Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
AKUSENSE
-
Sectional area:
-
30X30mm
-
Protection height:
-
180mm
-
Light curtain height:
-
210mm
-
Operating voltage:
-
12~24V DC±10%
-
Degree of protection:
-
IP65
-
Current consumption:
-
<200mA
-
Synchronizatioline synchronizationn type:
-
Optical synchronization, line synchronization
-
Response time:
-
≤10ms
-
Light source:
-
Infrared LED (Modulated)
-
Connection:
-
M12 connector
Quick Details
-
Mounting Type:
-
easy
-
Description:
-
area sensor
-
Model Number:
-
BKL20-T1006PC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
AKUSENSE
-
Sectional area:
-
30X30mm
-
Protection height:
-
180mm
-
Light curtain height:
-
210mm
-
Operating voltage:
-
12~24V DC±10%
-
Degree of protection:
-
IP65
-
Current consumption:
-
<200mA
-
Synchronizatioline synchronizationn type:
-
Optical synchronization, line synchronization
-
Response time:
-
≤10ms
-
Light source:
-
Infrared LED (Modulated)
-
Connection:
-
M12 connector
Product Description
Specification
|
Beam pitch
|
10/20/40mm
|
|
Min. sized detectable objects
|
>φ14/φ25/φ45mm, opaque
|
|
Operating voltage
|
12~24V DC±10%
|
|
Current consumption
|
<200mA
|
|
Power consumption
|
3~8W
|
|
Response time
|
≤10ms
|
|
Light source
|
Infrared LED (Modulated)
|
|
Ambient humidity
|
35~85%RH
|
|
Anti-interference ability
|
10000Lux(Incident angle≥5°)
|
|
Insulation resistance
|
>100MΩ high resistance meter based on DC500V
|
|
Accessories
|
Cable length 3m, female (Customization available)
|
