Quick Details
-
Table Travel (Y) (mm):
-
400
-
Dimension(L*W*H):
-
1900*2070*2300
-
Weight (T):
-
3.5 T
-
Range of Spindle Speed(r.p.m):
-
1 - 20000 r.p.m
-
Spindle Motor Power(kW):
-
5.5
-
Max. Table Load(kg):
-
300 kg
-
Feed Speed(mm/min):
-
1 - 20000 mm/min
-
Rapid Feed Speed(m/min):
-
48
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LEYO
-
Voltage:
-
380V
-
Product name:
-
CNC Machining Center
-
Machine Type:
-
CNC Vertical Machining Center
-
After-sales Service Provided:
-
Training
-
Product type:
-
Machining Center Cnc Mill Machine
-
Machine Name:
-
Vertical Drilling Machine Center
-
Application:
-
Metal Machining Center
-
Name:
-
Machine Center Vertical
-
Processing:
-
Metal Cutting Cnc Milling Machine
-
Keywords:
-
Machining Centre
-
Other Name:
-
Compact Machining Center
Quick Details
-
Table Size (mm):
-
700*420
-
Number of Axes:
-
3, 4, 5
-
Table Travel (X) (mm):
-
600
-
Table Travel (Y) (mm):
-
400
-
Dimension(L*W*H):
-
1900*2070*2300
-
Weight (T):
-
3.5 T
-
Range of Spindle Speed(r.p.m):
-
1 - 20000 r.p.m
-
Spindle Motor Power(kW):
-
5.5
-
Max. Table Load(kg):
-
300 kg
-
Feed Speed(mm/min):
-
1 - 20000 mm/min
-
Rapid Feed Speed(m/min):
-
48
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LEYO
-
Voltage:
-
380V
-
Product name:
-
CNC Machining Center
-
Machine Type:
-
CNC Vertical Machining Center
-
After-sales Service Provided:
-
Training
-
Product type:
-
Machining Center Cnc Mill Machine
-
Machine Name:
-
Vertical Drilling Machine Center
-
Application:
-
Metal Machining Center
-
Name:
-
Machine Center Vertical
-
Processing:
-
Metal Cutting Cnc Milling Machine
-
Keywords:
-
Machining Centre
-
Other Name:
-
Compact Machining Center
|
Items
|
Parameter
|
Unit
|
|
X/Y/Z axis travel
|
600/400/350
|
mm
|
|
X/Y/Z axis fast moving speed
|
48
|
mm/min
|
|
X/Y/Z axis Cutting feed speed
|
20
|
mm/min
|
|
Worktable size (L×W)
|
700*420
|
mm
|
|
Maximum load
|
300
|
kg
|
|
Spindle Speed
|
20000
|
rpm
|
|
Spindle motor power
|
5.5
|
KW
|
|
Spindle taper hole&Installation diameter
|
BT30
|
mm
|
|
T-slot
|
3*14*125
|
mm
|
|
Distance between spindle end face and worktable
|
135-480
|
mm
|
|
Distance from spindle centert to the column
|
420
|
mm
|
|
Controller
|
SYNTEC 22MA
|
mm
|
|
Tool magazine
|
21
|
T
|
|
Maximum tool diameter(Adjacent vacancy)
|
50（120）
|
mm
|
|
Maximum tool length
|
250
|
mm
|
|
Maximum tool weight
|
3
|
kg
|
|
Tool change time (adjacent tool)
|
1.2
|
Sec
|
|
Positioning accuracy
|
± 0.005
|
mm
|
|
Repeat positioning accuracy
|
± 0.003
|
mm
|
|
Machine dimension (L×W×H)
|
1900*2070*2300
|
mm
|
|
Machine weight
|
3500
|
kg
|
|
Power requirement
|
10
|
KVA
|
|
Required air pressure
|
6
|
kgf/cm²
|
|
Required gas flow
|
0.15
|
m²/min
|
|
Main configuration
|
|
|
|
|
||||
|
Items
|
Specification and model
|
Place of Origin
|
Remarks
|
Remarks
|
||||
|
Machine frame
|
HT300
|
China
|
LEYO
|
LEYO
|
||||
|
Sheet metal type
|
Full cover sheet metal
|
China
|
LEYO
|
LEYO
|
||||
|
Controller
|
SYNTEC 22MA
|
Taiwan,China
|
SYNTEC
|
SYNTEC
