Quick Details
-
Model Number:
-
T8011-ZCQ-H
-
Max. Current:
-
5A
-
Function option:
-
DP on-none-on
-
Rating:
-
5A @125 VAC or 28 VDC (Q contact)
-
Operated Temperature:
-
-30℃~85℃
-
life Cycles:
-
40,000
-
Dielectric withstanding voltage:
-
1500VRMS at Sea Level
-
Contact resistance:
-
10mΩ max. (initial) @2-4 VDC, 100Ma
-
INSULATION RESISTANCE:
-
1,000 MΩ min
-
Contacts:
-
Silver-plated/Gold-plated/tin-plated
-
Certification:
-
UL,CUL, CQC, ROHS, REACH
Quick Details
-
Max. Voltage:
-
125VAC/28VDC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HONGJU
-
Model Number:
-
T8011-ZCQ-H
-
Max. Current:
-
5A
-
Function option:
-
DP on-none-on
-
Rating:
-
5A @125 VAC or 28 VDC (Q contact)
-
Operated Temperature:
-
-30℃~85℃
-
life Cycles:
-
40,000
-
Dielectric withstanding voltage:
-
1500VRMS at Sea Level
-
Contact resistance:
-
10mΩ max. (initial) @2-4 VDC, 100Ma
-
INSULATION RESISTANCE:
-
1,000 MΩ min
-
Contacts:
-
Silver-plated/Gold-plated/tin-plated
-
Certification:
-
UL,CUL, CQC, ROHS, REACH
Product Description
Specification
|
item
|
value
|
|
Certification
|
UL,CUL, CQC, ROHS, REACH
|
|
Place of Origin
|
China
|
|
|
Guangdong
|
|
Max. Current
|
5A
|
|
Max. Voltage
|
125VAC/28VDC
|
|
Rating
|
5A @125 VAC or 28 VDC (Q contact)
|
|
Operated Temperature
|
-30℃~85℃
|
|
life Cycles
|
40,000
|
|
Dielectric withstanding voltage
|
1500VRMS at Sea Level
|
|
Contact resistance
|
10mΩ max. (initial) @2-4 VDC, 100Ma
|
|
INSULATION RESISTANCE
|
1,000 MΩ min
|
|
Contacts
|
Silver-plated/Gold-plated/tin-plated
|
