RCCP Reinforced Concrete Jacking Pipe Steel Cage Welding Equipment

RCCP Reinforced Concrete Jacking Pipe Steel Cage Welding Equipment

FOB Reference Price: Get Latest Price

≥1 Sets

US $20000

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: SMC

Voltage:: 220V/380V/480V

Power:: 7.5KW

Dimension(L*W*H):: 100X90X80CM

Weight:: 100 kg

Quick Details

Pipe Material:: CONCRETE

Production Capacity:: 100Pieces per Day

Place of Origin:: Shanghai, China

Brand Name:: SMC

Voltage:: 220V/380V/480V

Power:: 7.5KW

Dimension(L*W*H):: 100X90X80CM

Weight:: 100 kg

Product Overview

RCCP Reinforced Concrete Jacking Pipe Steel Cage Welding Equipment

Application range: suitable for DN400-3600mm spigot and bell port reinforcement cage and
DN400-3600 flat/tongue-groove/steel socket reinforcement cage. The welding cage diameter:DN425-3850mm.Suitable
Diameter: ring and longitudinal wire:4-12mm
Spigot/Bell Angle:0-15 degree
Welding longitudinal reinforcement: 6 or 12 or 18 or 24 or 36 pieces
Welding Length: 0-6000mm
Ring reinforce gap distance:40-110mm
Steel Bar should be low carbon cold wire drawing (meet GB/T343-94 Standard). The steel bar should be clean, no oil and rust.

FEATURES AT A GLANCE

DN800-2400X3000MM Cage Welding Machine

Welding Diameter:800-2400mm

Welding Length:1000-6000mm

Wire Thickness:4-12mm

Spigot/Bell Angle:0-15 degree

Wire Quantity: 6/12/18/24/36

Gap Distance:40-110mm

Cooling type: water

Air Compressor: have

Structure type: push or pull

Shipping Container:40feet HQ

Round Disc Welding Heads

Touch Screen PLC Control

Export Shipping to Canada

PRODUCT SPECIFICATIONS

Model	DN300-1200X3/6M	DN800-2400X3/6M	DN1400-3600X3/6M
Application Diameter Range	300-1200MM	800-24000MM	1400-3600MM
Nominal Length(mm)	3000/6000MM	DN300-1200X3/6M	DN300-1200X3/6M
Numbers of longitudinal bar(pieces)	6/12	6/12/24	6/12/24
Steel Bar Thickness(mm)	4-12mm	4-12mm	4-12mm
Ring Bar Pitch(mm)	40-110mm	40-110mm	40-110mm
Socket Angle	0-15degree	0-15degree	0-15degree
Power	Less Than 6KW	Less Than 10KW	Less Than 20KW
Transformer(KVA)	75	100	150
Reference Weight(ton)	about 7.5tons	about 9tons	about 10tons
Dimension(mm)	7700X3410X2475	8580X3990X3231	8755X4650X3660

PRODUCT CONFIGURATION

12mm wire Thickness Cage Welding

English Version Control System

Spigot and Bell Port

SALES AND SERVICE NETWORK

Successful Project

Project in Canada

Project in India

Project in Toronto

SIMILAR PRODUCTS

FAQ

Our factory is a professional manufacturer of
cement products complete sets equipment and molds. It has more than 40 years of experience in research and development, design and manufacture of cement products machinery and equipment. The company has strong technical strength and has a number of national patents. Our factory passed the ISO9001:2008 quality management system certification, and obtained a number of national invention patents. Our main products:
1. DN400-4000mm PCCP Pipe Production Line

2. JCCP Concrete Jacking Pipe Production Machine
3. Concrete Drainage Pipe Production Line
4. RCP Concrete Steel Cage Welding Machine
5. Concrete Pipe Mold
Our company have sell more than 60sets complete PCCP pipe production line equipment to domestic and foreign market. Now our
company's PCCP production line equipment has been exported to Canada, Egypt, India, Indonesia, Philippines and so on.

Welcome to visit our factory and concrete pipe production line working site.