|
||||
|
Ballscrews
|
φ32*16 C3-level Precision
|
Taiwan,China/Germany
|
PMI/HIWIN/Rexroth
|
PMI/HIWIN/Rexroth
|
||||
|
Linear guideway
|
XY:30mm/2 Z:35mm/2 P-level Precision
|
Taiwan,China/Germany
|
PMI/HIWIN/Rexroth
|
PMI/HIWIN/Rexroth
|
||||
|
Three axis servo motor and drive
|
SYNTEC
|
Taiwan,China
|
SYNTEC
|
SYNTEC
|
||||
|
Spindle servo motor and drive
|
SYNTEC
|
Taiwan,China
|
SYNTEC
|
SYNTEC
|
||||
|
Spindle
|
BT30-20000 rpm
|
Taiwan,China
|
SIPINDER/Kenturn/WAY LONG
|
SIPINDER/Kenturn/WAY LONG
|
||||
|
Tool magazine
|
21T
|
Taiwan,China
|
SANJET
|
SANJET
|
||||
|
Screw rod bearing
|
BSB2562
|
Switzerland
|
FAG
|
FAG
|
||||
|
Customized Handwheel
|
Separated hand wheel
|
Taiwan,China
|
LEYO
|
LEYO
|
||||
|
Centralized automatic lubrication system
|
3.5L
|
Taiwan,China
|
HERG
|
HERG
|
||||
|
Work lighting
|
LED 24V8W
|
China
|
LEYO
|
LEYO
|
||||
|
Alarm device
|
Led 24V three color + buzzer
|
China
|
LEYO
|
LEYO
|
||||
|
Cutting cooling system
|
Cooling pump and oil tank
|
Taiwan,China
|
STAIRS PUMPS
|
STAIRS PUMPS
|
||||
|
Spindle cooling system
|
Oil cooler
|
Taiwan,China
|
REID
|
REID
|
||||
|
Electric box cooling system
|
Convection heat exchanger
|
Taiwan,China
|
REID
|
REID
|
||||
|
Process blowing system
|
LEYO
|
Taiwan,China
|
LEYO
|
LEYO
|
||||
|
Automatic power off system
|
LEYO
|
Taiwan,China
|
LEYO
|
LEYO
|
||||
|
Three axis slide rail telescopic shield
|
LEYO
|
China
|
LEYO
|
LEYO
|
||||
|
Relay
|
Schneider
|
France
|
Schneider
|
Schneider
|
||||
|
Electromagnetic contactor
|
Schneider
|
France
|
Schneider
|
Schneider
|
||||
|
Front chip punching system
|
LEYO customized
|
China
|
LEYO
|
LEYO
|
||||
|
High grade high pressure water gun
|
LEYO customized
|
China
|
LEYO
|
LEYO
|
||||
1. Your product look similar, but the price is different. What's the difference?
-The appearance are similar, but the models, parameters and configurations are different, so the prices are different. The higher the configuration, the higher the price. If you want to get an accurate quotation, please contact customer service.
2. Can your offer customized service?
-Yes, we can. Please provide the specification for the machine you need, and tell us your requirements.
3.With so many machine tools, how to choose one that suits me?
-Please provide the requirements of the products you need to process: drawings, dimensions, size of workpeices etc. we will recommend the model suitable for you according to the products you need to process.
4. Is your machine tool 3-axis, 4-axis or 5-axis?
-We have 3-5 axis machine tools, we need know the size you need for 4th 5th rotary table,NC controller ,motor brand and models,so that can offer a accurate quotation to you.
5.Can you offer me a quotation with shipping fees ?
-Usually, we offer FOB price. Because the shipping fees is different in different countries at different times. We usually provide you with an FOB quotation first. If the price you are satisfied, we will find the forwarder to provide you with a freight quotation.
