Quick Details
-
Warranty(Year):
-
5-Year
-
Lamp Luminous Efficiency(lm/w):
-
160
-
Lifespan (hours):
-
60000
-
Working Time (hours):
-
60000
-
Product Weight（kg）:
-
8.5
-
Lamp Luminous Flux(lm):
-
80000
-
CRI (Ra>):
-
90
-
Beam Angle(°):
-
15°/30°/45°/60°
-
Working Lifetime(Hour):
-
60000
-
Place of Origin:
-
Guangdong, China
-
Working Temperature(℃):
-
-40~50
Quick Details
-
Lamp Body Material:
-
Die-cast aluminum
-
Application:
-
Theme Park
-
Light Source:
-
Induction Lamps, Fluorescent, LED
-
Warranty(Year):
-
5-Year
-
Lamp Luminous Efficiency(lm/w):
-
160
-
Lifespan (hours):
-
60000
-
Working Time (hours):
-
60000
-
Product Weight（kg）:
-
8.5
-
Lamp Luminous Flux(lm):
-
80000
-
CRI (Ra>):
-
90
-
Beam Angle(°):
-
15°/30°/45°/60°
-
Working Lifetime(Hour):
-
60000
-
Place of Origin:
-
Guangdong, China
-
Working Temperature(℃):
-
-40~50
Features
1. ADC12 Die-cast aluminium heat-sink with efficiency of up to 96W/ M.K.
2. Each module is 500W for optimum choice
3. Strong bracket, for a more solid installation
4. PC lens, Beam angle from 15/30/45/60/90 degree options
5. Lumileds SMD3030/5050 LED high brightness with 100,000hrs lifespan
6. Meanwell/Sosen/Inventronics/Philips driver for high stability and efficiency
7. IP 66 protection, Anti-dust, anti-corrosion, anti-UV, outdoor usage
8. Wide CCT colour, from 3000K - 6500K, Ra
>
70-80(optionals)
9. Easy installation, rotatable module and rotatable brackets
10.Widely used on stadium lighting, high mast lighting, airport lighting, etc
11.Laser pointer for precise aiming
12.5 years
Application
Sports stadium lighting, High mast lighting, Airport lighting etc.
Specifications
| Power | 500W | IP Rating | IP66 | |
| LED Chips | LUMILEDS | Lifespan | 60,000Hrs | |
| Luminous Efficacy | 140-160 lm/W | Housing | Die-cast aluminum | |
| Luminous Flux | 70,000-80,000 lm | Cover | PC Lens | |
| CCT | 3000K~6500K | Fixture Size | 721*273*122mm | |
| Beam Angle |
15°/30°/45°/60°
|
Carton Size | 784*504*185mm | |
| CRI(Ra) | 70+/80+ | Net Weight | 8.5kg | |
| Driver |
Me
an
W
ell
/Sosen/Inventronics
|
Gross Weight | 9.7kg | |
| Input Voltage | AC100~277V | |||
| Power Factor | 0.95+ | |||
| Output Voltage | DC48V | |||
| THD | 15%+ | |||
| Driver Efficiency | 92% | |||
Installation
