 2-8 . 0mm , Flex 0.01-0.25 "
|
|
Copper weight
|
0 . 5oZ-12oZ
|
|
Solder mask
|
Double-sided green LPI , Also support red , white , yellow , blue , black , purple , etc
|
|
Silk scree
|
Double-sided or single-sided in white , yellow , black , or negative
|
|
Min line width / space
|
0.06 / 0 . 06mm
|
|
Max board dimensions
|
25 . 6inch*43 .3inch or 650mm *1100mm
|
|
Min drill hole diameter
|
0 . 1mm
|
|
Min Laser Drill hole diameter
|
0 . 075mm
|
|
Surface finish
|
HASL , ENIG , Immission Tin , Immisson Silver ,OSP ,ENEPIG ,etc
|
|
Board thickness tolerance
|
±10%
|
|
Minimal slot width
|
0.12" ,3 .0mm , or 120mils
|
|
V-score depth
|
20-25% of board thickness
|
|
PTH Wall Thickness
|
> 0 . 025mm
|
|
PTH Hole Dia Tolerance
|
± 0 . 076mm
|
|
Non PTH Hole Dia Tolerance
|
± 0 . 05mm
|
|
Hole Position Deviation
|
± 0 . 076mm
|
|
Sink holes
|
Yes
|
|
Quality Standard
|
IPC-A600F / MIL-STD-105D
|
|
Design file format
|
Ki-CAD , Pro-E Gerber RS-274X , 274D , Eagle and AutoCAD'S DXF , DWG
|
|
Item#
|
Item Name
|
PCBA Capability
|
|
1
|
Assembly Options
|
Surface Mount ( SMT ) . Thru-Hole ( THT ) . Box building , COB , Conformal Coating ,Potting and Encapsulations , IC Programming & Marking Gringing & Lettering
|
|
2
|
Types of Solder
|
Leaded and Lead-free (RoHS Compliant ) PCB assembly services
|
|
3
|
Stencils
|
Laser cut stainless steel stencils
|
|
4
|
Minimum Order
|
1 pieces
|
|
5 |
Component Size |
Passive Component : we can accept components as small as 01005 . 0201BGA : we have the ability to handle BGA of 0 . 25mm pitch with X-ray testing Fine Pitch Parts : we can assemble 0 . 25mm fine pitch parts . POP ( Package on Package ) . QFP CCGA , CSP etc Max Component Height : 25mm ( SMT ), Top 120mm / Bot 15mm ( Wave-Solder )
|
|
6
|
Component Package
|
We accept parts in Reels , Cut Tape , Tube &Tray , Loose Parts and Bulk
|
|
7
|
Board Dimension
|
Min Board Size : No LimitedMax Board Size : 680x500mm
|
|
8
|
Board Shape
|
We can assemble boards in Rectangular, Circular and any Odd Shapes
|
|
9
|
Board Type
|
Rigid PCB . Flexible PCB,Rigid-flex PCB, Metal PCB
|
|
10 |
Repair& Rework |
Repair and rework accepted , Our BGA reballing service with which we can safely remove the misplaced BGA , reball it and put it back on the PCB correctly . It is cost-effective
|
|
11
|
Testing
|
ICT . AOI , X-Ray , Function Test ( FCT ) , Aging Test
|
|
12
|
OutPut
|
12 SMT lines and 5 DIP lines
|
|
13
|
Quality Standard
|
IPC-A-610E , IS0 13485 : 2003 , ISO 16949 : 2011 , ISO 14001 : 2004
|
