Quick Details
-
Panel Size:
-
Customize
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P5 / 292mm/W584xH505.76mm
-
Product name:
-
Hexagon Shape LED Display
-
Warranty:
-
2years
-
Brightness:
-
1000cd/sqm
-
Resolution:
-
≥1,920 Hz
-
IP rate:
-
IP30
-
Pixel pitch:
-
5mm
-
Module Side Length:
-
292mm
-
Module Dimension:
-
W584xH505.76mm
-
Display Area:
-
0.22sqm
Quick Details
-
Application:
-
Indoor
-
Brand Name:
-
Signic, Signic
-
Color:
-
Full color
-
Panel Size:
-
Customize
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P5 / 292mm/W584xH505.76mm
-
Product name:
-
Hexagon Shape LED Display
-
Warranty:
-
2years
-
Brightness:
-
1000cd/sqm
-
Resolution:
-
≥1,920 Hz
-
IP rate:
-
IP30
-
Pixel pitch:
-
5mm
-
Module Side Length:
-
292mm
-
Module Dimension:
-
W584xH505.76mm
-
Display Area:
-
0.22sqm
Specification
|
Pixel pitch
|
2.5mm
|
3mm
|
3mm
|
4mm
|
5mm
|
|
Destiny
|
160000dots/sqm
|
111111dots/sqm
|
111111dots/sqm
|
62500dots/sqm
|
40000dots/sqm
|
|
LED Type
|
SMD1010
|
SMD1515
|
SMD1515
|
SMD2121
|
SMD2121
|
|
Pixel type
|
SMD 3 in 1
|
SMD 3 in 1
|
SMD 3 in 1
|
SMD 3 in 1
|
SMD 3 in 1
|
|
Module Side Length
|
125mm
|
288mm
|
576mm
|
275mm
|
292mm
|
|
Module Dimension
|
W600xH519.62mm
|
W576xH498.8mm
|
W1152xH997.66mm
|
W550xH476.39mm
|
W584xH505.76mm
|
|
Module Resolution
|
W240xH207pixels
|
W192xH166pixels
|
W384xH332pixels
|
W137xH119pixels
|
W116xH101pixels
|
|
Display Area
|
0.23sqm
|
0.22sqm
|
0.86sqm
|
0.2sqm
|
0.22sqm
|
|
Price(USD)
|
$740
|
$630
|
$1,940
|
$460
|
$350
|
|
Net Weight
|
7kg
|
6.6kg
|
25kg
|
6kg
|
6.6kg
|
|
Drive mode
|
1/24 scan
|
1/20 scan
|
1/20 scan
|
1/16 scan
|
1/16 scan
|
|
Viewing Distance
|
≥3M
|
≥3M
|
≥3M
|
≥4M
|
≥5M
|
|
Brightness
|
1000cd/sqm
|
1000cd/sqm
|
1000cd/sqm
|
1000cd/sqm
|
1000cd/sqm
|
|
Viewing Angle
|
140° (H)/140°(V)
|
140° (H)/140°(V)
|
140° (H)/140°(V)
|
140° (H)/140°(V)
|
140° (H)/140°(V)
|
|
Refresh rate
|
≥1,920 Hz
|
≥1,920 Hz
|
≥1,920 Hz
|
≥1,920 Hz
|
≥1,920 Hz
|
|
Input voltage
|
AC46〜54HZ，220V±15％/ 110V±15％
|
AC46〜54HZ，220V±15％/ 110V±15％
|
AC46〜54HZ，220V±15％/ 110V±15％
|
AC46〜54HZ，220V±15％/ 110V±15％
|
AC46〜54HZ，220V±15％/ 110V±15％
|
|
Control method:
|
Asynchronous & Synchronous
|
Asynchronous & Synchronous
|
Asynchronous & Synchronous
|
Asynchronous & Synchronous
|
Asynchronous & Synchronous
|
|
Temperature Operating (℃)
|
-10°～+60°
|
-10°～+60°
|
-10°～+60°
|
-10°～+60°
|
-10°～+60°
|
|
Working Humidity
|
10%–70%RH
|
10%–70%RH
|
10%–70%RH
|
10%–70%RH
|
10%–70%RH
|
|
IP Rating
|
IP30
|
IP30
|
IP30
|
IP30
|
IP30
|
|
Application
|
Indoor
|
Indoor
|
Indoor
|
Indoor
|
Indoor
|
|
Certificate
|
CE/ROHS/FCC
|
CE/ROHS/FCC
|
CE/ROHS/FCC
|
CE/ROHS/FCC
|
CE/ROHS/FCC
|
Product Feature
What is the feature of creative LED displays?
