Quick Details
-
Warranty:
-
3 YEARS
-
Brand Name:
-
Zhiwang
-
Model Number:
-
ZW-6W-5V-CCTV
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
235mmx170mmx220mm
-
Size of Cell:
-
42mm*78mm
-
Number of Cells:
-
10
-
Max Voltage:
-
5V
-
Open Voltage:
-
5.5V
-
Peak Power:
-
6.3W Mono
-
Max Current:
-
1.2A Mono
-
Short Current:
-
1.5A Mono
-
Additional Function:
-
Support WIFI, Projection, Camera Function
-
Weight:
-
0.3KG
-
Charging port:
-
Micor USB/ Type C/ DC
Quick Details
-
Cell size:
-
41mm*78mm
-
Type:
-
PERC
-
Panel Efficiency:
-
18% - 21%
-
Warranty:
-
3 YEARS
-
Brand Name:
-
Zhiwang
-
Model Number:
-
ZW-6W-5V-CCTV
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
235mmx170mmx220mm
-
Size of Cell:
-
42mm*78mm
-
Number of Cells:
-
10
-
Max Voltage:
-
5V
-
Open Voltage:
-
5.5V
-
Peak Power:
-
6.3W Mono
-
Max Current:
-
1.2A Mono
-
Short Current:
-
1.5A Mono
-
Additional Function:
-
Support WIFI, Projection, Camera Function
-
Weight:
-
0.3KG
-
Charging port:
-
Micor USB/ Type C/ DC
|
Model: |
ZW-6W-5V-CCTV |
|
|
Brand: |
Zhiwang |
|
|
Size: |
235mmx170mmx220mm |
|
|
Material: |
Poly crystalline silicon plastic (aluminum) border color material can be customized. |
|
|
Battery: |
10 |
|
|
Size of Cell |
42mm*78mm |
|
|
Peak power: |
6.3W Mono |
|
|
Max voltage: |
6V |
|
|
Max current: |
1.2A |
|
|
Open voltage: |
5.5V |
|
|
Short current: |
1.8A |
|
|
Weight: |
0.3KG |
|
|
Keyword: |
Glass Laminated Solar Panel |
|
|
Front Glass: |
3.2mm, High Transmission, Low iron, tempered Glass |
|
|
Color: |
Customize |
|
|
Raw Material: |
Glass, Plastic Frame or Glass and aluminium sash Frame Poly-crystalline or Mono-crystalline Silicon EVA-------excellent anti-aging EVA TPT-------TPT hot seal made of flame resistance |
|
|
Operating Temperature(°C) |
-40°C ~ + 85°C |
|
|
Maximum System Voltage |
20V(UL)/30V(IEC) DC |
|
|
Maximum Rated Current Series |
2A |
|
|
Temperature Coefficients of Pmax |
-0.435% |
|
|
Temperature Coefficients of Voc |
-0.35% |
|
|
Temperature Coefficients of Isc |
0.043% |
|
|
Nominal Operating Cell Temperature |
47+/-2°C |
|
|
Current temperature coefficient |
%/K |
0.06+/-0.01 |
|
Voltage temperature coefficient |
mV/K |
-(78+/-10) |
|
Power temperature coefficient |
%/K |
-(0.5+/-0.05) |
Features
1. High cell efficiency with quality silicon materials for long term output stability;
2. Strictly quality control ensure the stability and reliability, totally 23 QC procedures;
3. Used in glass laminated solar panels high transmittance low iron tempered glass or with enhanced stiffness and impact resistance;
4. Epoxy resin sealant materials with high transparency, high hardness and high strength are used in epoxy resin sealant solar panels;
5. In PET semi-flexible solar panels, high light transmittance, high hardness and high strength PET surface materials are used.
6. Excellent electrical performance at high temperature and low irradiance;
7. Can be widely used in decorative lights, electric toys, electronics, gifts and other industries;
8. Voltage, power, material, size and shape can be customized;
9. The products are widely used in solar lighting, lamps, household electricity, transportation, communications, meteorology, construction and photovoltaic power stations and other fields.
10. High quality solar cell, high solar energy conversion efficiency, up to 35%.
11. Monocrystalline or polycrystalline silicon solar cells are available.
12. Transparent low iron tempered glass and anodized alumina frame used in glass laminated solar panels ensure the modules work in extreme outdoor environments.
13. Glass laminated solar panels have a service life of up to 15 years. PET solar panels have a service life of up to 5 years; Epoxy rubber solar panels have a service life of 1-3 years.
14. Strict quality control, in line with the highest international standards;
15. Two professional plants of Zhiwang New Energy manufacture world-class products in accordance with iso9001:2008 (Quality management system) certification;
Quality Assurance Test
Thermal cycling test (provided by the supplier of floor material and surface material)
Thermal shock test (provided by the supplier of floor material and surface material)
Heat/freeze and high humidity cycle test (provided by the supplier of floor material and surface material)
Electrical isolation test (laboratory simulation data)
Hail impact test (laboratory simulation data)
Mechanical, wind and torsional load tests (laboratory simulation data)
Salt spray test (provided by the supplier of floor materials and surface materials)
Light and water exposure tests (laboratory simulation data)
Wet CO2 / SO2 (laboratory simulation data)
Test ambient temperature 25 ° C ±2 ° C
The humidity of the test environment is 60%-70%
Light intensity 40*1000 LUX
The vertical distance of light is 30cm
Open-circuit test multimeter
Load the test dedicated test stand
Application battery charging
Storage environment 20cm above the ground; Humidity of 60% 70%; The normal temperature
Working environment -20℃ - +85℃
Filling factor 78
Q. Are you a manufacturer or a trading company?
A. We are a factory in Yuyao, with OEM&ODM&Customization available.
Q. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our 5V Waterproof Portable Solar Panel ZW-6W-5V Arlo Camera Solar Panel Power Charger 6.3W Mini CCTV Solar Panels sample.
Q. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.
Q. What is your terms of delivery?
A: EXW, FOB, CIF.
Q. How about your delivery time?
A: Generally, it will take 15 to 30 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your 5V Waterproof Portable Solar Panel ZW-6W-5V Arlo Camera Solar Panel Power Charger 6.3W Mini CCTV Solar Panels order.
Q. Can you produce according to the samples?
A: Yes, we can produce by your 5V Waterproof Portable Solar Panel ZW-6W-5V Arlo Camera Solar Panel Power Charger 6.3W Mini CCTV Solar Panels samples or technical drawings. We can build the molds and fixtures.
Q. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery Zhiwang 10W 18V Mono Silicon solar panel for solar system controlador charger ZW-10W-18V-1.
Q.How many years for warranty?
A.Our warranty is 5 years for our 5V Waterproof Portable Solar Panel ZW-6W-5V Arlo Camera Solar Panel Power Charger 6.3W Mini CCTV Solar Panels.
Q: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
Zhiwang New Energy attaches great importance to the development of new products.
In the past 15 years, the company has been developing itself.
We sincerely welcome new and old customers at home and abroad to visit!
