Quick Details
-
Battery Size:
-
12V100Ah
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
15kg
-
Chemistry:
-
Lithium Iron Phosphate (LiFePo4)
-
Case /Packing:
-
ABS or Customized metal case
-
Size:
-
326x170x220mm
-
Cycle life:
-
Over 3000times
-
Color:
-
Black
-
OEM:
-
Accept OEM Customize
-
Warranty:
-
5 Years, 5years
-
Certification:
-
MSDS , UN38.3
Quick Details
-
Application:
-
BOATS, Consumer Electronics, Electric Bicycles/Scooters, Electric Folklifts, electric vehicles, Electric Wheelchairs, Golf Carts, Solar Energy Storage Systems, Uninterruptible Power Supplies
-
Brand Name:
-
Suolang
-
Model Number:
-
12v
-
Battery Size:
-
12V100Ah
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
15kg
-
Chemistry:
-
Lithium Iron Phosphate (LiFePo4)
-
Case /Packing:
-
ABS or Customized metal case
-
Size:
-
326x170x220mm
-
Cycle life:
-
Over 3000times
-
Color:
-
Black
-
OEM:
-
Accept OEM Customize
-
Warranty:
-
5 Years, 5years
-
Certification:
-
MSDS , UN38.3
Suolang Tech offer a full power solution of LiFePO4 battery pack + charger + BMS.
Our range covers from 12V / 24V / 48V / 72V / 96V to 388V.
With a capacity of 10 Ah / 20Ah / 30Ah / 50Ah / 100Ah / 200Ah / 600Ah.
If the standard batteries don’t fit for your application, then we can assembly a custom made Lithium battery based on your specifications .
Please send us your parameters as dimensions, voltage, capacity and required current and we will search together with you for a solution.
Features :
Built-in Battery Management System ( BMS )
High charge & discharge current
Wide working temperature
High/Low Voltage Protection
Automatic Cell Balancing
Short Circuit Protection
Blue tooth Function (Optional)
LED Display (Optional)
More Usable capacity
Long cycle life
Lighter weight
Specification :
| Model | SL-LFP-12-100-PS |
| Nominal Voltage (V) | 12.8V |
| Nominal Capacity (Ah) | 100Ah |
| Energy | 1280wh |
| Chemistry | Lithium Iron Phosphate (LiFePo4) |
| Battery Dimensions | 326x170x220mm or customized |
| Net Weight | Approx.15.5kg |
| Layout/Terminals | M8 |
| Case /Packing | ABS Case |
| LCD display | Yes |
| Blue tooth | Yes |
| Comms. | blue tooth |
| Cycle life | >2000cycle at 100% Depth of Discharge (DoD), up to 5000 cycles at 80% DoD |
| Depth of Discharge (DoD) | 100% |
| Standard charge current | 20A (0.2C) |
| Optimum charge current range | 20A to 100A |
| Rapid charging | Max. charge current 100A (1C) (Max Temperature increase within 15°C) |
| BMS Charge Voltage Cut-Off | 15.0 V (3.75 ±0.025 vpc) (1 ±0.2 s) |
| BMS Discharge Voltage Cut-Off | 8.8 V (2.2 ±0.08 vpc) (20ms) |
| Max.Continuous discharge current | 100 Ampere |
| Peak discharge current | 200A(3C) for 10 seconds |
| Operating temperatures |
Standard 0℃~60℃
Discharge -30℃~75℃ Storage -20℃~45℃ |
| Storage performance | Capacity can be kept ≥ 80% in storage for 12months |
Applications :
AWP / Backup Power / Electric Vehicles / Floor Machines / Marine /
Solar System / EV / E-bike / E-Motorcycle / Boat /Golf Cart