The biggest feature of Creative LED displays is that most of the Creative LED displays are customized products. The special-creative LED display can better adapt to the structure and environment of the overall building. In addition, because the Creative LED display is used on more important occasions, it also has the features of high resolution, high refresh, high contrastratio, and so on.
Product Case
What are the features of the hexagon LED display?
• Customized Services
SignicLED makes your ideas into reality with our hexagon LED screen. This hexagon LED display panel is tailored for lots of different sizes. Based on customer requirements, various screen sizes can be customized. It accepts custom solutions for hexagon LED displays. For example, single-sided, double-sided, and 3D performance for optional.
• Creative Design
In the face of serious product homogeneity, stages, exhibition booths, events, clubs, and retail outlets are all working hard to make their products “eye-catching.” Therefore, great attention is paid to the shape design of the LED display screen. In addition to the hexagon, there are other shape options, like diamond, prismatic, star, Horn, DJ booth, and other irregular shapes.
• Indoor & Outdoor
With people’s pursuit of various theatrical performances, wedding performances, opening ceremony performances, leisure, and entertainment, etc., hexagon LED display screen has also become the first choice of event planners. In order to meet the diverse needs of customer projects, the hexagon LED display supports high definition indoor version, high brightness, and waterproof outdoor version.
• Flexible Installation
Customers can flexibly install in combination with the building structure of the installation site itself. Hexagon LED display
adopts a trapezoidal circuit design. It makes seamless splicing and perfect visual performance with this LED video wall. Perfect flatness makes a perfect effect with creative LED display.
• Easy Control
Hexagon LED display supports Synchronous & asynchronous mode, live broadcasting, and Autoplay without PC. Besides, each side panel can work independently and display different advertising content, working 24/7 hours. You can save time and money by designing LED billboards online. Even printing costs are reduced because everything is done on the computer.
• Various Applications
Choosing a creative LED billboard is an easy and efficient way to promote your business. Hexagon LED display is perfect for creative design and solutions, such as concerts, retail advertising, exhibitions, stage background, DJ booth, events, bars, clubs, airports, press conferences and etc. Assemble an interactive display area with high picture quality that enables you to effectively communicate, engage and entertain the masses, consumers and visitors.
SignicLED makes your ideas into reality with our hexagon LED screen. This hexagon LED display panel is tailored for lots of different sizes. Based on customer requirements, various screen sizes can be customized. It accepts custom solutions for hexagon LED displays. For example, single-sided, double-sided, and 3D performance for optional.
• Creative Design
In the face of serious product homogeneity, stages, exhibition booths, events, clubs, and retail outlets are all working hard to make their products “eye-catching.” Therefore, great attention is paid to the shape design of the LED display screen. In addition to the hexagon, there are other shape options, like diamond, prismatic, star, Horn, DJ booth, and other irregular shapes.
• Indoor & Outdoor
With people’s pursuit of various theatrical performances, wedding performances, opening ceremony performances, leisure, and entertainment, etc., hexagon LED display screen has also become the first choice of event planners. In order to meet the diverse needs of customer projects, the hexagon LED display supports high definition indoor version, high brightness, and waterproof outdoor version.
• Flexible Installation
Customers can flexibly install in combination with the building structure of the installation site itself. Hexagon LED display
adopts a trapezoidal circuit design. It makes seamless splicing and perfect visual performance with this LED video wall. Perfect flatness makes a perfect effect with creative LED display.
• Easy Control
Hexagon LED display supports Synchronous & asynchronous mode, live broadcasting, and Autoplay without PC. Besides, each side panel can work independently and display different advertising content, working 24/7 hours. You can save time and money by designing LED billboards online. Even printing costs are reduced because everything is done on the computer.
• Various Applications
Choosing a creative LED billboard is an easy and efficient way to promote your business. Hexagon LED display is perfect for creative design and solutions, such as concerts, retail advertising, exhibitions, stage background, DJ booth, events, bars, clubs, airports, press conferences and etc. Assemble an interactive display area with high picture quality that enables you to effectively communicate, engage and entertain the masses, consumers and visitors.
